REACH Wireless®
Sounder Base
Product overview
Product
REACH Wireless Sounder Base
Part No.
RW1300-110APO
Product
REACH Wireless Sounder Base -
Black Body
Part No.
RW1300-160APO
Digital Communication
Apollo protocol compatibility is handled via
the Loop-Interface device, RW1700-030APO.
See product for more detail.
Product information
The RW1300-110APO and RW1300-160APO are wireless
analogue addressable sounder bases that can be used as a stand-
alone notification device (with a blanking cap, see next page) or as
a combined solution with a REACH Wireless detector.
• Compatible only with REACH Wireless
• 16 number of tone settings (primary and secondary for alert
and evacuation), selectable via on-board DIL Switches
• Four Volume Settings
• Bi-directional wireless communication
• Dual channel redundancy
• Five year battery life
• Five year product warranty
36 Brookside Road, Havant
Hampshire, PO9 1JR, UK.
MANAGEMENT
MANAGEMENT
SYSTEMS
SYSTEMS
Assessed to ISO 9001:2015
Assessed to ISO 14001:2015
Cert/LPCB ref. 010
Cert/LPCB ref. 010 EMS
Tel: +44 (0)23 9249 2412
Email: enquiries@apollo-fire.com
Fax: +44 (0)23 9249 2754
Web: www.apollo-fire.co.uk
PRODUCT
T
CERTIFICATION
ON
© Apollo Fire Detectors Ltd 2024
Cert/LPCB ref. 010
Manufacturer's Specification
All data is supplied subject to change without notice. Specifications are
typical at 24 V, 25°C and 50% RH unless otherwise stated.
Number of Tone Pairs
16 (see table 4)
Volume Levels
Four (see table 3)
Sound Output (Typical)
88 - 91 dBA (tone dependant)
Communication Range
100 m (in open space)
between Loop-Interface and
Devices
Field Device Radio Frequency
22 pairs
Channel Pairs
Radiated Power
14 dBm (25 mW)
Battery Type
2x VARTA CR123A Lithium 3 V, 1250mAh
typical
Battery Lifespan
Five years in normal operation with good
signal strength (no dropped messages)
Operating Temperature
-10°C to +55°C
Maximum Relative Humidity
95%
(non-condensing)
IP Rating
IP 21C (Type A Indoor Use)
Dimensions
129 mm diameter x 54 mm height
Weight (including batteries)
190 g
All information in this document is given in good faith but Apollo
Fire Detectors Ltd cannot be held responsible for any omissions
or errors. The company reserves the right to change the
specifications of products at any time and without prior notice.
PP5118/2024/Issue 2
Page 1 of 4
54 mm
45 mm
129 mm
102 mm
