  • Page 1 NETWORK VIDEO RECORDER User Manual Wisenet NVR...
  • Page 2 ™ Design and specifications are subject to change without prior notice. You can download the latest version from the Hanwha Vision web site. (www.HanwhaVision.com) ™ The initial administrator ID is “admin” and the password should be set when logging in for the first time.

  • Page 3: Product User Manual Description

    • Monitor real time events that occur in Wisenet Recorder, sensors, and cameras or search through logs normally, or has been dropped. Before using this product, check if the latest version of this software is installed. Go to Hanwha Vision's website (http://www.HanwhaVision.com) to check the software version and download necessary files.

  • Page 4: Table Of Contents

    overview contentS StartIng web vIewer What is Web Viewer? Connecting Web Viewer overvIew Important Safety Instructions Product User Manual Description Target Audience lIve vIewer How to Use the Product Live Viewer Contents Control of connecting Network Camera lIve Getting Started SearcH vIewer Search viewer Live Screen Configuration...

  • Page 5: Live

    live gettIng Started Install wizard As shown below, proceed through each step of the <Install wizard>. Starting the system Install Wizard can only be accessed at factory reset. If you do not want to proceed, click <cancel>. 1. In the <language> screen, select the language and press the <next> button. 1.
  • Page 6 live 3. Set the administrator password on the <recorder Id/pw> screen and click the <next> button. If the LAN cable is not connected to the port, the setting button will not be activated for use. Check the LAN cable connection. (But in case of a PoE product, Network 1 is activated.) Click <...
  • Page 7 Shutting down the System 6. To set the recommended resolution on the <resolution> screen, click <apply> followed by the <next> button. 1. In the live screen menu, select <Shutdown>. 2. The “Shutdown” confirmation pop-up window will appear. 3. Click on <ok>. The system will shut down.

  • Page 8: Live Screen Configuration

    live lIve Screen confIguratIon login To use the Recorder menu, you are required to login as a user that is authorized to access the applicable menu. Icons on the live Screen 1. Right click with your mouse button on the live mode screen. You will see the context menu on the screen as shown.
  • Page 9 error Information Name Description • If the built-in HDD is not connected, the “NO HDD” icon ( ) will be displayed in the top left corner. In this It is displayed when there is firmware to update the server. RAID RAID SCSI case, make sure you contact the service center for assistance as this may cause a failure of recording,...
  • Page 10 live Split mode menu Menu Description In Live split mode, right-click to display this context menu as shown. Searches for a backup device and back up each channel at your desired time. Backup Live > Backup The look of the split mode menu is different for each Recorder product and it also depends on the login/logout See the "...

  • Page 11: Live Screen Mode

    lIve Screen mode view the launcher menu The Launcher menu appears on the bottom of the live screen. You can display your camera's live video in various split modes. 1. Select <Show launcher> in the context menu of the Live screen. The ‘Live4NVR’...

  • Page 12: Status

    CH11 CH11 CH11 CH12 CH12 CH12 CH10 CH11 CH12 CH13 example) after setting to 4-split mode in lrn-1610S, if you press the right [►] button: CH13 CH13 CH13 CH14 CH14 CH14 CH15 CH15 CH15 Channel(CH 1~4) ; Channel(CH 5~8) ; Channel(CH 9~12) ; Channel(CH 13~16)
  • Page 13 connection Status record Status Right-click on the live screen and select <connection> in the <Status> menu to check the status of cameras Right-click on the live screen and select <record> in the <Status> menu to check each channel's profile, connected to each channel. record type, input/recording frame count, allowed/input/recorded amount of data.
  • Page 14 CH10 CH11 CH12 CH10 CH11 CH12 CH13 CH14 CH15 CH13 CH14 CH15 live CH10 CH11 CH12 CH12 CH10 CH11 CH12 CH16 CH16 CH13 CH14 CH15 CH16 CH16 CH13 CH14 CH15 CH16 network Status channel Setting Right-click on the live screen and select <network> in the <Status> menu to check the status of network You can display the channel in a desired area of a split screen.

  • Page 15: Zoom

    Zoom layout This is activated only in Live Single mode. In the live screen, you can set the layout for each channel. 1. After right-clicking on the live screen, click <Zoom>. Setting up the live layout You can also press the [Zoom] button on your remote controller or click < >...

