Comen STAR 5000 Manual

Hide thumbs

Advertisement

Table of Contents

Copyright
Version：A
p
No.：046-001670-00
p
Add.：Floor 10, Floor 11 and Section C of Floor 12 of Building 1A & Floor 1 to Floor 5 of Building 2,
p
FIYTA Timepiece Building, Nanhuan Avenue, Matian Sub-district, Guangming District, Shenzhen,
Guangdong, 518106, P.R. China
Note
Quick operation guide serves as a convinient way for you to master the basic functional operation of this
p
product. Please refer to the product instruction manual for detailed instructions.
Please carefully read and understand the contents of the product instruction manual before installing and using
p
this product to ensure the correct use of this product and to ensure the safety of patients and operators.
All illustrations provided herein are for reference only. The menus, options, values and functions shown in the
p
illustrations may be not exactly identical to what you see on the monitor. If you have any doubt，please
contact our company.
The content of this quick operation guide is subject to changes without prior notice. All rights reserved by
p
Shenzhen Comen Medical Instruments CO.,Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAR 5000 and is the answer not in the manual?

Questions and answers

Mrs Peter
March 12, 2025

How to clear sd storage

0

Subscribe to Our Youtube Channel

Related Manuals for Comen STAR 5000

Summary of Contents for Comen STAR 5000

  • Page 1 If you have any doubt，please contact our company. The content of this quick operation guide is subject to changes without prior notice. All rights reserved by Shenzhen Comen Medical Instruments CO.,Ltd.

  • Page 3: Front View

    Product Introduction ①Alarm indicator: emitting light of different colors according to different alarm levels. ②Logo: COMEN. ③Keys: nAlarm reset key nFreeze/unfreeze key nRecord/stop key: press this key to start a real-time recording. nTOCO Reset key nMain menu key ④Power on/off key: press this key to switch on/off the monitor.

  • Page 4: Right View

    Product Introduction Right View Rear View Supporting shaft: to support the display. Interfaces: including four sockets with the USB port same definition, used as Fetal Heart Rate Network port: for connection to the network. (FHR) socket 1, FHR socket 2, socket of Handle: you can hold the handle to move the fetal movement marker sensor and TOCO monitor.

  • Page 5: On-Screen Display

    On-screen Display Network Connection Icon, Select the network connection icon to directly access [NETWORK SET] menu. Patient information area, select here to directly access [PATIENT INFO] menu. Technical alarm message area Physiological alarm message area, select here to directly access [ALARM RECALL] window. Timed monitoring information area, Click here to directly access [TIMER] menu.

  • Page 6: Basic Operations

    Basic Operations Setting Alarm Volume Using the Main Menu Select the on-screen key to access [MAIN MENU] Enter [Main Menu] [Option Setup]  [Alm Vol] (Alarm and perform operations and settings. Volume) to set the alarm volume (range: X-6, where X is the minimum alarm volume).
  • Page 7 Basic Operations Alarm Limit Select [Save Current As User Config] to save current settings. You can set up the alarm limits for all alarm levels with the same method. Here FHR1 is taken as an example: Select the FHR1 parameter area; How to use factory adult/pediatric/neonate default settings: Select [FHR1 Alarm Setup] in the pop-up [FHR1 Setup] 1.Access [Main Menu]→[Monitor Setup] →[Restore Default...
  • Page 8 Printing Changing record paper: Record paper Thermal print head Paper roller Paper compartment lock Unlock the paper compartment with your right hand and open the compartment door outwards; Put new record paper into paper slot with the grid side facing up and top of the paper (210) toward the left of the monitor;...
  • Page 9 Printing Real-time Printing Stored Patient Case Printing: Real-time printing means the printing triggered by pressing the print key on the front Stored patient case printing means the printing panel during real-time monitoring. triggered by pressing the print key on the front panel and enter patient case review interface.
  • Page 10 Battery The monitor is equipped with a built-in rechargeable battery. When an AC power supply is connected, the battery is charged automatically until it is fully charged. In the event of unexpected power outage, the system automatically uses the battery to supply power, thus to avoid interruption of device operation. After grid power supply is cut off, the battery indicator turns on.
