Pyroelectric Human Body Infrared Sensor Manual
1st. Overview .................................................................................................................................................................................... 2
2nd.Product Features ...................................................................................................................................................................... 2
3rd. Product Applications ............................................................................................................................................................... 2
4th.Technical Parameters................................................................................................................................................................ 3
5th. Product selection model ........................................................................................................................................................... 3
6th. Installation method .................................................................................................................................................................. 4
7th. Product size and physical map................................................................................................................................................ 4
8th. Wiring instructions .................................................................................................................................................................. 6
9th. wiring diagram of various models .......................................................................................................................................... 7
10th. Installation and use instructions ........................................................................................................................................... 8
11th.Product warranty terms and instructions ............................................................................................................................ 8
12th. Manual version ..................................................................................................................................................................... 10
Phone: 86-0755-33523599
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
XKC-003K4
table of Contents
FAX: 86-0755-33515410
-V1.6
XKC-003K4
URL: http://www.sz-xkc.com
1 / 10
Advertisement
Table of Contents
Related Manuals for XingKeChuang XKC-003K4
Summary of Contents for XingKeChuang XKC-003K4
-
Page 1: Table Of Contents
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. -V1.6 XKC-003K4 Pyroelectric Human Body Infrared Sensor Manual XKC-003K4 table of Contents 1st. Overview ....................................2 2nd.Product Features ..................................2 3rd. Product Applications ................................2 4th.Technical Parameters................................3 5th. Product selection model ................................3 6th. -
Page 2: 1St. Overview
Shenzhen XingKeChuang Technology Co., Ltd. 1st. Overview XKC-003K4 is an automatic control product based on infrared technology. It has high sensitivity, strong reliability, and ultra-low voltage working mode. It is widely used in various automatic induction electrical equipment. 2nd.Product Features 1. -
Page 3: 4Th.technical Parameters
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. 4th.Technical Parameters Operating voltage range DC4.5-20V Quiescent Current <200uA High and low level (high 3.3V/low 0V)/NPN/relay (normally Output type open/normally closed)/drive 2A LED Trigger method L can not be triggered repeatedly / H can be triggered repeatedly (default) -
Page 4: 6Th. Installation Method
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. 6th. Installation method （ Wall installation icon） （ Ceiling installation icon） 7th. Product size and physical map XKC-003K4-V XKC-003K4-M XKC-003K4-LED2A XKC-003K4-N XKC-003K4-MC 1. Note: Shell size 51.5mm(L)*52.6mm(W)*32.5mm(H) (The following is the size drawing of model... - Page 5 深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. 2. The following is the size drawing of model XKC-003K4-LED2A Phone: 86-0755-33523599 FAX: 86-0755-33515410 URL: http://www.sz-xkc.com Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen 5 / 10...
-
Page 6: 8Th. Wiring Instructions
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. 8th. Wiring instructions Adjust the distance potentiometer to rotate clockwise, the sensing distance is reduced (about 3 meters); on the contrary, the sensing distance is increased (about 7 meters); Adjust the delay potentiometer to rotate clockwise, the induction delay is shortened (about 5S); on the contrary, the induction delay is extended (about 300S). -
Page 7: 9Th. Wiring Diagram Of Various Models
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. 9th. wiring diagram of various models 1. The negative pole of the black wire power supply; 2.OUT yellow wire signal output; 3. Red wire power supply positive; 4.L can not trigger the port repeatedly;... -
Page 8: 10Th. Installation And Use Instructions
深圳市星科创科技有限公司 Shenzhen XingKeChuang Technology Co., Ltd. The relay normally closed output (dry contact signal) means that the relay is closed when there is no induction, and the relay is open when there is induction. 10th. Installation and use instructions 1. After the sensor is powered on, there is about one minute of initialization time, during which the module will output 0-3 times at intervals, and enter the normal standby state after one minute. - Page 9 DOA application deadline is 7 days from the product shipment date. (F). Statement 1. The copyright of this manual belongs to Shenzhen Xingkechuang Technology Co., Ltd. (Xingkechuang) and its authorized licensors. Shenzhen Xingkechuang Technology Co., Ltd. (Xingkechuang) reserves all rights.
-
Page 10: 12Th. Manual Version
Shenzhen XingKeChuang Technology Co., Ltd. 4. Due to product version upgrades or other reasons, the contents of this manual may change. Xingkechuang reserves the right to modify the contents of this manual without any notice or prompt. This manual is only used as a guide.
