Haier HSU-09H03/R1 Operation Manual
Split type room air conditioner
Hide thumbs
Also See for HSU-09H03/R1:
- Operation manual (21 pages) ,
- Installation manual (9 pages) ,
- Operation manual (16 pages)
Related Manuals for Haier HSU-09H03/R1
Summary of Contents for Haier HSU-09H03/R1
-
Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-09H03/R2(DB) HSU-12H03/R2(DB) Please read this operation manual before using the air conditioner. - Page 2 Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide.
- Page 3 Cautions Do not obstruct or cover the ventilation grille of the air conditoner.Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner.In no case should children be allowed to sit on the outdoor unit.
-
Page 4: Safety Instruction
Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. Installation in a inadequate place may cause accidents. Do not install in the following place. - Page 5 Cautions When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION Do not start or stop the operation by disconnecting the power supply cord and so on.
-
Page 6: Parts And Functions
Parts and Functions Indoor unit Inlet grille Air filter Vertical flap Use remote controller to adjust up and down air flow. (Don't adjust it manually.) Outdoor unit INLET OUTLET Timer mode indicator Power indicator Lights up when unit starts. Lights up when Timer operation is selected. - Page 7 11. SIGNAL SENDING display 12. LOCK display 13. TEMP display Remote controller: to display the TEMP. setting. 14.TIMER MODE display OFF:The air conditioner stops operation after the designed period. ON:The air conditioner starts operation after the designed period. 15. POWER/SOFT display 16.
- Page 8 When sudden power failure happens during unit operation in power failure resume mode, if the air conditioner is not desired for use in a long period, please shut off the power supply in case that the unit automatically resume operation when power is re-supplied, or press ON/OFF to turn off the unit when power resumes.
-
Page 9: Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: AUTO Air conditioner is running under displayed fan speed. When FAN is set to AUTO,the air conditioner automatically adjusts the fan speed according to room temperature. 5. Unit stop Press ON/OFF button, the unit stops. -
Page 10: Heat Operation
Remote controller: AUTO Air conditioner is running under displayed fan speed. In HEAT mode, warm air will blow out after a short period of the time due to cold-draft prevention function. When FAN is set to AUTO,the air conditioner automatically adjusts the fan speed according to room temperature. -
Page 11: Air Flow Direction Adjustment
Operation Air Flow Direction Adjustment Vertical Adjustment When ON/OFF switch is pressed, the vertical louver will move to the adequate positions for each operation automatically. Swing of Air Flow If air flow direction switch is pressed once, the vertical louver will move within the range of figures as right. - Page 12 Operation Timer Off Operation Remote Controller NOTICE Once the remote controller set the timer, the period is memorized. From next time operate easily with operation of the ON/OFF switch and the timer mode swith. After replacing the dry batteries, the designated period is set automatically as follows: OFF: 1 hour, ON: 6 hour.
- Page 13 Operation Timer On Operation Remote Controller With this function, the system starts operating after the designated period: the system can be set to turn on automatically at the time of awakening or arriving home. Set clock correctly before starting TIMER operation. 1.
-
Page 14: Power/Soft Operation
Operation Power/Soft Operation POWER Operation When you need rapid heating or cooling, you can use this function. Selecting of POWER operation Remote Controller Press POWER/SOFT button. Every time the button is pressed,display changes as follows: Stop the display at In POWER operation status: In HEAT mode, fan speed automatically runs in HI mode for 15 min then returns to original status setting. -
Page 15: Emergency And Test Operation
Operation Emergency and Test Operation Emergency operation: Use this operation only when the remote controller is defective or lost. When the emergency operation switch is pressed,the" Pi "sound is heard once, which means the start of this operation. In this operation, the system automatically selects the operation modes, cooling or heating, according to the room temperature. -
Page 16: Maintenance
Maintenance For Smart Use of The Air Conditioner Setting of proper room temperature Close doors and windows during operation If the unit is not to be used for a long time, turn off the power supply main switch. Do not block the air inlet... -
Page 17: Remote Controller
Close the inlet grille. Indoor Body Wipe the air conditioner by using a soft and dry cloth. For serious stains, use a neutral detergent diluted with water. Wring the water out of the cloth before wiping, then wipe off the detergent completely. -
Page 18: Cleaning The Body
Maintenance To Keep Your Air conditioner in Good Condition after Season Operate in cooling mode for 2-3 hours. To prevent breeding mold or bad smell, be sure to operate at the designated temperature or 30 mode and High speed fan mode for 2-3 hours. -
Page 19: Connecting The Earthing Cable
Maintenance Before Setting in High Season Cleaning the standard air filter. Operation without filter may cause troubles.Be sure to attach both right and left filters prior to the operation. Each of them are of different shapes. Connecting the earthing cable. Incomplete earthing may cause an electric shock. -
Page 20: Troubleshooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
