Beko DCY 7402 Service Handbook

Bx platform (b7s / bled) condanser dryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BX CNDU
Tumble Dryer
SERVICE HANDBOOK NO:
REV. 01
BX PLATFORM (B7S / BLED)
CONDANSER DRYER
SERVICE HANDBOOK
Sensitivity: Confidential

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCY 7402 and is the answer not in the manual?

Questions and answers

Related Manuals for Beko DCY 7402

Summary of Contents for Beko DCY 7402

  • Page 1 BX CNDU Tumble Dryer SERVICE HANDBOOK NO: REV. 01 BX PLATFORM (B7S / BLED) CONDANSER DRYER SERVICE HANDBOOK Sensitivity: Confidential...

  • Page 2: Table Of Contents

    BX CNDU Tumble Dryer 2. Table of Contents TABLE OF CONTENTS ..................2 TECHNICAL SPECIFICATION: ................3 GENERAL WORKING PRINCIPLE ..............7 ELECTRONIC COMPONENTS ................ 15 SERVICE TEST PROGRAM BLED ..............16 SERVICE TEST PROGRAM B7S ..............19 SERVICE TEST PROGRAM BLED (ECOSENSE) ........... 24 SERVICE TEST PROGRAM B7S (ECOSENSE) ..........

  • Page 3: Technical Specification

    3. Technical Specification: 3.1. Product Definition: : Arçelik A.Ş. 3.1.1. Manufacturer Çerkezköy - Tekirdağ / TÜRKİYE 3.1.2. Model : Beko DCY (7/8/9)402 3.1.3. Capacity (kg) : 7/8/9 3.1.4. Programs (Qty) : 14 sensor-controlled programs 1 timed program 1 ventilation program (compressor off) 3.2.
  • Page 4 BX CNDU Tumble Dryer 3.6. Electrical Specification: 3.6.1. Voltage (V / Hz) : 230-240 / 50 3.6.2. Power (W) : 800 / 900 3.6.3. Current (A) 3.7. Power Cord: 3.7.1. Type : 3 x 1.5 mm or 3x1.0mm cord copper wire 3.7.2.
  • Page 5 BX CNDU Tumble Dryer 3.11.3. Flow Rate (l / min) : 2,4 3.11.4. Head (m) : 0,8 3.11.5. Revolution Speed (rpm) : 3000 : 1480 ±10% 3.11.6. Winding Resistance (ohm) 3.12. Pump: B13-5AE12110 Manufacturer / Type : Hanyu / Synchronous 3.12.1.
  • Page 6 BX CNDU Tumble Dryer NOTE: If the heater does not work because of manuel resetting thermostat is open circuit, do not change heater with the new one. You should do the following operation that described below. With the multimeter manual resetting thermostat is checked from the terminals while heater is on the dryer.

  • Page 7: General Working Principle

    BX CNDU Tumble Dryer 4. General Working Principle Figure 4.1. Tumble Dryer Product Specifications November’ 19 Sensitivity: Confidential...
  • Page 8 BX CNDU Tumble Dryer 4.1. Condanser Dryer Working Principles: • Firstly, the process air is sucting from ambient it goes to the electrical heater • The process air is heated in the electrical heater and directed into the drum • The hot and the dry air goes through the drum, it interacts with laundries and takes out the humidity from them.
  • Page 9 BX CNDU Tumble Dryer CND Ecosense Working Principles: In all sensor dryer we use a humidity plate(two metal strip) on front-bearing. When wet or dry clothes touch this plate, we can read a resistance by electronic card. And thus, we can understand the dryness level of clothes. When this level reaches to the limit(already determined) heater are off and cooling period occurs.
  • Page 10 BX CNDU Tumble Dryer 1-Process air fan 2-Heater 3-Drum 4-Filter 5-Condanser 6-Cooling fan 7-Humudity plate 8-Condanser inlet NTC 9-Condanser outlet NTC November’ 19 Sensitivity: Confidential...
  • Page 11 BX CNDU Tumble Dryer 4.2. Components Related to the Drying Cycle: 4.2.1. Heater: Two circuit open spiral wire type heater is driven by the 2 relays. A manual resettable thermostat is used on these heater, in order to provide IEC safety rules accordingly. This manual resettable thermostat cut the heater power at prescribed temperature and can be resetted by pressing the button on thermostat, so heater can be used after a failure bacause of thermostat is open circuit.
  • Page 12 BX CNDU Tumble Dryer Figure 4.3. NTC located after the door filter in air suction channel 4.2.3. Humidity Sensor : Humidity level will be measured by the resistance of clothes. With this property of the humidity sensor, it is possible to check and control the humidity level precisely. It is driven by microcontroller.
  • Page 13 BX CNDU Tumble Dryer Figure 4.5. Door Lock 4.2.5. Door Microswitch: The current is sent to electronic card and motor by the door switch. By this way when door is opened due to any reason, motor stops automatically. However, because of EN&IEC safety rules, when the door is closed again, motor does not start.
  • Page 14 BX CNDU Tumble Dryer In the condanser models with energy class B and the Silent machines, the drum and fan are driven by brushless direct current (BLDC) motor. This motor communicates with the electronic board by the aid of the motor communication port. Figure 4.7.