  • Page 16: Audio On/Off

    live audIo on/off event monItorIng You can turn the sound on/off corresponding to the channel in Live mode. This will display the channel in sync with a specific event (Sensor/Motion/Video Loss) if it occurs. To use the event monitoring function, you should set the <event display> by referring to the "monitor" page in the CH19 audIo on/off in Single mode table of contents "menu Setup >...

  • Page 17: Capture

    maIntaIn tHe Screen ratIo Select <Alarm Stop> to initialize the status of alarm output and release the event function. If your product supports a remote controller, then press the [ALARM] button to reset the alarm output status. For products that support remote controls, see page 4 “Products supporting each feature” of the Product Specification The screen ratio for a live video can be changed.

  • Page 18: Display Text

    Even if the connected network camera does not support the PTZ operations, you can configure the PTZ control settings (if possible) by installing the PTZ driver (physical device). It supports only the Hanwha Vision PTZ function network camera and ONVIF registration network camera. 18_ live...

  • Page 19: Backup

    using digital ptZ (d-ptZ) function to change or delete a registered preset 1. Register a camera that supports the D-PTZ profile. In cameras that support the D-PTZ profile, you can use the D-PTZ function. 2. Both cameras that support general PTZ and cameras that support D-PTZ can control the live image using some of the <ptZ control>...
  • Page 20 live • Backup Range : Sets the <Start> and <end> time for the backup. - Start time : Set the backup start time to your desired time. If you click the [Start] button, the Backup start time is set to the starting time of the last video recording. However, the Start time will not be displayed on the screen.

  • Page 21: Menu Setup

    menu setup Sets the camera, recording, event, device, network, and system environment. • Holiday : A user can select specific dates as holidays according to their own preferences. Holidays are applied in the <Recording Schedule> or <Alarm Schedule> setting too. SyStem Setup You can setup Date/Time/Language, User, System Properties and Log.
  • Page 22 menu setup user user setting You can create a group or set permissions for each group. You can set permissions of each user over the Recorder's specific function and settings. You can add a user and edit the registered user information. Setting the Administrator menu >...
  • Page 23 Setting permissions If you want to register a user You can set restricted access for all general users. Items with restrictions will require logging in for use. menu > System > user > permission Setup 1. Click on the [ ] button to launch the user addition popup window.
  • Page 24 menu setup If the user has restricted access System management If a new group is restricted to access the entire menus, the users belonging to the group can access only the You can check the system version, update to a newer version, as well as data backup and initialization. basic menus and can change only their respective password.
  • Page 25 Settings to upgrade the current software version You can copy and import the Recorder settings by using a storage media. menu > System > System management > Settings 1. Connect a device storing the software to be updated. It may take about 10 seconds to recognize the device. Upgradeable devices include USB memory, and network device.
  • Page 26 menu setup Log Information Checking the event log You can search recorded events including alarms, camera events and video loss. You can browse logs on the system and events. It also shows the log and its timestamp. Checking the system log menu >...

  • Page 27: Setting The Camera

    SettIng the CAmeRA Checking the backup log You can find out who backed up and the details (backup time, channel, device to use, file format, etc.). Sets the contents related to the camera, channel, profile, and camera password. menu > System > Log Information > Backup Log Setting the Channel You can register a network camera for each channel and make connection between.
  • Page 28 - Wisenet Camera : You can register Hanwha Vision's cameras and encoders. have to change the camera ID/password information registered in Recorder. - Wisenet Multi-Channel : You can register Hanwha Vision's multi directional cameras and multi-imager cameras. A multi-channel camera is a camera that has multiple camera modules in one body.
  • Page 29 If you want to check the error details of camera registration • Address type : Select an address type of the camera. If you failed to register a camera, the reason for the failure will be displayed. The supported address type may differ depending on the type of the connected product. •...
  • Page 30 menu setup network Camera Firmware upgrade OnVIF Setup In the bottom of the camera addition screen, click on the <OnVIF> button to set additional settings for cameras with the ONVIF protocol. You can change the information only if the user account (camera account used for camera registration) is used to read the user information and a connection is made with the admin privilege.
  • Page 31 event Focus You can set details of the event. You can adjust the focus of you camera's video. You can set focus, zoom in, simple focus, and focus reset. • Available events (camera) : It shows the list of all the events supported by a camera by using the ONVIF protocol.
  • Page 32 menu setup Setting the Live profile Setting the Remote profile You can change the live transfer settings of the network camera. You can set the video profile transmitted to the network. menu > Camera > profile > Live menu > Camera > profile > Remote •...
  • Page 33 editing the profiles Dewarping Setup Press the <Dewarping> button at the bottom of the <Detailed profile configuration> window to go to the You can change the video settings of a registered network camera for each channel. distortion correction setup popup window for each channel. menu >...
  • Page 34 menu setup Setting Camera password Dynamic gOV/FpS setup Dynamic GOV can be used to automatically change the length of GOV depending on the video condition. For You can change the passwords of all registered cameras at once. more information, see help for your camera or the product user manual. You can register the camera’s ID and password.

