2.6 Footplates height

• Unscrew the screw shown in figure with the allen
wrench while holding the nut behind with the open-
end wrench.
• Repeat the operation for both left and right side of
the wheelchair.
• Set the position of the footplate according to
desired height.
• Screw again the screws.
It is possible to adjust separately left and right legrest if you have splitted
footrest.
Average needed
time:
<5 min
Figure 12
www.neatech.it
11/39
RIGHT AND LEFT SIDE
ALLEN WRENCH
OPEN-END WRENCH
Difficulty level:
Easy
6 mm
13 mm
