Summary of Contents for Delta VFD-G Series

  • Page 2 www.termoprocesos.com...
  • Page 4 VFD-G Series Preface Thank you for choosing DELTA’s VFD-G series for plastic molding and air compressors machinery. VFD-G Series are manufactured by adopting high-quality components, material and incorporating the latest microprocessor technology available. Getting Started This manual will be helpful in the installation, parameter setting, troubleshooting, and daily maintenance of the AC motor drives.

  • Page 5: Table Of Contents

    CHAPTER 5 DESCRIPTION OF PARAMETER SETTINGS 5.1 Group 0: AC Drive Status Parameters ..........5 - 1 5.2 Group 1: Basic Parameters ..............5 - 4 5.3 Group 2: Operation Method Parameters ..........5 - 8 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 6 CHAPTER 8 SUMMARY OF PARAMETER SETTINGS......8 - 1 APPENDIX A SPECIFICATIONS ............... A - 1 APPENDIX B ACCESSORIES B.1 All Braking Resistors & Braking Units Use in AC Drives ....B - 1 APPENDIX C DIMENSIONS............... C - 1 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 8: Chapter 1 Receiving And Inspections

    Version Type Input Voltage 43:Three phase 460V Series Name Applicable motor capacity 450: 60HP(45kW) 055: 7.5HP(5.5kW) 550: 75HP(55kW) 220: 30 HP(22kW) 075: 10 HP(7.5kW) 750: 100HP(75kW) 300: 40HP(30kW) 110: 15 HP(11kW) 370: 50HP(37kW) 150: 20HP(15kW) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 9: Serial Number Explanation

    VFD-G Series 1.3 Serial Number Explanation 075F43A4 22 0001 Production number 460V 3-PHASE 10HP(7.5kW) Production model If there is any nameplate information not corresponding to your purchase order or any problem, please contact your distributor. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 10: Chapter 2 Storage And Installation

    Relative Humidity: Less than 90%, no condensation allowed Atmosphere pressure: 86 to 106 kPa Vibration: Maximum 9.86 m/s (1G) at less than 20Hz, Maximum 5.88 (0.6G) at 20Hz to 50Hz Pollution Degree 2: good for a factory type environment. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 11: Installation

    Mount the AC drive vertically and do not restrict the air flow to the heat sink fins. The AC drive generates heat. Allow sufficient space around the unit for heat dissipation. 150mm VFD-F VFD-PU 01 STOP JO G JO G STO P RESET Air Flow 150mm DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 12: Chapter 3 Wiring

    Wait five minutes for DC bus capacitors discharge. Any electrical or mechanical modification to this equipment without prior written consent of Delta Electronics, Inc. will void all warranties and may result in a safety hazard in addition to voiding the UL listing.

  • Page 13: Basic Wiring Diagram

    Analog Signal Common RS-485 Serial interface 0-10V 0-1A 1: +EV 2: GND 3:SG- 4: SG+ 5: NC 6: for communication 0~1A 0~10V NOTE:*1-3 are optional. Analog Signal Common Main circuit (power) terminals Control circuit terminals DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 14 VFD-G Series Wiring for SINK mode and SOURCE mode E.F. Sink E.F. Source *Don apply main voltage directly 　 to above terminals. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 15 Analog voltage Input operation frequency 0 to +10V / 0 to 1A correspond to Max. Analog current Input operation frequency AC1/AC2 Analog control signal common * Control signal wiring size: 18 AWG (0.75 mm DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 16: Main Circuit Wiring

    Wire Type: Stranded copper only, 75° C NOTE: If wiring of the terminal utilizes the wire with a 6AWG-diameter, it is thus necessary to use the Recognized Ring Terminal to conduct a proper wiring. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 17 Wire Type: Stranded copper only, 75° C NOTE: If wiring of the terminal utilizes the wire with a 1AWG-diameter, it is thus necessary to use the Recognized Ring Terminal to conduct a proper wiring. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 18 U/T1 V/T2 2/T3 POWER MOTOR Control Terminal Torque: 4Kgf-cm (3 in-lbf) Wire: 12-24 AWG Power Terminal Torque: 57kgf-cm (49.5 in-lbf) min. Wire Gauge: VFD370F43A-G: 3AWG VFD450F43A-G: 2AWG Wire Type: Stranded copper only, 75° C DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 19 Screw Torque: POWER MOTOR 200kgf-cm (173in-lbf) Control Terminal Torque: 4Kgf-cm (3 in-lbf) Wire: 12-24 AWG Power Terminal Torque: 200kgf-cm (173 in-lbf) Wire Gauge: VFD550F43A-G: 1/0-4/0 AWG VFD750F43A-G: 3/0-4/0 AWG Wire Type: Stranded copper only, 75°C DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 20: Wiring Notes