  • Page 35: Setting The Device

    SettIng the DeVICe • Status : Displays the current working condition of a storage device. To create an HDD alarm for inspection or replacement, see the "hDD Alarm Setting" page under "menu Setup > Setting the Device" in the Table of Contents. You can set the options for storage device, remote device, monitor, and text.
  • Page 36 menu setup hDD Alarm Setting Remote Devices For HDD malfunctions, you can set the inspection alarm output terminal, the replacement alarm output terminal This function is only available for products that support the use of a remote controller. For products that support and the alarm time.
  • Page 37 monitor expansion monitor settings This function is only available for products that support the use of an extended monitor. You can set the information displayed on the monitor as well as the output system. For products that support extended monitor, see page 4 “products supporting each feature”of the Product Specification Manual.
  • Page 38 menu setup text Display position settings Some monitors many not display information (camera name, icon, time information, etc.) about the Recording, Device and events can be set up. depending on the condition. Then, you can change the display position of the data. Device Settings Relevant values of a device connected to Recorder can be set.

  • Page 39: Setting The Recording

    SettIng the ReCORDIng event Settings You can set up event keywords. You can setup scheduled recording, event recording and other recording related settings. menu > Device > text > event Recording Schedule Make your reservation on a date and time to schedule the recording on specified time. menu >...
  • Page 40 menu setup Record Setup Record Option You can set resolution, IPS, and quality of recordings by channel, and by recording type of standard / event. When the HDD capacity is full, you can set whether to stop recording or start overwriting. You can check frame rates and data transfer amount of Full Frame and Key Frame recordings for each channel, menu >...

  • Page 41: Setting The Event

    SettIng the eVent Camera event You can set the activation of events (motion detection, video analysis, audio event) sent from the camera, alarm You can make the setup for record in case of sensor detection, camera event or video loss detection. output method and alarm time.
  • Page 42 menu setup motion detection setup Video Analysis Setup • Area : Click the Setup button to set a motion detection area. • Area: Click the Setup button to set a video analysis area. • MD Type : You can set a detection area and a detection excluded area. •...
  • Page 43 tampering detection Video Loss Detection You can set up an event signal when camera tampering is detected, such as when the screen is obstructed or You can set the camera so that the camera can trigger the alarm if it is disconnected or the video is lost due to the camera location is changed.

  • Page 44: Network Configuration

    menu setup netWORK COnFIguRAtIOn Alarm Out Schedule You can set the conditions and operating hours for scheduled alarms. It provides networked monitoring of Live screen from a remote place, and supports mail forwarding function with events. You can configure the network environment which enables such functions. menu >...
  • Page 45 Connecting and Setting the network • Setting the DhCp Ip Address of the Broadband Router 1. To access the Broadband Router's configurations, open a web browser on the local PC that is connected Networking may differ from the connection method, check your environment before setting the connection to the Broadband Router and enter the router's address (ex : http://192.168.1.1).
  • Page 46 menu setup DDnS to check Quick Connect status A progress bar and its message appears for a Quick Connect. If a remote user accesses the network, you can set whether or not to use DDNS and the site to be connected. •...
  • Page 47 Ip Filtering You can prepare the list of IP addresses to allow or block access to a specific IP address. You can select a security connection system or install public certificates. menu > network > Ip Filtering menu > network > SSL •...
  • Page 48 menu setup 802.1x e-mail When connecting to a network, you can select whether to use the 802.1x protocol and install a corresponding You can send an e-mail to a Recorder-registered user at a specific time interval, or if an event occurs. certificate.
  • Page 49 event Setting Snmp You can set the interval and type of the event that will be sent to the user. Using the SNMP protocol, the system or network administrator can monitor the network devices remotely as well as the operating environment. menu >...
  • Page 50 menu setup DhCp Server You can set the internal DHCP server and assign an IP address to the network camera. This function is only available for products that support P2P. For products that support P2P function, see page 4 “products supporting each feature” of the Product Specification Manual. network Setting When using P2P service, Recorder can be used by connecting to mobile web viewer.

