- Page 1 DRAFT BEER DISPENSER DBF-25SD-SU-AU DBF-25SD-EN DBF-43SD-AU DBF-43SD-T DBF-43WD-SU-AU INSTRUCTION MANUAL 3-16 Minamiyakata, Sakae, Toyoake, Aichi 470-1194 Japan L1B009112 (011017)
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. -
Page 3: Unpacking And Location
I. INSTALLATION O-ring P21 1 pc Measuring Cup 1 pc (-AU type only) Funnel 1 pc (-AU type only) 1. CONSTRUCTION [a] DISPENSER [13] 2. UNPACKING AND LOCATION CAUTION 1. To prevent injury, wear work gloves and hold the bottom [12] panel to carry the unit. -
Page 4: Plumbing Connections
* If the supply cord and/or the plug [1] CO2 gas cylinder should need to be replaced, it Contains CO2 gas to prevent beer from becoming flat and to push should only be done by a qualified beer out of the keg. Consult with the liquor shop or beer company, service engineer. -
Page 5: Trial Run
IMPORTANT [d] EXTERNAL BEER LINE 1. Handle the regulator with care to have no impact on it, or the pressure gauge may not read accurately. 1) Attach the O-ring P10A (accessory) on the beer hose adapter (accessory), and install it on the beer inlet. 2. Stand the CO2 gas cylinder upright, and fix it securely with the accessory chain. - Page 6 II. OPERATION [b] COOLING WATER SUPPLY (-AU type only) IMPORTANT 1. CHECKS BEFORE OPERATION (DAILY) Fill the water tank slowly not to spill water. [a] REPLACEMENT OF CO2 GAS CYLINDER 1) Unplug the unit. 1) Close the main valve of the CO2 gas cylinder. 2) Remove the top cover.
- Page 7 4) Attach the keg coupler on the new keg by turning it clockwise. [b] LEADING BEER TO TAP Keg coupler 1) Check that the regulator adjust dial is set to the appropriate pressure specified by the beer company. 2) Check that the beer tap lever is closed. Opening the keg coupler with the beer tap lever open will cause beer to splash out.
-
Page 8: Maintenance
[d] END OF OPERATION 1) Close the beer circuit before flushing. Rotary type: Turn the keg coupler handle counterclockwise until it 1) Close the keg coupler, and remove it from the keg. Flush the beer stops. circuit according to “III. 1. BEER CIRCUIT (DAILY)” and “III. 4. Vertical type: Unlock and lift the keg coupler handle all the way CLEANING BEER CIRCUIT WITH SPONGE (WEEKLY)”. - Page 9 Keg coupler handle 17) Attach the keg coupler on the keg by turning it clockwise until it stops. Keg coupler Vertical type Rotary type Rotary type Vertical type 12) Check if the cleaning tank is provided with a siphon tube inside. If no siphon tube is provided: Turn down the ferrule of the cleaning 18) Wash the cleaning tank thoroughly, dry it well, and use the cap tank (upside down).
- Page 10 4. CLEANING BEER CIRCUIT WITH SPONGE (WEEKLY) 8) Attach the beer tap on the unit by tightening the union nut. 9) Prepare a plastic bucket under the beer tap to receive drain water. IMPORTANT 1. Store the used cleaning sponge for later use. Cleaning sponge 10) Wash the cleaning tank thoroughly, and fill it with tap water.
- Page 11 19) Recover the cleaning sponge from the bucket. 5) Remove the valve shaft from the beer tap. Valve shaft 20) Repeat the above steps 10) to 16) until clear water comes out of the beer tap. 21) Remove the beer tap, set the valve shaft in its normal position, and refit the beer tap on the unit.
- Page 12 (stains). If any problem is found, contact an authorized 3) Insert the accessory funnel into the pipe at the top of front cover. Hoshizaki service company. 4) Use the accessory measuring cup to pour the cooling water into the water tank [approx.
- Page 13 * In case of relocation or disposal of the product, contact an authorized Hoshizaki service company. * When selling or transferring this product, tape this instruction manual to the exterior to provide the new owner with information on...