    To reverse the direction of motor rotation, switch over any of the two motor leads. 9. Make sure that the power source is capable of supplying the correct voltage and required current to the AC drive. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 21: Motor Operation Precautions

    3. When the standard motor operates at low speed, the output load must be decreased. 4. If 100% output torque is desired at low speed, it may be necessary to use a special “inverter-duty” rated motor. 3-10 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 22: Chapter 4 Digital Keypad Operation

    Description of the Keypad Description of Display Keypad Operation Modes & Programming Steps VFD-PU01 Dimensions: mm (inch) 19.0 [0.75] 44.0 [1.73] 73.0 [2.87] M4* 0.7(2X) MODE PROG DATA STOP DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 23: Description Of The Digital Keypad Vfd-Pu01

    Master Frequency. Display Message Descriptions Display the AC drive Master Frequency. Display the actual operation frequency present at terminals U/T1, V/T2, and W/T3. Display voltage (V), Current (A), power factor and feedback signal (P) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 24 Display “End” for approximately 1 second if input has been accepted. After a parameter value has been set, the new value is automatically stored in memory. To modify an entry, use the keys. Display “Err”, if the input is invalid. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 25: Operation Steps Of The Digital Keypad Vfd-Pu01

    Input data error move to previous display MODE NOTE ： In the parameter setting mode, you can press to return the selecting mode. MODE To shift data START To modify data START Setting direction DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 26: Chapter 5 Description Of Parameter Settings

    22 PHL (phase loss) Input power lacks phase. 3-phase input power is unbalance and exceeds specification. 23 Lc (Low Current) Low current detection during operation. 24 FbL(Feedback Loss) Feedback signal is abnormal. 25 Reserved DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 27 00 - 09 Output Power (kW) Factory setting: Read Only This parameter displays output power of the AC drive. 00 - 10 Feedback Signal Actual Value Factory setting: Read Only This parameter displays feedback signal value. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 28 PLC Time Factory setting: Read Only This parameter displays remaining time of PLC each step. Output Reactive Power (KVAR) Factory setting: Read Only 00 - 15 This parameter displays reactive power of AC drives. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 29: Group 1: Basic Parameters

    This parameter sets the Mid-point Frequency of the V/F curve. This parameter must meet the following argument. Pr.1-01 >= Pr.1-03 >= Pr.1-05. Mid-point Voltage Factory Setting: 11.0 01 - 04 Settings 0.2V~510.0V This parameter sets the Mid-point Voltage of the V/F curve. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 30 Pr.1-08, will result in an output equal to Pr.1-08. Upon a start command, the drive will accelerate from Pr.1-05 Minimum Output Frequency to the Master Frequency Command point. Output voltage 01-02 01-04 01-06 Output Frequency 01-05 01-03 01-01 01-07 01-08 01-00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 31 (Pr. 04-00 to 04-03 set to 07) or the JOG key on keypad. Once a JOG command is initiated, the AC drive will accelerate from the Minimum Output Frequency (Pr.01-05) to the JOG frequency (Pr.01-19). The accel/decel time of the JOG operation is determined by the JOG accel/decel speed (Pr.01-17 and 01-18). DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 32 This parameter sets the resolution of accel/decel time (Pr.01-09 to 01-18). A high resolution decreases the accel/decel time range as shown in the following chart. 01-23 Accel/Decel time unit Accel/Decel time range 1 Sec 1~36000 Sec 0.1 Sec 0.1~3600.0 Sec 0.01 Sec 0.01~360.00 Sec DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 33: Group 2: Operation Method Parameters