  • Page 51: Search & Play

    search & play SeARCh 3. The record data on the specific date will be listed. The display bar is different according to the data type. So check the data type for the color in the left pane. You can perform the search for recorded data by the time or by the search criteria such as an event. If DST (Daylight Saving Time) is configured, overlapping multiple recordings may be produced for a certain moment of time.
  • Page 52 search & play Smart Search text Search You can select a specific area of the image as an area of interest or exclusion using a virtual line to perform a You can search data that was entered into POS systems connected to Recorder. search of events that have occurred in a specific time period.
  • Page 53 Backup Search ARB Search Searches for backup data in the connected backup device. You can search ARB data and export it to a file on your preferred storage device or play it back. Only data in the format of Recorder is included in the search. 1.

  • Page 54: Playback

    search & play pLAyBACK using the playback Button play You can play data stored in the HDD and backup a desired portion of the data. b c d e f g h i j k l m n o p q Name Description Play Timeline...

  • Page 55: Starting Web Viewer

    starting web viewer What is Web VieWer? ConneCting Web VieWer 1. Open your web browser and type the IP address or URL of Recorder into the URL address box. WebViewer is a software program with which the operator can access a remote Recorder for real-time monitoring, PTZ control (if configured) or search.

  • Page 56: Live Viewer

    Video window Shows the video of the camera connected to the recorder. The ID of the connected user is displayed. You are directly connected to the Hanwha Vision homepage (www.HanwhaVision.com). Changes the color theme of Web Viewer. System status display Displays the status of the system, hard disk, and network.
  • Page 57 Checking the system status Camera Layout setup The icon at the top of the screen indicates the status of the system. Check Camera List Name Description Displays the camera type, status, and name registered in the recorder. Displayed when a problem occurs with the pan or recording status. Monitoring >...
  • Page 58 live viewer Layout setup Check event list According to the purpose of use and convenience, the desired channels can be grouped in a layout so that Check event list they can be checked immediately when needed. Monitoring > List Check the event list set under setup > Device > text > event. Monitoring >...
  • Page 59 Video export Check the recorded video status Click the < > button, followed by the <record> tab. You can back up the recorded video by manually inputting the desired channel, date, and time. You can check the profile, recording type, input/recording rate, and setting/input/recorded data rate by channel. 1.
  • Page 60 live viewer Capture Using PtZ You can control PTZ of the selected channel. Select a channel to capture video and click the < > button. Select a channel and click the < > button. The captured image is saved as .png file in the download folder. The PTZ control screen will appear.

  • Page 61: Control Of Connecting Network Camera

    ControL oF ConneCting netWorK CaMera to utilize the digital PtZ (D-PtZ) function 1. Register a camera that supports the D-PTZ profile. PtZ Control You can utilize the D-PTZ feature only for cameras that support the D-PTZ profile. 2. In addition to cameras that support normal PTZ, cameras that support D-PTZ can also control Live video If the connected network camera is a PTZ camera, the <...
  • Page 62 search viewer searCh VieWer Name Description You can search and play the recorded video stored in the recorder by connecting the recorder remotely. Turns on/off the section setup. Configuration of search Viewer screen Saves the video of the selected channel in the designated path in AVI format. time search screen The date of the recorded video is displayed in orange, and the current date is displayed in a Calendar...
  • Page 63 search for time text search screen You can search recorded data by setting the desired date and time. to search by date You can use the calendar to select a search date. 1. Click <<,>> to select the year and month to search. Dates with data appear in orange, and current dates appear in orange circle.
  • Page 64 search viewer export search results text search You can export the searched results to a file. You can search data entered into the POS device connected to the recorder. 1. Click the [ ] button. to search text 2. Select a layout to export, and select a channel you want. 3.
  • Page 65 to play text search Play button names and functions Select the desired list from the text search list to check the recorded video and details. Pause status Play status Name Description Previous Event Moves back by event. to adjust the time line Backward Moves to Step Backward.

