- Page 1 TreeTronic Manual Software version: Q72.x Manual version: November 2021 With Passion and Precision Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk...
-
Page 2: Table Of Contents
Changing the accumulator................- 35 - 8.2. Technical specifications ..................- 36 - Abbreviations......................- 36 - Contact information....................- 36 - - 2 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 3: Introduction
Please see the PiCUS Sonic Tomograph manual for more information. Grafic by Dr. T. Günther and Dr. C. Rücker - 3 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... - Page 4 The colours in the EI Tomograms represent values in the unit [Ohm * meter]. Program scheme by Dr. T. Günther and Dr. C. Rücker - 4 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:...
-
Page 5: Picus : Treetronic Technical Notes
This means that areas of relative high conductivity, such as the ring of sapwood and bark, shown in blues in an ERT, are more conductive than the “dryer” heartwood in spring, summer, - 5 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 6: Electrodes
In general you can use any type of conductive metal electrodes to take ERT measurements. We recommend electrical galvanized nails, which can be used for taking both sonic and electric impedance measurements. - 6 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 7: Ert Measurements
Sapwood cannot be found if distance between the MP is too large. In many cases it is best to use twice as many MP as you would use for SoT measurements. - 7 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... - Page 8 In order to detect/measure the size of outer layers such as bark/sapwood, the distance between MP should coincide with the thickness of the layer expected. - 8 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:...
-
Page 9: Installing The Nails
MP should also be placed in damaged areas because the altered properties of the damaged wood can be detected better this way. - 9 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 10: Selecting The Measuring Level
(top tomogram) infringe upon the above rule, but the result is very likely correct as it shows same pattern as at other levels. 25 cm - 10 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 11: Mount The Equipment On The Tree
Do not connect the electrodes with one another. Also, do not mount more than one electrode to a nail. - 11 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 12: Using Two Treetronic Instruments
“Treetronic 1”. Device 2 Device 1 Allocation table Treetronic device Wire number 1..24 1..24 … … - 12 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 13: Measure The Geometry At The Measuring Level
However, in some cases you will need to record the geometry correctly. The screen looks like this: - 13 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 14: Resistance Measurement
To do so, proceed as follows: 1. Create a new Treetronic file (File → New Electric Impedance Tomogram (ERT)…) - 14 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... - Page 15 The “Allocation” map specifies how the electrodes are mapped when two or more Treetronics (e.g. more than 24 MP) are used. - 15 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:...
- Page 16 These settings can also be changed in the measuring window shown in the following sections. B-M distance = 8 [MP] M-N distance = 3 [MP] - 16 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk...
-
Page 17: Ert Measuring Process
“Amp-AB” and “Volt-MN” indicators should be shown in green or yellow colours. If they appear more in red colours, you will need to change the voltage level. - 17 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... - Page 18 Do not touch the cables or the tree while the measurements are running! There is a risk of electric shock while current is present. - 18 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:...
- Page 19 10. Run the calculation to see the results. Click “File” → “Save” again to save the tomogram calculated in the measuring file. - 19 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:...
-
Page 20: Calculate The Electrical Resistance Tomogram (Ert)
Do not touch the tree or any of the wires while the measurements are being taken. Voltages can reach up to 100 Volt. - 20 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 21: Software Description
These positions coincide with those calculated in the SoT. Smoothness 1 Smoothness 3 Smoothness 20 - 21 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 22: Mesh Fineness
The smoothing level 20 is a good value which will work for most situations. - 22 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 23: 3-D Ert Tomograms
Alternatively the “alt” + “print” keys can be used to copy the current screen into the window clipboard. From here it can be pasted into other image-processing programs. - 23 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 24: Interpretation
– because of the moisture content, it is not dry – but it is less conductive than the heartwood. - 24 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... - Page 25 EIT. Recorded by IML Electronic, Rostock, Germany 2009. - 25 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:...
- Page 26 Cavity / dead decay There are exceptions to these guidelines, depending on tree species, type of fungus, etc. - 26 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk...
-
Page 27: Examples
This may indicate another root-related problem – an early stage of decay. Recorded by IML Electronic, Aubonne, Switzerland, 2008. - 27 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 28: Crack/Bark Inclusion Or Decay - Beech Tree
NOT to fell the tree. Recorded by Frits Gielissen, The Netherlands, 2008. - 28 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 29: Crack/Bark Inclusion Or Decay? Sequoia Giganteum
SoT (2) very likely consisted of intact wood, because the conductivity seemed to be normal (3). The high resistance area (4) appeared to be a cavity. - 29 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 30: Activity Of Fungus Infection
Low sonic velocity and high resistance (5) show where the cavity is. photo of the linden tree Recorded by IML Electronic, Rostock, Germany, 2009. - 30 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 31: Decay Or Cavity (Ii)
(red colours in ERT) than the ERT in section 5.2.7 above shows. SoT – 20cm above ground Meripilus Giganteus fruiting bodies - 31 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 32: Additional Remarks
- 32 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 33: Possible Problems
(red) curve as shown in this example. In this case, you should try to enlarge the voltage level and repeat the measurements. - 33 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web:... -
Page 34: Safety Information And General Hints
Do not connect the electrodes with one another. Do not mount more than one electrode to each nail. - 34 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 35: Technical Information
2. Remove the soft cover. 3. Disconnect the cable from the old accumulator. 4. Connect the new accumulator. - 35 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk... -
Page 36: Technical Specifications
Sonic Tomography or Sonic Tomogram Voltage Ωm Physical unit the EIT is showing: Ohm * meter Date : 27 March 2015 - 36 - Promat (HK) Limited | Tel: (852) 2661 2392 | Whatsapp: (852) 5196 8861 | Email: sales@Promat.hk | Web: https://www.promat.hk...