    Ramp: The AC drive decelerates the motor to minimum output frequency according to the deceleration time setting. Coast: The AC drive output instantly stops upon command and the motor free spins until it comes to a complete stop. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 34 Signification Signification Minimal Signification Minimal Minimal Minimal When the carrier frequency is low, current ripple of the AC drive is large. This may result in a current display value greater than the actual value. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 35 For example, a setting of 21 (decimal 21= hex 010101) will display the “H” and “REV” LEDs and the cursor will stay at the 3rd 7-step display upon power up. 5-10 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 36 If the Flying Start feature is enabled upon start-up, the DC braking 08-01 will be disabled. Factory Setting: 00 02 - 12 Flying Start Frequency Settings 00: Begin search from Master Frequency Command 01: Begin search from Maximum Frequency (Pr.01-00) 5-11 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 37 Upon power up the last known frequency is displayed. After a fault, the AC drive will always remember the last know master frequency command. This feature is only enabled when Pr. 02-00 is set for 0 or 4. 5-12 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 38: Group 3: Output Function Parameters

    The corresponding output will be closed when the AC drives DC bus voltage exceeds (Pr.08-19) the braking level. OL or OL1 overload warning The corresponding output will be closed upon an overload (OL or OL1) fault. 5-13 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 39 There is a ± 2Hz window of operation. If the master frequency attained is 20Hz and the output frequency exceeds 20Hz, the corresponding output relay will be “closed”. When the output frequency is less than 18Hz, the corresponding output relay will be “opened” as the following diagram shows. 5-14 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 40 02: Fan begins upon a RUN command. Fan stops after a STOP command 03: Fan is controlled by temperature. Fan will be started at approximate 60°C. This parameter determines DC fan control method. 5-15 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 41: Group 4: Input Function Parameters

    External selection of the Operation Command Source. (Keypad = terminal open) or (External terminals = terminal closed). This setting is valid when Pr.02-01 is set to 00. Otherwise, the Operation Command Source will follow the setting in Pr.02-01. 5-16 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 42 Maximum Output that corresponds to AI1 Settings 0.00~100.00% Unit: 0.01 Factory Setting: 0 04 - 09 Minimum AI2 Analog Input Factory Setting: 100 04 - 10 Maximum AI2 Analog Input Settings 0 ~ 100% Unit: 1 5-17 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 43 This parameter selects the terminals used for summation of the External Frequency Sources. Setting 07 is used to compare AI1*(Pr. 04-13) with AI2*(Pr. 04-14). If AI1*(Pr. 04-13) > AI2*(Pr. 04-14), it indicates that command source is from AI1, otherwise is from AI2. 5-18 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 44: Group 5: Multi-Step Speed Frequency Parameters

    Continuously execute program cycles step by step This parameter selects the mode of PLC operation for the AC drive. The AC drive will change speeds and directions according to the user’s desired programming. 5-19 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 45 The diagram above shows the PLC program stepping through each speed. Set Pr.05-15 to 2 for continuous program execution. To stop the PLC program, one must either pause the function or turn it off. (Refer to Pr.04-00 to 04-03 values 32 and 33). 5-20 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 46 The equivalent 15-bit number is used to program the forward/reverse motion for each of the 15 speed steps. The binary notation for the 15-bit number must be translated into decimal notation and then entered. 5-21 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 47 Setting 05-16 =19570 NOTE: 2 =16384 2 =8192 2 =4096 2 =2048 2 =1024 2 =512 2 =256 2 =128 2 =64 2 =32 2 =16 2 =8 2 =4 2 =2 2 =1 5-22 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 48 6550 seconds. Note: If a parameter is set to “00” (0 sec), the corresponding step will be skipped. This is commonly used to reduce the number of program steps. 5-23 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 49 Pr.04-00 to Pr.04-07 (MI1 to MI8 4) Jog Freq. Multi-Step Speed via External Terminals 05 - 32 Time Unit Settings Factory Setting: 00 Settings 1 Sec 0.1 Sec This parameter determines the time unit for Pr.05-17~Pr.05-31. 5-24 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 50: Group 6: Protection Parameters

