Induced combustion gas furnace upflow and downflow/horizontal

Advertisement

Quick Links

®
WARNING: If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal in-
jury or loss of life.
— Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
This document was created with FrameMaker 4.0.4
®
®
Model 330AAV
Upflow and
331AAV Downflow/
Horizontal
USER'S
INFORMATION
MANUAL FOR
THE
OPERATION
AND
MAINTENANCE
OF YOUR NEW
GAS-FIRED
FURNACE
NOTE TO
INSTALLER:
This manual
must be
left with the
equipment user.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Payne Plus 80 330AAV and is the answer not in the manual?

Questions and answers

Summary of Contents for Bryant Payne Plus 80 330AAV

  • Page 1 ® ® ® Model 330AAV Upflow and WARNING: If the information in this manual 331AAV Downflow/ is not followed exactly, a fire or explosion may result causing property damage, personal in- Horizontal jury or loss of life. — Do not store or use gasoline or other flam- mable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2: Welcome To Today'sgeneration Of Comfort

    WELCOME TO TODAY’S GENERATION OF COMFORT Congratulations! Your new, high efficiency gas furnace is a sound investment which will reward you and your family with years of warm memories winter after winter. Not only is your new furnace energy ef- ficient, it is also extremely reliable and supplies superior home comfort.
  • Page 3: Important Facts

    DOWNFLOW/HORIZONTAL FURNACE COMPONENTS Manual Reset Auxiliary Limit Switch Blower and Blower Motor Relief Box Rating Plate Gas Valve Control Knob (On/Off) 2-Stage Gas Valve Gas Burner Blower Door Safety Switch Draft Safeguard Tube and Switch Gas Manifold Hot Surface Ignitor Flame Sensor Manual Reset Flame Rollout Switch (2) Status LED Light...
  • Page 4: Steps For Starting Your Furnace

    Understand the signal words DAN- dures on the furnace or see “Shutting GER, WARNING, and CAUTION. Down your Furnace” section in this These words are used with the safety- manual, then call your dealer as soon alert symbol. DANGER identifies the as possible.
  • Page 5: Shutting Down Your Furnace

    11. After 15 to 70 sec, the gas valve continuously except for a 77-sec delay permits gas to flow to the main at the “call for heat.’’ This keeps the burners where it is ignited. Hot temperature level in your home more flames begin to warm the fur- evenly balanced.
  • Page 6: Performing Routine Maintenance

    CAUTION Never operate your furnace without a filter in place. Doing so may damage the furnace blower motor. An accumula- tion of dust and lint on internal parts of your furnace can cause a loss of efficiency. The air filter for upflow furnaces is normally located in the blower com- partment.
  • Page 7: Combustion Area And Vent System

    3. Remove the left-side filter by tip- can mean a loss of efficiency and bright blue? If not or if you sus- ping the filter toward the center improper performance. Buildups on pect some other malfunction, call and raising it from the V-shaped the main burners can cause faulty fir- your servicing dealer.
  • Page 8: Regular Dealer Maintenance

    • Check the manual reset flame roll- knowledgeable preparation for the ser- 6. Inspection of all supply- and out switch(es) located near the burn- vice call. return-air ducts for obstructions, ers. If the furnace has experienced a air leaks, and insulation. Any high-temperature condition due to problems found should be REGULAR DEALER...
