- Page 1 PRODUCT INSTRUCTION MANUAL Model: RS-A07 www.gzsamebike.com EN User Manual DE Benutzerhandbuch FR Manuel utilisateur I T Manual dell’utente ES Manuale de usuario...
- Page 2 CONTENTS English....1-11 Deutsch...12-22 Francais..23-33 Italiano... 34-44 Espanol ..45-55...
- Page 3 Urban commuting electric bicycles User Manual Model: RS-A07 Production license No. : (粤)XK16-002-01025...
-
Page 4: Table Of Contents
Contents Important warning Unpacking and specs Product components Method of assembly Adjust handlebar and stem Install the front and rear mudguards Install the front wheel Install the vegetable basket and front headlights Installing the pedal Method to remove battery Charging Methods Display Instruction LCD Display (functional instruction) Preparation before riding... -
Page 5: Important Warning
1. Important warning This manual include important safety performance information and service information. Please make sure you have read the following warning content before the first time you use our product. If you borrow your electric bicycle to other people, please let the user read this manual, it could help to decrease the risk of accident. -
Page 6: Unpacking And Specs
2. Unpacking and specs Remove all package material, then inspect each item for any accident damage that may have occurred during shipping.You should find each of these items in your box: (Large wrench*3) RS-A07 TOOLS BATTERY CHARGER (Allen wrench*5) (Screwdriver*1) -
Page 7: Product Components
3. Product components Handlebar Display Derailleur Control Panel Rear Brake Lever Front Brake Lever charge port Throttle Horn button Overall View Handlebar Disc brake Battery Pedal Basket Tire Motor Headlight Saddle Flywheel Suspension Fork Rear Rack Chain... -
Page 8: Method Of Assembly
4. Method of assembly 4.1 Adjust handlebar and stem Turn the stem clockwise to the front After adjusting the angle of the handle, tighten Loosen the screws in the direction the screws in the direction to fix the handle Loosen the four screws and remove the Handlebars center on stem assembly After adjusting the angle according to handle cover... -
Page 9: Install The Front Wheel
4.3 Install the front wheel Take out the quick-release Take out the front wheel Put the tire into the fork Place the caliper in the clamp, pls pay attention to the disc brake direction of spring. Place the quick release clamp Install quick-release nuts on Tighten the quick disassembly Press the quick release clamp... -
Page 10: Installing The Pedal
4.5 Installing the pedal Pay attention to the "L" and Don't install pedals upside Tighten the right pedal “R” Tighten the left pedal “L” "R" marks on the pedal down, otherwise it will damage clockwise counter clockwise the thread 4.6 Method to remove battery Find the key (factory default Turn the key to open the lock Take out the battery at the arrow... -
Page 11: Display Instruction
5. Display Instruction 5.1 LCD Display (functional instruction) Power Display Headlight Display Error Code Display Real-time Speed Cruise Indication Assist Pushing Display Single Mileage PAS level Total Mileage Maximum Speed Average Speed Functions The meter offers a variety of features to meet your cycling needs, including: ●... - Page 12 On/Off key Plus key Headlight key Toggle key Minus key USB charge port ◆ Power on/off After long pressing the power on/off button ,the meter starts to work and turn on the working power of the controller. In the power-on state, long press the power-on/off button to turn off the power.
-
Page 13: Preparation Before Riding
6. Preparation before riding 1.Before riding, please read the <User Manual> carefully. Please check whether the parts in good condition to ensure the safety of your riding. 2.Please check the status of the vehicle. Please check the brake, wheel, handlebar, folding buckle, quick release part of the electric bike to make sure the electric bike has good status. - Page 14 AFTER SALES PROBLEMS SCAN THE QR CODE GUANGZHOU SAMEWAY ELECTRIC BICYCLE CO.,LTD Add: N0.1 Factory, Xiling, Huashan town, Huadu dstrict, Guangzhou City, Guangdong Province, CHINA Official website: www.gzsamebike.com Please contact for after-sales questions E-mail: sameway@gzsamebike.com https://www.youtube.com/channel/UCDDjD4TNvZE1- Jb0bPkdONvQ （Pre-sales, after-sales and installation videos）...