    Pr.06-01 (please see the graph below). When the over-current stall prevention is activated, the acceleration time of the AC drive will be longer than the time set in Pr. 01-09. 5-25 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 51 02: Over-torque detection enabled during constant speed operation (OL2), and operation halted. 03: Over-torque detection enabled during operation (OL2), and operation continues. 04: Over-torque detection enabled during constant speed operation (OL2), and operation halted. 5-26 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 52 Pr.6-07, the drive will fault with an OL1. The common electronic thermal reaction time (150% output current for 1 minute) is shown in the chart below. The actual reaction time will vary depending on output current. 5-27 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 53 06 - 14 Fourth Recent Fault Record Settings No fault occurred Over-current (oc) Over-voltage (ov) Overheat (oH) Overload (oL) Overload1 (oL1) External fault (EF) IGBT protection (occ) CPU failure (CF3) Hardware protection failure (HPF) 5-28 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 54 After successfully entering the password, the user may change parameters as they wish. Once the drive is powered off, the drive has locked the parameters again. To clear the password, the user must enter the correct password in Pr.6-16 and then set Pr.6-17 to 00. 5-29 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 55 This parameter allows the user to set a password for parameter protection. After entering a password, Pr.6-17 will display 1. Be sure to keep the password in a safe place. If the password is lost, please return the drive to DELTA. 5-30 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 56: Group 7: Ac Drive And Motor Parameters

    The full-load current of the motor must be equal to or less than (but not less than 50%) the rated current of the AC drive. Factory Setting: 30% 07 - 03 No-load Current of Motor Settings 1~99% Unit: 1 This parameter sets the no-load current of the motor. 5-31 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 57 If rated frequency of motor is 60Hz, number of motor poles is 4 and rated rotation speed of motor is 1650rpm. The rated slip frequency of motor is 60Hz-(1650rpm X 4/120) = 5Hz. 5-32 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 58 Electric Bill for One Time 07 - 10 Factory Setting: Read Only 07 - 11 Accumulated Electric Bill (per currency unit) Factory Setting: Read Only 07 - 12 Accumulated Electric Bill (per 10 currency unit) 5-33 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 59 07 - 13 Electric Rate (per currency unit) Settings 0.01 to 655.35 Unit: 1 You can get electric bill from Pr. 07-10 to Pr. 07-12 after inputting local electric rate into Pr. 07-13. 5-34 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 60: Group 8: Special Parameters

    If this parameter is set greater than 01-05 minimum frequency setting, it won’t decelerate to 01-05 and enter DC braking status when AC drive brakes. Suitable DC braking start-up frequency setting will get better braking characteristic. 5-35 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 61 The allowable power loss time must in the condition that AC drive auxiliary power is working normally. If auxiliary power is turned off in the allowable power loss time, the actual allowable power loss time will be shorter than the parameter setting. 5-36 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 62 Maximum allowable Max. Allowable power loss time Power Loss Time 08-05 Power 08-05 Input Speed Synchronization Speed Search Detection 08-04=01 08-04=02 B.B. Time B.B.Time Output 08-06 08-06 Frequency Output Voltage Momentary Power Loss Operation 5-37 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 63 AC drive reset and runs with the parameter that is set before fault occurred. If fault occurred times exceed 08-09 setting, AC drive will reject to restart and need to reset by users to keep on running. 5-38 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 64 When AC drive accelerates or decelerates, output frequency will pass through inhibition operation frequency range. Factory Setting: 00 08 - 17 Automatic Energy-saving 00: Energy-saving operation disabled Settings 01: Energy-saving operation enabled This parameter determines automatic energy-saving function. 5-39 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 65 The model VFD055~150F43A has braking chip, user could select suitable braking resistor to have the best deceleration characteristics. The action level of the braking resistor could be set by this parameter. Factory Setting: 00 08 - 20 Vibration Compensation Factor Settings 00~1000 Unit: 1 5-40 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 66 VFD-G Series This parameter will minimize vibration at low speed during vector control. The value of the parameter is a GAIN. The higher the value, the more vibration dampening that will occur. 5-41 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 67: Group 9: Communication Parameters

