- Page 1 CABINET User Manual SBP-150NBW...
- Page 2 Cabinet User Manual Copyright ©2024 Co., Ltd. All rights reserved. Hanwha Vision Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
- Page 3 ~ Use only the accessories or camera that are compatible with this product and comply with its technical specifications. ~ Hanwha Vision do not guarantee the quality of third-party products purchased separately. ~ When cleaning the product surface, use only a clean, soft cloth moistened lightly with isopropyl alcohol (IPA) or water.
- Page 4 COMPONENT As for each sales country, accessories are not the same. Appearance Quantity Description Main body Bracket for installing the main body User Manual T20, M4 X L10 For camera installation (Use the double gang) S6, M8 X L25 For mount installation...
- Page 5 COMPONENT Appearance Quantity Description T20, M4 X L8 For installation of internal accessories DIN35 rail M20 cable bushing for ø5 to 6.5 ※ Spare part Cable adapter for ø2 to 6 ※ For a cable gland Cable clamp for ~ ø10.6 Cable clamp for ~ ø6.8 Cable clamp for ~ ø3.3...
- Page 6 OVERVIEW Bracket for installing the main body ~ Main body installation and disassembly positions guide ~ Knock-out ~ Knock-out M25 (3/4”), 3 EA M25 (3/4”), 3 EA M20 (1/2”), 2 EA M20 (1/2”), 2 EA ~ Main body assembly guide ring, 4 EA ~ Screw holes for wall and pole ~ Main body fixing tab M6 (0.24”), 2 EA mounting ø9 mm (0.36˝), 6 EA...
- Page 7 OVERVIEW Front of main body ~ Door fixing screw T30, 4 EA ~ M16 cable bushing 2-hole for I/O cable ~ M20 cable bushing for LAN cable ~ M8 (0.32”), 4 EA ~ M4 (0.16”), 4 EA/EACH 86 x 130mm Double gang...
- Page 8 OVERVIEW Inside the main body ~ Din35 structure ~ M25 drill-out 1 EA ~ M20 cable bushing 3 EA for ø5 to 6.5 ~ Main body fixing screw T30, 2 EA ~ M16 cable gland 2 EA for ø4.5 to 10 ~ Door movement range 0 to 105 degrees ~ Air vent...
-
Page 9: Installation
INSTALLATION 3-192mm (7.68”) ~ Screw holes for wall and pole mounting ø9 mm (0.36”), 6 EA. ~ Knock-out M25 (3/4”), 3 EA M20 (1/2”), 2 EA ~ Knock-out M25 (3/4”), 3 EA M20 (1/2”), 2 EA ~ Remove knock outs for floor or wall (as needed) - Page 10 INSTALLATION ~ Installing on wall ~ Not included ~ Installing on pole mount ~ Included on pole mount...
- Page 11 INSTALLATION...
- Page 12 INSTALLATION...
-
Page 13: Cable Connection
INSTALLATION Cable connection ~ Electrical cables must be installed by a qualified person in the electrical field. During installation, be sure to follow local regulations of your country or region. ~ The power supply must be connected from the main supply after installation. ~ Signal or power cables must be separated and tidied up in the cabinet. - Page 14 INSTALLATION 2.0N.m (1.4lb.ft)
- Page 15 INSTALLATION 2.0N.m (1.4lb.ft)
-
Page 16: Camera Installation
INSTALLATION Camera installation ~ Be sure to install the camera or other items with the door closed. ~ Do not leave the door open for a long time with the camera or other items mounted. - Page 17 INSTALLATION Mount installation...
- Page 18 Подлежит использованию по назначению в нормальных условиях Срок службы : 7 лет. Türkiye Distribütörü EDS Elektronik Destek Sanayi ve Ticaret Ltd. Şti. Meclis Mah. Teraziler Cad. Hayran Sk. (Eskisi Kılıç Sk.) No: 4 Sancaktepe / İstanbul / Türkiye Tel +90.216.313.25.15 ENTES ELEKTRONİK CİHAZLAR İMALAT VE TİC.