  • Page 66: Setup Viewer

    setup viewer setUP VieWer system You can configure the various settings of the Recorder system. You can configure the Recorder settings remotely on the network. To configure the Recorder settings, click <setup>. settings screen Date/time/Language See the "setting the Date/time/Language" page under "Menu setup > system setup" in the Table of Contents.
  • Page 67 User system Management See the "User" page under "Menu setup > system setup" in the Table of Contents. See the "system Management" page under "Menu setup > system setup" in the Table of Contents. administrator system information You can change the admin ID or the password. You can see information of the current system.
  • Page 68 setup viewer Log information Camera system Log You can check a list of cameras that are connected to the Recorder and configure the necessary settings. Click <Camera> in the menu screen. Data recorded in the system log displays various system-related logs/date/time such as system starts, system For more detailed setup, see the "Menu setup >...
  • Page 69 Recorder. If you want to change the proxy port, then select the port setup menu. - 4 channels (10001-10004), 8 channels (10001-10008), 16 channels (10001-10016) Example) Defaults of cam proxy ports for each product • LRN-1610S, QRN-1620S (16 channels) : 10001-10016 • LRN-810S, QRN-820S (8 channels) : 10001-10008 remote •...
  • Page 70 setup viewer Camera Password hDD alarm You can set the alarm output port and the duration in case an error occurs. You can change the passwords of all registered cameras at once. Monitor Device You can configure the monitoring screen settings and set the output system. You can check a list of devices that are connected to the Recorder and configure the necessary settings.
  • Page 71 text record Device For more detailed setup, see the "Menu setup > setting the recording" page in the Table of Contents. Relevant values of a device connected to Recorder can be set. recording schedule If you set a recording schedule for a specific date and time, the recording will start at that specific time. event It is possible to set total amount conditions and keywords to display events of a text device.
  • Page 72 setup viewer Video Loss Detection event You can set to trigger the alarm if a video loss occurs. For more detailed setup, see the "Menu setup > setting the event" page in the Table of Contents. sensor Detection recorder / Camera This function is only available for products that support alarm function.
  • Page 73 network DDns You can set DDNS. For more detailed setup, see the "Menu setup > network Configuration" page in the Table of Contents. interface A remote user can access the Recorder via the network to check the current mode and the IP address. network Specify the network connection path.
  • Page 74 setup viewer 802.1x recipient You can set groups and recipients to receive emails. When connecting to a network, you can select whether to use the 802.1x protocol and install corresponding certificate. snMP e-mail Using the SNMP protocol, the system or network administrator can remotely monitoring the network devices and sets the environment.
  • Page 75 DhCP server network You can set the internal DHCP server and assign an IP address to the network camera. Check iP You can check the IP and MAC currently used through the DHCP server, and the connected network port. This function is only available for products that support P2P. For products that support P2P function, see page 4 “Products supporting each feature”...

  • Page 76: Backup Viewer

    backup viewer backup viewer seC baCKUP VieWer f g h i You can play a file that is backed up in the format of SEC. Backup in SEC format produces backup data file, library file and self-executable viewer file. If you run the backup file viewer, the backup data file will be played. Recorder_CAM 01 2019-01-01 16:17:49 VIDEO:H264(2048x1536)/AUDIO:NONE...
  • Page 77 Item Description Enlarge the image by up to 100 times as big as the current one. Press the Zoom In ( ) button the enlarge the image; press the Zoom Out ) button to shrink the image. You can also use the slide bar ( ) in the pop-up window to zoom in/out.

  • Page 78: Using A Remote Controller

    appendix Using a reMote ControLLer Using the numeric buttons CHANNEL 1–9 This function is only available for products that support the use of a remote controller. For products that support Press each button between 1 to 9. remote controls, see page 4 “Products supporting each feature” of the Product Specification Manual. CHANNEL 10 Press the [+10] button first, then press the 0 button again within 3 seconds.

  • Page 79: Use Joystick

    Use JoYstiCK Using VirtUaL KeYboarD The function is only available for the product that supports a joystick. For products that support joy stick, see page 4 “Products supporting each feature” of the Product Specification Manual. The SPC-2000/2001 joystick is operated as follows: 1.

  • Page 80: Troubleshooting

    appendix troUbLeshooting Problem Action Problem Action The camera is not connected or the PC fails to connect y Check if the network cable is connected properly. to the product. y Ensure that you have set Network – Connection Mode. Live video will be slow or cut off. y The frame number set for multiple data transmission set in camera or y Check the IP setting of the PC or camera.
  • Page 81 Problem Action Problem Action Backup data is just not played by the PC or Recorder. y When you are backing up data, you have choices about the player either: PC Recording is not performed in accordance with the y If the recording status displays 'Exceeds the maximum hard disc or Recorder.
  • Page 82 Hanwha Vision cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Vision's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