  • Page 15: Electronic Components

    BX CNDU Tumble Dryer 5. Electronic Components 5.1. Electronic Card Assembly: Figure 9.1. Electronic Card Assembly Electronic Card (Mono Models) BX Tumble dryers have electronic card assembly which shown above Picture. Firstly, Electronic card is mounting the card holder, then card holder cover is attached to the electronic card assembly.

  • Page 16: Service Test Program Bled

    BX CNDU Tumble Dryer 6. Service Test Program BLED Step 1: Press “Ending In(1)” and “Start/Pause(2)” button, then turn the “On/Off Program Selection Knob(3)” 90 degrees in a clockwise direction within 2 seconds. This combination will start service test program and all LEDs blink. In this program “Start/Pause” button is used to pass other steps.
  • Page 17 BX CNDU Tumble Dryer Step 5: “Start/Pause” button is pressed. The motor continues to rotate in clockwise direction. “Clean Filter Led” starts to blink for humidity sensor short circuit control. Open the door of the tumble dryer and make the sensor short circuit by touching the sensor plate. If short circuit control of the humidity sensor is OK, “Clean Filter Led”...
  • Page 18 BX CNDU Tumble Dryer Step 8: “Start/Pause” button is pressed. All components stop. After 3 seconds, “Sound Warning Led” starts to blink and it is allowed to pass to the next step. Step 9: “Start/Pause” button is pressed. “End Led” lights on. Motor starts to rotate in a counter- clockwise direction.

  • Page 19: Service Test Program B7S

    BX CNDU Tumble Dryer 7. Service Test Program B7S Step 1: Press “Dryness Level(1)” and “Start/Pause(2)” button, then turn the “On/Off Program Selection Knob(3)” 90 degrees in a clockwise direction within 2 seconds. This combination will start service test program. In this program “Start/Pause” button is used to pass other steps.
  • Page 20 BX CNDU Tumble Dryer Step 6: “Start/Pause” button is pressed. All LEDs light on and service test program waits for another “Start/Pause” press. Step 7: “Start/Pause” button is pressed. The last error codes are shown on display. In this section, this error codes could be deleted by service technician with “On/Off Program Selection Knob”.
  • Page 21 BX CNDU Tumble Dryer Step 9: “Start/Pause” button is pressed. “Drr” appears on display. The motor rotates in clockwise direction. After 3 seconds, “Sound Warning Led” starts to blink and it is allowed to pass to the next step. Step 10: “Start/Pause” button is pressed. The motor continues to rotate in clockwise direction. “Clean Filter Led”...
  • Page 22 BX CNDU Tumble Dryer Step 13: “Start/Pause” button is pressed. All components stop. “StP” appears on display. After 3 seconds, “Sound Warning Led” starts to blink and it is allowed to pass to the next step. Step 14: “Start/Pause” button is pressed. “rLL” appears on display. Motor starts to rotate in a counter-clockwise direction.
  • Page 23 BX CNDU Tumble Dryer model is tank-up and “Tank Full Led” blinks, the overflow micro switch and cables have to be checked. Step 17: “Start/Pause” button is pressed. The last error codes are shown on display. In this step, error codes cannot be deleted. It is allowed to finish the service test program.

