2
B
Using the radio remote power controller PTVTEL:
•
Within 10 seconds press the "+" and "-" buttons to select a channel [1-12] chosen for
pairing. Example channel «1» Fig.7
•
Immediately afterwards press the
•
The Blue LED on the heater goes out to confirm that the pairing operation is complete
and the heater turns on to maximum power (Green LED). Fig.9
N.B. If programming does not work, repeat programming
Fig.7
3
1 REMOTE CAN PAIR WITH UP TO 12 HEATERS
TO PAIR ANOTHER HEATER, ALWAYS CARRY OUT OPERATION WITH ONLY
ONE HEATER CONNECTED TO MAINS VOLTAGE / SWITCHED ON.
Once next / new heater is switched on, pick up the radio remote power controller PTVTEL:
•
Repeat the operations of the previous sections 2A and 2B by selecting the channel of
your choice [1-12].
•
If preferred, all heaters can be assigned to the same channel.
•
In multi-heater set ups, it is also possible to form groups of heaters on one channel to
creating "heating zones".
•
If you accidentally leave another heater switched on when pairing, you may find that you
will pair it to the same channel.
1 HEATER CAN BE CONTROLLED BY A MAXIMUM OF 4 REMOTES, OR 3
REMOTES AND A PIR PROXIMITY SENSOR.
button as shown in Fig. 8.
instructions again
Fig.8
5
Fig.9
CHANNEL13
