Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-09CR13 HSU-12CR13 HSU-14CR13 Please read this operation manual before using the air conditioner No.0010562469... -
Page 2: Safety Instructions And Warnings
Before starting the air conditioner, read the Before disposing an old air conditioner that information given in the User's Guide caref- goes out of use, please make sure it's inop- ully. The User's Guide contains very impor- erative and safe. Unplug the air conditioner tant observations relating to the assembly, in order to avoid the risk of child entrapment. -
Page 3: Specifications
3. If the fuse of indoor unit on PC board is broken,please change it with the type of T. 3.15A/ 250V. If the fuse of outdoor unit is broken,change it with the type of T.25A/250V... -
Page 4: Safety Instruction
Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place. CAUTION Do not install in the... - Page 5 PROHIBITION PROHIBITION CAUTION Take fresh air occasionally especially Do not operate the switch with Do not use for the purpose of storage of food, art work, precise equipment, when gas appliance is running at the wet hand. breeding, or cultivation.
-
Page 6: Parts And Functions
Bacteria-killing medium sets Inlet grille (inside) display board(inside) Vertical flap Anion generator (inside) (adjust up and down air flow. Don't adjust it manually) Horizontal louver(inside) (adjust left and right air flow) Power plug Outdoor unit OUTLET CONNECTING PIPING AND ELECTRICAL WIRING... -
Page 7: Parts And Functions
Used to set clock and timer setting. 34. Emergency operation button(touch key) 9. Purify button Used to set emergency operation and test operation. Used to set air ionization purify and healthy function. NOTE: 1.Cooling only unit do not have functions and displays related with heating. -
Page 8: Clock Set
If the remote controller can't run normally during operation, please remove the batteries and reload several minutes later. Hint: Remove the batteries in case unit won't be in usage for a long period. If there are any display after taking-out, just need to press reset key. -
Page 9: Operation
1.The anion generator in the air conditioner can generate a lot of anion effectively balance the quantity of position and anion in the air and also to kill bacteria and speed up the dust sediment in the room and finally clean the air in the room. -
Page 10: Auto Operation
1 C,if kept depressed, it will decrease rapidly Select a desired temperature. 4.Fan speed selection Press FAN button. For each press, fan speed changes as follows: Remote controller: AUTO Air conditioner is running under displayed fan speed. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. -
Page 11: Cool Operation
1 C,if kept depressed, it will decrease rapidly Select a desired temperature. 4.Fan speed selection Press FAN button. For each press, fan speed changes as follows: Remote controller: AUTO Air conditioner is running under displayed fan speed. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. -
Page 12: Dry Operation
1 C,if kept depressed, it will decrease rapidly Select a desired temperature. 4.Fan speed selection Press FAN button. For each press, fan speed changes as follows: Remote controller: AUTO Air conditioner is running under displayed fan speed. COOL operation starts when room Ultra-low air flow temp.is higher than temp.setting. -
Page 13: Fan Operation
Remote controller: AUTO COOL Then Select FAN operation 3.Fan speed selection Press FAN button. For each press, fan speed changes as follows: Remote controller: 4.Unit stop Press ON/OFF button, the unit stops. About FAN operation In FAN operation mode, the unit will not operate in COOL mode but only in FAN mode ,AUTO is not available in FAN mode.And temp.setting is disabled. -
Page 14: Air Flow Direction Adjustment
: remote controller: Pos.1 Pos.2 Pos.3 Pos.4 Pos.5 Pos.6 Pos.7 Pos.8 The horizontal louvers will swing according to the above positions. Note:When restart after remote turning off, the remote controller will automatically memorize the previous set swing position. -
Page 15: Sleep Operation
C higher than temp. setting. After Rises 1 another 1 hours, temp. rises by 1 C further. 1 hr The unit will run for further 6 hours then stops. Unit stop Temp.setting Temp. is higher than temp. setting so that room In COOL, DRY mode temperature won't be too Iow for your sleep. -
Page 16: Timer On/Off Operation
After replacing batteries or a power failure happens, time setting should be reset. Remote controller possesses memory function, when use TIMER mode next time, just press SET button after mode selecting if time setting is the same as previous one. - Page 17 " on the remote controller stops flashing. " " starts flashing. Time displayed: Unit starts or stops at x hour x min. 5.Time setting for TIMER OFF Just press HOUR button ,follow the same procedure in "Time setting for TIMER ON"...
- Page 18 15 min then returns to original status setting. To cancel POWER operation Press POWER/SOFT button twice ,POWER/SOFT disappears. SOFT Operation You can use this function when silence is needed for rest or reading. Selecting of SOFT operation Press POWER/SOFT button. Every time the button is pressed,...
-
Page 19: Health Airflow Operation
2).Press the button of health airflow again, appears on the display. The above inlet and outlet grills of the air cond- itioner are closed and the airflow is blown vertically from the nether inlet and outlet grills. Avoid the strong airflow blows direct to the body. -
Page 20: Emergency And Test Operation
Removal of the restriction of emergency or test operation Press the emergency operation switch once more, or manipulate through the remote controller; the "Pi" sound, the emergency or test operation is terminated. When the remote controller is manipulated, it gets the system back to the normal operation mode. -
Page 21: Maintenance
Use the timer effectively during operation During cooling operation prevent the penetration of direct sunlight with curtain or blind If the unit is not to be used Use the louvers effectively for a long time, turn off the power supply main switch. -
Page 22: Air Filter Cleaning
Maintenance For Smart Use of The Air Conditioner WARNING Before maintenance,be sure to turn off the system and the circuit breaker. Remote Controller Indoor Body Wipe the air conditioner by using a soft and Do not use water, wipe the controller with a dry cloth.For serious stains,use a neutral... -
Page 23: Aip/Vc Layer + Bacteria-Killing Medium Sets
The AIP layer will be replaced in fixed time. In normal family, it will be replaced every 6 months. In the use, please note to clean the filter frequently (take off the back suction cleaner or lightly pat it) to avoid the operating effect is lowered due to the dust covering the filter. AIP layer and bacteria-killing medium filter is strictly prohibited from being cleaned by water. - Page 24 To Keep Your Air conditioner in Good Condition after Season. 1. Operate in cooling mode for 2-3 hours. To prevent breeding mold or bad smell, be sure to operate at the designated temperature or 30 C,cooling mode and High speed fan mode for 2-3 hours.
- Page 25 Before Setting in High season 1. Cleaning the standard air filter. Operation without filter may cause troubles.Be sure to attach both right and left filters prior to the operation. Each of them are of different shapes. 2. Connecting the earthing cable.
-
Page 26: Troubleshooting
This noise is generated by the inspection casing expanding or shrinking because of temperature changes. Should there be a big noise from air flow in unit operation, air filter may be too dirty. This is because the system circulates smells Smells are generated.
