Apollo REACH Wireless RW1300-260APO Manual

REACH Wireless®
Sounder VAD Base
Product overview
Product REACH Wireless Sounder VAD Base
Part No. RW1300-210APO
RW1300-211APO (Red Flash)
Product REACH Wireless Sounder VAD Base
- Black Body
Part No. RW1300-260APO (White Flash)
Digital Communication
Apollo protocol compatibility is handled via
the Loop-Interface device, RW1700-030APO.
See product for more detail.
Product information
The RW1300-210APO, RW1300-211APO and RW1300-260APO
are wireless analogue addressable sounder VAD bases that can
be used as a stand-alone notification device (with a blanking cap,
see next page) or as a combined solution with a REACH Wireless
detector.
• Compatible only with REACH Wireless
• 16 number of tone settings (primary and secondary for alert
and evacuation), selectable via on-board DIL Switches
• Four Volume Settings
• Bi-directional wireless communication
• Dual channel redundancy
• Five year battery life
• Five year product warranty
36 Brookside Road, Havant
Hampshire, PO9 1JR, UK.
MANAGEMENT MANAGEMENT
SYSTEMS SYSTEMS
Assessed to ISO 9001:2015 Assessed to ISO 14001:2015
Cert/LPCB ref. 010 Cert/LPCB ref. 010 EMS
(White Flash)
Tel: +44 (0)23 9249 2412 Email: enquiries@apollo-fire.com
Fax: +44 (0)23 9249 2754 Web: www.apollo-fire.co.uk
PRODUCT T
CERTIFICATION ON
© Apollo Fire Detectors Ltd 2024
Cert/LPCB ref. 010
Manufacturer's Specification
All data is supplied subject to change without notice. Specifications are
typical at 24 V, 25°C and 50% RH unless otherwise stated.
Number of Tone Pairs 16 (see table 7)
Volume Levels Four volume settings
Sound Output (Typical) 88 - 91 dBA (tone dependant)
VAD Coverage Rating (EN54- Configurable (see table 4)
25)
Flash Rate
0.5 Hz
Communication Range 100 m (in open space)
between Loop-Interface and
Devices
Field Device Radio Frequency
22 pairs
Channel Pairs
Radiated Power 14 dBm (25 mW)
Battery Type 2x VARTA CR123A Lithium 3 V, 1250mAh
typical
Battery Lifespan Five years in normal operation with good
signal strength (no dropped messages)
Operating Temperature -10°C to +55°C
Maximum Relative Humidity 95%
(non-condensing)
IP Rating IP 21C (Type A Indoor Use)
Dimensions 129 mm diameter x 54 mm height
Weight (including batteries) 190 g
All information in this document is given in good faith but Apollo
Fire Detectors Ltd cannot be held responsible for any omissions
or errors. The company reserves the right to change the
specifications of products at any time and without prior notice.
PP5119/2024/Issue 2
Page 1 of 4
54 mm
45 mm
129 mm 102 mm