    01: Even parity + 2 stop bit 02: Odd parity + 2 stop bit 03: None parity + 1 stop bit 04: Even parity + 1 stop bit 05: Odd parity + 1 stop bit 5-42 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 68 This parameter can be set by communication settings. It can’t be set by keypad. Factory Setting: 60.00 09 - 07 Communication Frequency Setting Settings 0~120.00Hz Unit: 0.01 This parameter can be set by communication settings. It can’t be set by keypad. 5-43 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 69 ‘4’ ‘5’ ‘6’ ‘7’ ASCII Code Character ‘8’ ‘9’ ‘A’ ‘B’ ‘C’ ‘D’ ‘E’ ‘F’ ASCII Code RTU mode: Each 8-bit is the combination of two 4-bit hexadecimal characters. For example, 64 Hex. 5-44 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 70 (8 , N , 2 : 9-04=1 or 2, 9-05=00) Start Stop Stop 8-bit character 11-bit character frame (8 , E , 1 : 9-04=1 or 2, 9-05=04) Start Even Stop parity 8-bit character 11-bit character frame 5-45 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 71 Valid communication addresses are in the range of 0 to 254. a communication address equal to 0, means broadcast to all AC drives (AMD). In this case, the AMD will not reply any message to the master device. 5-46 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 72 ‘0’ END 1 (Word) ‘2’ ‘8’ END 0 LRC CHK 1 ‘D’ 0102H ‘9’ LRC CHK 0 ‘7’ ‘8’ END 1 ‘D’ CHK 1 END 0 ‘1’ CHK 0 END 1 END 0 5-47 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 73 CHK 1 ‘7’ ‘7’ END 1 ‘0’ ‘0’ END 0 LRC CHK 1 ‘7’ LRC CHK 1 ‘7’ LRC CHK 0 ‘7’ LRC CHK 0 ‘7’ END 1 END 1 END 0 END 0 5-48 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 74 CHK 1 ‘7’ ‘7’ END 1 ‘0’ ‘0’ END 0 LRC CHK 1 ‘7’ LRC CHK 1 ‘7’ LRC CHK 0 ‘0’ LRC CHK 0 ‘0’ END 1 END 1 END 0 END 0 5-49 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 75 ‘8’ CHK 0 The first ‘1’ END 1 data ‘3’ END 0 ‘8’ ‘8’ The second ‘0’ data ‘F’ ‘A’ ‘0’ LRC CHK 1 ‘9’ LRC CHK 0 ‘A’ END 1 END 0 5-50 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 76 Data starting ‘0’ address ‘4’ ‘0’ ‘1’ Number of data ‘0’ ‘0’ ‘0’ ‘1’ LRC CHK 1 ‘F’ LRC CHK 0 ‘6’ END 1 END 0 01H+03H+04H+01H+00H+01H=0AH, 2’s complement of 0AH is F6H. 5-51 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 77 The following is an example of CRC generation using C language. The function takes two arguments: Unsigned char* data a pointer to the message buffer Unsigned char length the quantity of bytes in the message buffer 5-52 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 78 01B: FWD command Bit 4-5 10B: REV command 11B: Direction change command 00B: 1 step acce/decel speed 01B: 2 step acce/decel speed Bit 6-7 10B: 3 step acce/decel speed 11B: 4 step acce/decel speed 5-53 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 79 13: Ground Fault (GFF) 14: Low voltage (Lv) 15: CPU failure 1 (cF1) 16: CPU failure 2 (cF2) 17: Base Block (bb) 18: Overload (oL2) 19: Auto accel/decel failure (cFA) 20: Software protection enabled (codE) 5-54 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 80 Power Factor (n) 2108H Output power (XX.XXKW) 2109H Feedback Signal 210AH Feedback Signal (%) 210BH Estimated torque ratio 210CH User output (Low) uL 0-99.99 210DH User output (High) uH 0-9999 210EH PLC Time 210FH Reserved 5-55 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 81 Illegal data value: The data value received in the command message is not available for the AC drive. Slave device failure: The AC drive is unable to perform the requested action. Communication time-out: 5-56 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 82 When this parameter is set to 00: when negative feedback control, the deviation equation is deviation = target value – detection signal. When increasing output frequency will increase detection value, this setting should be chose. 5-57 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 83 This parameter could set the upper bound of I controller. In other words, upper bound for integral control = (01-00) X (10-04) % Factory Setting: 0.0 10 - 07 Primary Low Pass Filter Time Settings 0.0~2.5 Sec Unit: 0.1 5-58 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 84 01: 1.5 power curve 02: 1.7 power curve 03: 2 power curve 04: 3 power curve This parameter is to set V/F curve. If this parameter isn’t set to 00, parameter 01-03 and 01-04 will disable. 5-59 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 85 AC drive to accel/decel quickly. If it needs to accel/decel quickly, it is not recommended to use this parameter. 01-02 Voltage% 1.5 power curve 1.7 power curve 2 power curve 3 power curve Frequency 01-01 V/F Curve Diagram 5-60 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 86: Chapter 6 Maintenance And Inspections

