- Page 1 TECHNICAL DESCRIPTION CTR 500TT DEHUMIDIFIERS FOR CRAWLSPACES Technology and products for remediation of radon, moisture and odours Installed by Address: Contact person: Tel. no.: Developed and manufactured by Corroventa Avfuktning AB...
- Page 2 Technical description of CTR 500TT dehumidifier for crawl spaces page 1 How are different materials affected by moisture? How can one effectively eliminate mould and odours in a house with a crawl space? Description of dehumidifier CTR 500TT a) Function...
- Page 3 1. HOW ARE DIFFERENT MATERIALS AFFECTED BY MOISTURE? All air contains a greater or lesser degree of moisture. We can’t see it with the naked eye before it appears in the form of small water drops against a cold surface of metal or glass. But before moisture is visible, it is already causing problems by affecting materials and manufacturing processes, causing corrosion and growth of micro-organisms.
- Page 4 One gram of silica gel has a moisture absorbent surface of 500 - 700 m A CTR 500TT dehumidifier contains desiccant with a total drying aera of approx. 600,000 m The dehumidifier is used to dry atmospheric air using the adsorption principle.
- Page 5 It is therefore especially strongly-constructed both externally and internally, see the front page. CTR 500TT is manufactured from strong sheet steel and is powder coated both internally and externally. It comes with a practical carrying handle. The front of the dehumidifier consists of:...
- Page 6 c) Construction internal Electrical equipment is located in an internal distribution box and the rotor unit is attached to this by a quick release connector. The rotor unit contains the rotor (6), drive motor (7), drive belt (8), heating element (15) and covers (12,13), that is to say all internal components close to the fan (3).
- Page 7 To ensure the function of the fan, manual checks should be made at the dehumidifier or wet The ventilation must always function. pipe outlet. If it stops operating, a warning lamp comes on. 4. TECHNICAL DATA FOR DEHUMIDIFIER CTR 500TT Dry air volume 500 m Wet air volume 60-80 m Height x width x length...
-
Page 8: Installation
- distribution of the correct air volumes - the hygrostat’s position and connection. This is described more in the next section. a) Location of CTR 500TT The dehumidifier must be placed in the crawl space so that the following requirements and... -
Page 9: Operation And Care
To bear in mind The wet air hose must not be replaced with one with smaller dimensions. If Moisture this occurs, the installation's function is affected and the dehumidi- fier can overheat. c) Connection of control panel, (hygrostat section) The hygrostat is placed in the crawl space where the conditions are considered suitable or particularly critical. - Page 10 b) Maintenance, service The filter must be checked and replaced regularly, at least once a year. If the air filter is extremely dirty it must be replaced more often. Open the filter door and replace the filter with a new one.
-
Page 11: Installation Order
7. INSTALLING CONTROL PANEL CONTROL PANEL CONSISTS OF: - indicator box located in main entrance, cloakroom or similar. - hygrostat section with connection box is placed in the crawl space. INSTALLATION ORDER: NOTE! Ensure that the dehumidifier is unpowered! 1. Remove the cover of the indicator box. 2. - Page 12 Technology and products for remediation of radon, moisture and odours CORROVENTA AVFUKTNING AB | Mekanikervägen 3 | SE-564 35 Bankeryd Tel +46 (0)36-37 12 00 | mail@corroventa.se | www.corroventa.se...
