Frigidaire FRS093LS1 Product Specifications
Frigidaire FRS093LS1 Product Specifications

Frigidaire FRS093LS1 Product Specifications

Home comfort ductless mini-split air conditioner
Hide thumbs Also See for FRS093LS1:

Advertisement

Home Comfort
FRS093LS1
Signature Features
Effortless™ Temperature
Control
Our air conditioners maintain the preset
room temperature, so you will remain
comfortable at all times.

Remote Control

Allows you to precisely control the
temperature and fan speed from across
the room.
FRS093LW1
Indoor
1
FRS093LC1
Outdoor
1
Ready-Select™ Controls
Easily select options with the touch of a
button.
Effortless™ Clean Filter
Our anti-microbial filter cleans the air,
removing harmful bacteria.
Ductless Mini-Split
Air Conditioner 
Product Dimensions
Evaporator (Indoor) Model
Height
10-7/16"
Width
31-1/8"
Depth
7-11/16"
Product Dimensions
Condenser (Outdoor) Model
Height
21-1/4"
Width
30-3/4"
Depth
9-7/8"
More Easy-To-Use Features
Energy and Cost Savings
A split system helps avoid the energy
losses that normally come with ductwork.
This loss can amount to up to 40% due to
leaks, tears and long lengths.
Multi-Speed Fan
Features three different fan speeds, for
more cooling flexibility.
Sleep Mode
Quiet operation keeps you cool without
keeping you awake. Plus, Sleep Mode
gradually increases room temperature
after being activated.
Quickly Cools
Turbo Mode for that quick cool-down
when you first turn it on
Comfort Control Design
Easily control the direction of your cool air,
wherever your unit is.
Effortless™ Restart
Automatically resumes operating at its
previous settings when power is restored
to your unit.
24 Hour On/Off Timer
Performance
BTUs
Cool
9,000
1
Photo may not represent actual model.
frigidaire.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRS093LS1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Frigidaire FRS093LS1

  • Page 1: Remote Control

    Energy and Cost Savings A split system helps avoid the energy losses that normally come with ductwork. This loss can amount to up to 40% due to leaks, tears and long lengths. Multi-Speed Fan Features three different fan speeds, for more cooling flexibility.
  • Page 2 Insulated line sets and control wires are required and available for Frigidaire split systems in 16.4 ft. length. Each line set is equipped with flare nuts on both ends. Each system requires one line set for each indoor unit installed.
  • Page 3 Min/Max Cooling F 12.7 mm (1/2") Suction (od) SEER 13.0 OUTDOOR UNIT 14.8422 £ 55 dB (A) Low Ambient Temperature 17° C-43° C (62° F~109° F) Sound rating Voltage/Frequency/Phase 115V/60Hz/1P Net Weight 67 lbs Dehumidification 2.0 PT/H Shipping Weight 72 lbs Dimensions (H x W x D) 21.26"...
  • Page 4 13.6 A Sound Rating Maximum Fuse Size 15 A Net Weight 67 lb Shipping Weight 72 lb CAPACITIES Dimensions (H x W x D) 21.26" x 30.71" x 9.84" Cooling 9,000 Btu Recommended Fuse 15 A Amps 7.3 A Minimum Amps 0.7 A...

This manual is also suitable for:

Frs093lw1Frs093lc1