    Clean off any dust and dirt with a vacuum cleaner. Place special emphasis on cleaning the ventilation ports and PCBs. Always keep these areas clean, as accumulation of dust and dirt can cause unforeseen failures. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 88: Chapter 7 Troubleshooting And Fault Information

    3. Bus over-voltage may also be caused has exceeded its by motor regeneration. Either increase maximum allowable the decel time or add an optional value. braking resistor. 4. Check whether the required braking power is within the specified limits. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 89 (Pr.6-03 to Pr.6-05) to an appropriate setting (Pr.06-03 to Pr.06-05). 1. Check the connection between the AC drive and computer for loose wires. Communication Error 2. Check if the communication protocol is properly set. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 90 2. Press RESET after fault has been cleared. Emergency stop. When the multi-function input terminals (MI1 to Press RESET after fault has been cleared. MI6) stop, AC drive stops any output. Software protection Return to the factory. failure DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 91 2. Check the EEPROM on the control cannot be programmed. board. Internal memory IC 1. Return to the factory. cannot be read. 2. Reset drive to factory defaults. Drive’s internal circuitry Return to the factory abnormal. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 92 VFD-G Series Fault Fault Descriptions Corrective Actions Name U-phase error V-phase error W-phase error Return to the factory OV or LV Isum error OH error DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 94: Chapter 8 Summary Of Parameter Settings

    15: CF1(abnormal input data) 16: CF2(abnormal output data) 17: bb(Base Block) 18: oL2(over load2) 19: Reserved 20: codE(software or password protection) 21: EF1(external Emergency Stop) 22: PHL(phase loss) 23: Lc (Low Current) 24: FbL(Feedback Loss) 25: Reserved DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 95 User Target Value (Low bit) Read only Read uL 0-99.99 00-13 User Target Value (High bit) Read only Read uH 0-9999 00-14 PLC Time Read only Read 00-15 Output Reactive Power Read only Read (KVAR) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 96 0.00 01-21 S Curve Delay Time in Decel 0.00~2.50sec 0.00 01-22 Modulation Index 0.90~1.20 1.00 01-23 Accel/Decel Time Unit 00: Unit is 1 Sec 01: Unit is 0.1 Sec 02: Unit is 0.01 Sec DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 97 03:Stop = coast to stop, E.F. = ramp to stop 02-03 PWM Carrier Frequency 1K~6KHz Selections 02-04 Forward/Reverse Enable 00: Forward enabled 01: Reverse disabled 02: Forward disabled 02-05 Reserved 02-06 Line Start Lockout 00: Disabled 01: Enabled 02-07 Reserved DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 98 Flying Start Frequency 00: Trace from master frequency command 01: Trace from maximum setting frequency 01-00 02-13 Master Frequency Memory 00: Do not remember the last Setting known frequency 01: Remember the last known frequency DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 99 00: Fan runs on power up. 01: Fan begins upon a RUN command. Fan stops 1 minute after a STOP command. 02: Fan begins upon a RUN command. Fan stops after a STOP command DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 100 VFD-G Series Factory Parameters Functions Settings Customer Setting 03-04 DC Fan Control 03: Fan is controlled by temperature. Fan will be started at approximate 60°C. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 101 AI2 04-13 AI1 Gain 0.0~100.0% 100.0 04-14 AI2 Gain 0.0~100.0% 100.0 04-15 Reserved 04-16 Reserved 04-17 Analog Input Delay AI1 0.00~10.00 Sec 0.50 04-18 Analog Input Delay AI2 0.00~10.00 Sec 0.50 04-19 Reserved DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 102 Summation of External 00: No functions Frequency Sources 01:AI1*(Pr.04-13) + AI2*(Pr.04-14) 02:AI1*(Pr.04-13) - AI2*(Pr.04-14) 03: AI1*(Pr.04-13) * AI2 *(Pr.04-14) 04: Reserved 05: Communication master frequency+AI1*(Pr.04-13) 06: Communication master frequency+AI2*(Pr.04-14) 07: Max (AI1*(Pr. 04-13), AI2*(Pr. 04-14)) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 103 Time Duration Step 9 0.0 to 65500 Sec 05-26 Time Duration Step 10 0.0 to 65500 Sec 05-27 Time Duration Step 11 0.0 to 65500 Sec 05-28 Time Duration Step 12 0.0 to 65500 Sec 8-10 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 104 Time Duration Step 13 0.0 to 65500 Sec 05-30 Time Duration Step 14 0.0 to 65500 Sec 05-31 Time Duration Step 15 0.0 to 65500 Sec 00: 1 Sec 05-32 Time Unit Settings 01: 0.1 Sec 8-11 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 105 02: Warn and keep operating 06-11 Present Fault Record 00: No Fault 01: Oc (over-current) 06-12 Second Most Recent Fault 02: Ov (over-voltage) Record 03: OH (over temperature) 06-13 Third Most Recent Fault Record 8-12 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 106 24: FbL(Feedback Loss) 25: Reserved 06-15 Parameter Reset 00~65535 09: Reset parameters (50Hz, 380) 10: Reset parameters (60Hz, 440) 06-16 Parameter Protection Password 00~65535 Input 06-17 Parameter Protection Password 00~65535 Setting 00: No password protection 8-13 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 107 Electric Bill for One Time Read Only Read 07-11 Accumulated Electric Bill (per Read Only Read currency unit) 07-12 Accumulated Electric Bill (per Read Only Read currency unit) 07-13 Electric Rate (per currency unit) 0.01 to 655.35 8-14 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 108 00: AVR function enabled (AVR) 01: AVR function disabled 02: AVR function disabled for deceleration 08-19 Software Setting of the Braking 740V~820VDC Level 00:Disable (the action level of the braking resistor) 08-20 Vibration Compensation Factor 00~1000 8-15 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 109 Bit4~5: 00: No function 01: FWD command 10: REV command 11: Change direction command Bit6~7: 00: 1 step accel/decel speed 01: 2 step accel/decel speed 10: 3 step accel/decel speed 11: 4 step accel/decel speed 8-16 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 110 Bit12: Select Bit6~11 function Bit13~15 Reserved 09-07 Communication Frequency 0~120.00Hz 60.00 Setting 09-08 Communication Operation Bit0: 1: EF ON Command 2 Bit1: 1: Reset Bit2: 0: BB OFF, 1: BB ON Bit3~15: Reserved 8-17 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 111 01: Warn and COAST stop 02: Warn and keep operating 10-11 V/F Curve Selection 00: Determined by group 01 01: 1.5 power curve 02: 1.7 power curve 03: 2 power curve 04: 3 power curve 8-18 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 112: Appendix A Specifications

