- Page 1 NETWORK VIDEO RECORDER Quick Guide XRN-426S...
-
Page 2: Part Names And Functions (Front)
English Package Contents Part Names and Functions (Front) ■ The appearance of the components may differ from the image shown. ■ Accessory category and quantity may differ depending on sales region. Name Functions Recorder Mouse Quick Guide POWER : Shows the power ON/OFF status. NETWORK : Displays both network connection and data transfer status. -
Page 3: Installing The Product
Installing the Product Method 2 (installation on a wall) You can install the product by standing it up using a bracket or mounting it on a wall. Mount two brackets to both sides of the Fix the recorder on the wall with four screws. recorder with four bracket mounting screws. - Page 4 Using a Multi-adaptor Align the screws on the bottom of the product to Push the product into the multi-adaptor and lower fit into the screw hole of the multi-adaptor. it for fixing. The product can be installed with a multi-adaptor mounted. The multi-adaptor has a hole that meets VESA ■...
-
Page 5: Connecting To An External Device
Connecting to an External Device Connecting the Alarm Input/Output The Alarm In/Out port at the back is composed of the following. Alarm Sensors ALARM IN 1 ~ 4 : Alarm Input Port ● ALARM OUT 1 ~ 2 : Alarm Output Port ●... -
Page 6: Connecting The Network
Connecting the Network Connecting to the Network Using a Router If you want to add 1-3 PCs and recorders in an environment using xDSL/Cable modem, you can use the router ■ For more information about network connection, see "Setting the Network" in the User Manual. with only one Internet line. - Page 7 Connecting the Network Cameras Using Product Information You can check the product information/manual/firmware information/FAQ/HDD compatibility list on the homepage Example 1) or mobile web of your smartphone. IP : 192.168.231.100 http://www.HanwhaVision.com http://www.HanwhaVision.com Network Camera IP : 192.168.231.10 Example 2) NETWORK 1 IP : 192.168.1.200, NETWORK 2 IP : 192.168.231.200 Switch Switch Network Camera...
- Page 8 The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. Hanwha Vision cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.