  • Page 24: Service Test Program Bled (Ecosense)

    BX CNDU Tumble Dryer 8. Service Test Program BLED (Ecosense) Step 1: Press “Ending In(1)” and “Start/Pause(2)” button, then turn the “On/Off Program Selection Knob(3)” 90 degrees in a clockwise direction within 2 seconds. This combination will start service test program and all LEDs blink. In this program “Start/Pause” button is used to pass other steps.
  • Page 25 BX CNDU Tumble Dryer Step 4: “Start/Pause” button is pressed. “Drying Led” lights on. The motor rotates in clockwise direction. After 3 seconds, “Sound Warning Led” starts to blink and it is allowed to pass to the next step. Step 5: “Start/Pause” button is pressed, “Iron Drying Led” lights on. The motor continues to rotate in clockwise direction and the heater of 1600W power starts to work.
  • Page 26 BX CNDU Tumble Dryer Full Led” blinks. If it is connected, “Sound Warning Led” blinks and it is allowed to finish the service test program. Step 9: “Start/Pause” button is pressed. The service test program will be exited. November’ 19 Sensitivity: Confidential...

  • Page 27: Service Test Program B7S (Ecosense)

    BX CNDU Tumble Dryer 9. Service Test Program B7S (Ecosense) Step 1: Press “Dryness Level(1)” and “Start/Pause(2)” button, then turn the “On/Off Program Selection Knob(3)” 90 degrees in a clockwise direction within 2 seconds. This combination will start service test program. In this program “Start/Pause” button is used to pass other steps.
  • Page 28 BX CNDU Tumble Dryer Step 6: “Start/Pause” button is pressed. All LEDs light on and service test program waits for another “Start/Pause” press. Step 7: “Start/Pause” button is pressed. The last error codes are shown on display. In this section, this error codes could be deleted by service technician with “On/Off Program Selection Knob”.
  • Page 29 BX CNDU Tumble Dryer If NTC and voltage error occurs, it is not allowed to pass to the next step. Step 9: “Start/Pause” button is pressed. “Drr” appears on display. The motor rotates in clockwise direction. After 3 seconds, “Sound Warning Led” starts to blink and it is allowed to pass to the next step.
  • Page 30 BX CNDU Tumble Dryer Step 12: “Start/Pause” button is pressed. All components stop. “StP” appears on display. After 3 seconds, “Sound Warning Led” starts to blink and it is allowed to pass to the next step. Step 13: “Start/Pause” button is pressed. “POn” appears on display. If the model is tank-up, the pump activates.
  • Page 31 BX CNDU Tumble Dryer Error Codes: Error Codes Definition E 00: No error E 01: Door Opened While Running E 02: Tank Full E 03: Drum Empty E 04: Start While Door Open E 05: Maximum Time E 06: Door NTC: Open Circuit E 07: Door NTC: Short Circuit E 08: Door NTC: Overheat E 09: Heater NTC: Open Circuit...

  • Page 32: Faults Algorithms

    BX CNDU Tumble Dryer 10. Faults Algorithms 10.1. Machine Does Not Work: November’ 19 Sensitivity: Confidential...
  • Page 33 BX CNDU Tumble Dryer 10.2. Drum is not rotating: November’ 19 Sensitivity: Confidential...
  • Page 34 BX CNDU Tumble Dryer 10.3. Program does not progress although the tank is empty: November’ 19 Sensitivity: Confidential...