    Ambient Temperature C to 40 C Non-Condensing and not frozen Storage/ Transportation C to 60 Temperature Ambient Humidity Below 90% RH (non-condensing) Vibration 9.80665m/s (1G) less than 20Hz, 5.88m/s (0.6G) at 20 to 50Hz DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 114: Appendix B Accessories

    Note: Please only use DELTA resistors and recommended values. Other resistors and values will void Delta’s warranty. Please contact your nearest Delta representative for use of special resistors. For instance, in 460 V series, 100 HP, AC drive has 2 braking units with total of 16 braking resistors, so each braking unit uses 8 braking resistors.

  • Page 116: Appendix C Dimensions

    VFD-G Series DIMENSIONS VFD055F43B-G VFD075F43B-G VFD110F43A-G VFD150F43A-G Unit: mm (inches) 200.0 [7.88] 185.6 [7.31] 183.2 [7.22] 7.0 [0.28] DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 117 VFD-G Series VFD185F43A-G VFD220F43A-G VFD300F43A-G Unit: mm (inches) 250.0 [9.84] 10.0 [ 0.39] 205.4 [8.08] 226.0 [8.90] 10.0 [0.39] DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 118 VFD-G Series VFD370F43A-G VFD450F43A-G VFD550F43A-G Unit: mm (inches) 370.0 [14.57] 260.0 [10.24] 335.0 [13.19] 18.0 [0.71] 132.5 [5.22] R6.5[0.25] 13.0[0.51] DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 119 VFD-G Series VFD750F43A-G Unit: mm (inches) 370.0 [14.57] 260.0 [10.24] 335.0 [13.19] 18.0 [0.71] 132.5 [5.22] R6.5[0.25] 13.0[0.51] DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
