ADSORPTION DEHUMIDIFIER
IA2 ES F
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IA2 ES F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CorroVenta IA2 ES F

Summary of Contents for CorroVenta IA2 ES F

  • Page 1 ADSORPTION DEHUMIDIFIER IA2 ES F USER MANUAL...

  • Page 2: Table Of Contents

    Service reminder ........................... 25 Maintenance and service ........................26 Filter replacement ......................... 27 Service and repair work as well as cleaning .................. 27 Accessories and consumables ......................28 Fault tracing ............................29 Technical data ........................... 31 © Corroventa Avfuktning AB 2023.04 1 (31)

  • Page 3: Intended Use

    The machine is not intended for use in environments where flammable gases can occur. Any other use of IA2 ES F, as well as use contrary to the instructions in this manual, may result in personal injury and/or damage to equipment and other property.

  • Page 4: Manufacture Directive

    Manufacture directive IA2 ES F is CE approved. The dehumidifier is manufactured in Bankeryd, Sweden, by Corroventa Avfuktning AB, which is certified in accordance with ISO 9001. Limitation of Liability Incorrect installation and/or incorrect use can cause damage to property as well as injury.

  • Page 5: Safety Information

    Children must be kept under supervision to prevent them from playing with the device. Electrical installations carried out in connection with the installation of IA2 ES F must be performed by a qualified electrician in accordance with local and national regulations.
  • Page 6 26. The dehumidifier must not be used with accessories other than those described in this manual or approved by Corroventa Avfuktning AB. Contact the supplier for further advice on the safety and use of the product.

  • Page 7: Product Overview

    Product overview The dehumidifier’s main components Control panel Switch Process air connector integrated in filter hatch Wet air connector Regeneration air connector integrated in filter hatch System device Dry air connector © Corroventa Avfuktning AB 2023.04 6 (31)
  • Page 8 Rotor Process air fan Rotor motor Regeneration heater Regeneration fan © Corroventa Avfuktning AB 2023.04 7 (31)

  • Page 9: Drying Theory And Drying Method

    Works in the hatched area. As can be seen from the diagram above, condensing dehumidifiers are used in warm and moist conditions where the aim is to dry the room and the ambient air. © Corroventa Avfuktning AB 2023.04 8 (31)

  • Page 10: This Is How The Dryer Works

    This is how the dryer works IA2 ES F is a four-hole adsorption dehumidifier, which means that it has two fans and two entirely separate air flows. It is also fitted with connectors for all the air flows, which deliver maximum flexibility as regards the positioning of the machine, within or outside of the space that is to be dried.

  • Page 11: Transportation And Lifting

    Installation The installation of IA2 ES F should be planned in such a way that the ducting for the required air flows can be kept as short and, for the respective two air flows, as well balanced as possible. Long ducts generate greater resistance for the respective fans and impede the capacity and energy efficiency in the process.
  • Page 12 Start for the machine to run continuously (Manual mode) at maximum capacity (Max). 7. Check that the air flows are as anticipated, and that ducting, connected pipes and hoses are not leaking. © Corroventa Avfuktning AB 2023.04 11 (31)

  • Page 13: Starting And Stopping The Machine

    2. The machine now enters a cooling phase – wait until the countdown on the display is complete. 3. The machine is now in standby. To shut down completely, turn off the switch. © Corroventa Avfuktning AB 2023.04 12 (31)