  • Page 35: Dismounting Details

    BX CNDU Tumble Dryer 11. Dismounting Details Figure 11.1. General View 11.1. Top Plate: Figure 11.2. Disassembling the top plate • Unscrew the top plate. • Pull the top plate towards the rear of the machine. November’ 19...
  • Page 36 BX CNDU Tumble Dryer 11.2. Side Panel: 11.2.1. Side Panel / Side Support Bracket: Figure 11.3. Screws between the side panel and side support bracket (Water Tank Side) • Remove the screws between the side panel and side support bracket. Figure 11.4.
  • Page 37 BX CNDU Tumble Dryer 11.2.2. Side Panel / Rear Panel: Figure 11.5. Connections between the side panel and the rear panel at the back side of the dryer • Remove the screws as highlighted in the figure between the side panel and the rear panel. 11.2.3.
  • Page 38 BX CNDU Tumble Dryer • Remove the 1 piece of the screw on each bottom side of the dryer as highlighted in the figure. • Disassemble the side panels from the geometric mounting points through the direction as shown in the figure. 11.2.4.
  • Page 39 BX CNDU Tumble Dryer 11.4. Control Panel Assembly: Figure 11.10. Connection points between Control Panel and Tank Housing Figure 11.9. Connection points between Front Panel Assembly and Support Sheet of Front Panel • Remove the 2 pieces of sheet screws between the front panel and support sheet of the front panel.
  • Page 40 BX CNDU Tumble Dryer Figure 11.12. Connection points for Support Sheet Brackets on Left Hand Side (LHS) • Remove the screws on the connection points of support sheet brackets on left and the right-hand sides of the dryer. 11.6. Rear Panel Assembly Figure 11.13.
  • Page 41 BX CNDU Tumble Dryer • Disassemble the washer and the circlip shown in the figure by the aid of a screwdriver. Figure 11.14. Sub-parts on the Rear Panel Assembly • After removing the PT screws, washer and circlip, dismount the rear panel from the assembly by removing the hoses from the water hose holders located on the rear panel as shown in the figure.
  • Page 42 BX CNDU Tumble Dryer 11.7. Drum Assembly: ➢ To disassemble the drum assembly: • Lift up the drum on the highlighted direction. • Pull towards the drum to the backside and remove from the dryer body. • By this movement, any interaction between the drum and the plastic chassis is prevented.
  • Page 43 BX CNDU Tumble Dryer 11.9. Water Tank Housing: Figure 11.18. Water Tank Housing • Disassemble the water tank housing due to the details mentioned above figure. • Water tank housing consists of hose holders, tank housing safety part and the tank housing cover.
  • Page 44 BX CNDU Tumble Dryer 11.11. Kickplates: Figure 11.20. Disassembling the kickplate 11.12. Front Panel: Figure 11.21. Disassembling the front panel November’ 19...
  • Page 45 BX CNDU Tumble Dryer • After disassembling the kickplates, front panel can be dismounted from the dryer by removing the screws shown in the figure above. 11.13. Drum Front Bearing Unit: Figure 11.22. Connections of drum front bearing housing • Disassemble the front bearing housing from the mounting points shown in the figure above. 11.14.

  • Page 46: Service Details For The Components

    BX CNDU Tumble Dryer 12. Service Details for the Components: 12.1. Service Details of the Motor Unit: • Remove the top plate. • Remove the heater cover (2). • Remove the side panel on RHS (3). ➢ Force the motor assembly to turn it on clockwise direction to loosen V-belt (5). ➢...
  • Page 47 BX CNDU Tumble Dryer ➢ Take out the process fan dismounting the mounted nut (8). ➢ Dismount the capacitor from the support sheet parts which is located on plastic chassis Read the Service Information form with 2012-K13 code before applying that operation.
  • Page 48 BX CNDU Tumble Dryer • Disassemble hoses (10). • Drum assembly lifted up direction and pull back slightly (11). • To re-assemble the drum assy. to the dryer properly, the above pictures should be considered. 12.3. Service Details of Door NTC: •...
  • Page 49 BX CNDU Tumble Dryer 12.4. Service Details of Heater: Listed details below should be applied while assembling the heater to the dryer body. ➢ Heater cover must be changed after every service operation ➢ Heater assembly is mounted to the dryer body with 2 type of connection by listed order •...
  • Page 50 BX CNDU Tumble Dryer 12.5. Service Details of Pump and Microswitch: • Remove the highlighted screw. • Open the cover with pushing snap-fit. • Remove the highlighted hose. • It is possible to apply service on microswitch parts on this level. •...
  • Page 51 BX CNDU Tumble Dryer 12.7. Service Details of Door Lock System: • Remove the top plate. • Remove side panel on LHS. • Disassemble the plastic housing as shown on the pictures. • Take out the locking assembly working on inner side as highlighted on the picture. November’...
