- Page 1 MATARA CORNER SOFA DINING SET INSTRUCTION MANUAL IMPORTANT: Please read these instructions before using the product and retain for future use. HHGL Limited, MK9 1BA V1_2023 HHGL (ROI) Limited, D02 X576...
- Page 2 SAFETY & CARE ADVICE： Please read these instructions fully before starting assembly. • This table is made from toughened glass, which is strong but not unbreakable. In the unlikely event that the glass fails, it will break into a large number of small fragments that may be spread over a wide area. This is a feature of toughened glass and is designed to remove the risk of injury from glass breaking into large shards.
- Page 3 0333 003 7084 between 09:00 & 18:00, or use the contact form on our website. www.homebase.co.uk Parts list: Label Part Number Description Part Image Label Part Number Description Part Image Right Left P00140042301 P00140042501 Sofa...
- Page 4 Label Part Number Description Part Image Buckle (Pre-assembly P00220050501 x 23 on B,C,B1,C1,B3.) Metal Bracket H990020017 (Pre-assembly on B.) Note: The below 2 steps are only relevant if the buckle needs replacing in the future.
- Page 5 ASSEMBLY INSTRUCTIONS IMPORTANT INFORMATION Step 1: Open the clip, rotate the triangle hook to a suitable position that the clip lock to the hook base tightly. Step 2: Fix the triangle hook to the hook base. Step 3: Lock the clip tightly.
- Page 6 Disassemble of the clips: Open the clip, then open the triangle hook.
- Page 7 ASSEMBLY INSTRUCTIONS - 3-SEAT SOFA Label Part Number Description Part Image Qty Label Part Number Description Part Image Qty Screw Right P00140042301 M6*25mm H010030021 (Pre-assembly Sofa on B,D.) P00150018701 Back 1 Metal Bracket Sofa Seat P00160032301 H990020017 (Pre-assembly Board 1 on B.) Left P00140042401...
- Page 8 ASSEMBLY INSTRUCTIONS - LEFT-ARM SOFA Label Part Number Description Part Image Left P00140042501 Sofa P00150018801 Back 2 Sofa Seat P00160032401 Board 2 Seat P00180024601 cushion Back P00170015101 cushion Clip P00220050501 (Pre-assembly on B1. C1.) Step 1: Insert latches on back (B1) to sofa seat (C1), then lock the clip tightly. Step 2: Insert latches on left arm (A1) to sofa seat (C1) and sofa back (B1), then lock the clip tightly.
- Page 9 ASSEMBLY INSTRUCTIONS – OTTOMAN Label Part Number Description Part Image Stool P00160032501 Side P00010057501 panel Seat P00180024701 cushion Clip P00220050501 (Pre-assembly on B3.) Step 1: Insert latches on side panel (B3) to side panel (B3), then lock the clip tightly. Step 2: Place stool top (A3) on the top.
- Page 10 ASSEMBLY INSTRUCTIONS - TABLE Label Part Number Description Part Image Qty Label Part Number Description Part Image Qty Screw H010030030 x 10+2 Table M6*15mm P00370004401 H050010025 Washer x 10+2 P00540077801 H090030002 Allen key Support P00500092501 Glass P00210060701 other support and fully tighten all the screws. Step 3: Carefully place the glass D2 to the table rim.
