Non-contact liquid level sensor instruction manual
(Intelligent externally attached pipeline detection liquid level special series products)
1st. Overview .................................................................................................................................................................................... 2
2nd.Product Features ...................................................................................................................................................................... 2
3rd.Product Applications ................................................................................................................................................................ 2
4th.Product parameter .................................................................................................................................................................... 3
5th.product selection........................................................................................................................................................................ 3
6th. Installation method .................................................................................................................................................................. 3
7th. Sensitivity adjustment.............................................................................................................................................................. 5
8th.Y28A wiring diagram of various models ................................................................................................................................ 5
9th. Product size and physical map................................................................................................................................................ 7
10th.Other matters needing attention............................................................................................................................................ 7
11th.Troubleshooting ....................................................................................................................................................................... 8
12th.Product warranty terms and instructions ............................................................................................................................ 8
13th. Manual version ..................................................................................................................................................................... 10
