ControlByWeb X-410CW Quick Start Manual

X-410CW
Cloud Setup & Cell Activation
(For faster setup, we recommend doing this step first)
1. Register or login to your account at: www.ControlByWeb.cloud
2. Choose 'Devices' from the left navigation bar and click 'New Device'.
3. On the New Device page, select the 'Cell Device' tab.
4. Enter a device name, the last 6 digits of serial number, and the Cell ID
(located on the side of the device) and click 'Submit'.
5. You'll be redirected to the Device Edit page. *Click 'Activate SIM Card'.
*Note: If data plan was
purchased separately, first
enter Data Plan Code
(sent via email) & click
'Apply Data Plan'.
Activation may take 15
minutes. Click 'Check SIM
Status' to verify activation.
6. Once activated, power
up the X-410CW.
May take up to 5
minutes to connect.
See users manual for setup instructions:
www.ControlByWeb.com/support/
| Quick-Start Guide
power
supply
+5V
Vin+
Gnd
Rly1
Rly4
4X
Com Common For All Relays
In1+
In4+
4X
Gnd
Data
5Vo
Power Supply Input (9-28VDC)
Power Supply Input (Ground)
Relay 1 Normally Open
4X 4X
Relay 4 Normally Open
Digital Input 1+
4X 4X
Digital Input 4+
Ground for Inputs &
1-Wire Sensors
Data
+5VDC Output
