3.5 Battery charging

In order to recharge batteries, use only the provided charger or one recommended by the
manufacturer. The manufacturer is not responsible for any damage to person or objects
resulting from the use of non-original product.
•
Connect the power cord to a power supply 230 V.
• Connect the cable to the joystick as shown in Figure.
• When batteries are loaded unplug the power cord and the battery cable from the joystick.
CHARGER SPECIFICATION
24 V -MIN 6 A MAX 10 A - Charge profile for AGM batteries - Input 100-240
V AC 50-60 Hz - IEC 60601-1 compliant
Figure 19
Typically, batteries are able to offer 100% performance after about 15-20
cycles.
BATTERIES SPECIFICATION
24 V - 86 Ah - about 260x170x205 (h) mm - about 24 kg
www.neatech.it
23/39
RUNNING-IN PERIOD