  • Page 14: The Control Panel's Menus And Functions

    The control panel’s menus and functions IA2 ES F is fitted with a control panel that has a display and five push buttons. For easy navigation, the user interface is implemented in such a way that the two upper, larger buttons are used for navigation between menus, while the three smaller buttons below the display are used for selecting and editing within each given menu.
  • Page 15 E.RF, E.X or E.DP appears shown against a INT – in this mode. black background. Intermittent fan operation, 5 minutes every hour. Read important information in the following chapter. © Corroventa Avfuktning AB 2023.04 14 (31)
  • Page 16 Start view Normal start When IA2 ES F starts up, two options are presented to the user on the display: Start: Starts the machine with standard settings, continuous operation with maximum capacity. Any adjusted operating point, as well as all other settings including control mode etc., are deleted and the...
  • Page 17 The external control mode requires that the machine is network connected and connected to an external temp. and RH sensor. If the machine is not already connected to the network, the machine asks whether to create a network. © Corroventa Avfuktning AB 2023.04 16 (31)
  • Page 18 Setup and Maintenance menus. ALARMS At the bottom of this menu, it is possible to activate an alarm, which is presented on the display in the event the humidity should reach an excessively high level. © Corroventa Avfuktning AB 2023.04 17 (31)
  • Page 19 60 minutes. If such a delay is not acceptable in the operating case in question when the humidity is rising, continuous fan operation or the use of an external temperature and RH sensor is recommended instead. © Corroventa Avfuktning AB 2023.04 18 (31)
  • Page 20 Capacity mode The drying capacity of IA2 ES F can be optimised for a given work task and situation with two different operating modes, Max and DX1. In the case of Max, the machine is fully operational with the maximum possible dehumidification capacity. In...
  • Page 21 Network Note! Install all system cables before the machines are started. IA2 ES F has network functions that make it possible for the machine to be monitored and controlled remotely via Digital Gateway or SuperVision® 2.0. A network is established by installing the machines in the intended way and connecting them to each other using system cables before they are started.
  • Page 22 Press Reset to reset the work counter. Confirm resetting of the counter by pressing OK on the following screen. The operating hours for the entire service life of the machine are displayed at the bottom. This counter cannot be reset. © Corroventa Avfuktning AB 2023.04 21 (31)
  • Page 23 The user does not have to erase the alarms that are shown. As soon as the machine detects that the function has been reset, the alarm disappears automatically. © Corroventa Avfuktning AB 2023.04 22 (31)

  • Page 24: Control Mode And Hysteresis

    Control mode and hysteresis In addition to the normal, continuous drying operation, the operation of IA2 ES F can also be controlled via its built-in sensor for relative humidity and temperature as well as via its external hygrostat or external, networked sensor.

  • Page 25: Alarms

    The filters are clean The air flows are not blocked That the air flow from the fans is normal. If no reason is discovered, consult a service technician before starting to use the machine again. © Corroventa Avfuktning AB 2023.04 24 (31)

  • Page 26: Connection Of Supervision® 2.0/Digital Gateway

    When servicing has been carried out, the service counter is reset with the function that is accessed in Setup and the Maintenance menu. © Corroventa Avfuktning AB 2023.04...

  • Page 27: Maintenance And Service

    The machine is designed in such a way that a breakdown of the rotor motor or fan(s) will not endanger safety, which is why the preventive replacement of this hardware is not necessary. © Corroventa Avfuktning AB 2023.04 26 (31)

  • Page 28: Filter Replacement

    Clean the outside of the machine with a damp cloth. Inside the machine, use a vacuum cleaner with a brush to remove dust and particles. Vacuum clean the rotor from both sides with a brush nozzle, taking care to ensure the surface of the rotor is not damaged. © Corroventa Avfuktning AB 2023.04 27 (31)

  • Page 29: Accessories And Consumables

    Accessories and consumables The following parts are available as accessories and consumables for IA2 ES F: Article number Name 6000902 Filter, process air 1003187 Filter, regeneration air 1002749 System cable, 0.5 m 1002748 System cable, 5 m 1002816 Adapter cable, hygrostat 1002817 External temp.

  • Page 30: Fault Tracing

    (MAN), the operation, MAN (for manual operating continuous fan functions mode) should be indicated. Check the are switched off and the setpoint value if another operating mode is surrounding humidity is so being used. © Corroventa Avfuktning AB 2023.04 29 (31)
  • Page 31 Contact a service technician. to be shut off, even overheat protection by the though the switch is heat cover or the thermal turned on. fuse by the wet air cover may have tripped. © Corroventa Avfuktning AB 2023.04 30 (31)

  • Page 32: Technical Data

    Technical data IA2 ES F Capacity 20°C, 60% RH 16.8 ΔX mode, at 110/50*, g/kg Nominal dry air flow, m³/h Available static pressure, Dry air flow, Pa Maximum dry air flow, m³/h Nominal wet air flow, m³/h Available static pressure, Wet air flow, Pa Maximum wet air flow, m³/h...
  • Page 33 DO YOU HAVE QUESTIONS OR NEED HELP? Visit www.corroventa.com or call us at +44 (0)161-244 95 23 to speak with an expert. We have the knowledge and the equipment to find a solution as efficiently as possible. Corroventa develops, manufactures, sells and rents high quality products for dealing with water damage, moisture, odours and radon.
