EasyPro ELN75 Instructions For Use

Thank you for purchasing an EasyPro Arching Stream Fountain, a color-changing LED light
stream that adds beauty, fun and enjoyment to any water feature, pond, fountain or pool. These instructions cover the ELN75
(Arching Stream Fountain unit with LED light) and ELN75K (Arching Stream Fountain unit with LED light, pump and plumbing).
Specific ELN75K kit assembly instructions are on page three.
Specifications
• Inlet: 1" O.D. barb
• Nozzle opening: / "
3
8
• Electrical Requirement — LED operates on AC/DC 12 volt power adaptor with inline LED Controller
(Remote control operation of controller)
• LED Light — 3 watt (max) RGB
• Adjustable mounting bracket for desired angle and secure placement options (Use
• 16' cable to LED controller; (3' to epoxy filled inline junction box)
• Ideal installation: 6' to 10' spray distance with 5' to 6' maximum arch height.
Note: Further distance and higher arch can be achieved if installed indoors with no wind. Avoid using
in windy locations.
General Information and Operation
Please read the following before installing or running the Arching Stream Fountain.
1. The Arching Stream Fountain must be used in a clean water environment. If the water is dirty a pre-
filter is required. Running dirty water through the fountain will result in improper flow and disrupted
stream.
2. Flow rates between 600-1000 gph are recommended. The flow consistency of mag drive pumps best suit the functionality of
the Arching Stream Fountain. Avoid pumps with inconsistent flow.
3. The nozzle of the Arching Stream Fountain should never be submersed. The fountain can be submersed into the water as
long as the nozzle remains above water.
4. A flow control valve is recommended to adjust water flow and size of the arch. Install ball valve in-line between the pump
and fountain. If the arch is too long it will result in a disrupted stream and may cause splashing. Windy locations may limit
the distance that an uninterrupted stream is able to travel. Ideal applications will be able to maintain the arch to a maximum
length of 12'.
NOTE: You may need to adjust the length of the arch to be sure the light can travel from start to end. If arch is too long the
light may not reach the end and the stream flow could get distorted.
5. Periodic maintenance is required for proper flow of water and light. Please see maintenance instructions to clean the LED light
lens and filter sponges inside the fountain.
6. Transformer is not submersible. Turn the LED light on only when water is running.
NOTE: If the fountain is not properly filled with water it will cause the stream to distort and splatter. To fix this simply tilt the
nozzle 15-20 degrees forward and return it back to desired angle. If noise is coming out of the unit do the same. At times you
may have to tilt the nozzle 15 degrees in the opposite direction then back to normal to purge air from the unit.
ELN75
Arching Stream Fountain
Instructions for Use • Maintenance Guide
EasyPro Pond Products, Grant, MI • www.easypro.com
/ " socket)
1
2
1
LED Cord
Components
Adjustable Mounting
Bracket
