Summary of Contents for Avantree Audikast Plus
- Page 1 Audikast Plus User Manual Model No.: BTTC-418-P-BLK...
-
Page 2: Table Of Contents
User Manual AUDIKAST PLUS Table of Contents Box Contents 3... -
Page 3: Box Contents
User Manual AUDIKAST PLUS Box Contents Audikast Plus - Bluetooth Digital Optical Transmitter Audio Cable AUX 3.5mm AUX 3.5mm to Audio Cable RCA Adapter USB C power cable Adhesive Pad... -
Page 4: Product Introduction
User Manual AUDIKAST PLUS Product Introduction Product Overview Volume control button Audio input Codec indicator indicator Pairing button for Pairing button for AD APT X 2nd headphone 1st headphone Bluetooth status Bluetooth status for 1st headphone for 2nd headphone ON/OFF... -
Page 5: Button Functions
User Manual AUDIKAST PLUS Button Functions Button Fuctions Switch to “ON” to turn it on ON/OFF Switch to “OFF” to turn it off Press and hold for 5s to enter pairing mode for headphone Press and hold for 10s to lock the 1... -
Page 6: Setting Up
Once the Audikast Plus is connected to a power source, you can then connect it to your TV's audio ports. You can choose one of 3 different ways to do this:... - Page 7 User Manual AUDIKAST PLUS OPTION 1 Optical port (recommended) Plug the provided optical cable into the TV’s “optical OUT”or “OPT OUT” port, then plug the other end into the transmitter’s optical port. OPTION 2 AUX 3.5mm port Plug the provided AUX 3.5mm audio cable into the TV’s AUX 3.5mm output port, then plug the other end into the...
- Page 8 User Manual AUDIKAST PLUS OPTION 3 RCA port Attach the RCA adapter to the AUX 3.5mm audio cable. Plug the red & white connectors into the TV’s “AUDIO OUT” ports, then plug the other end into the transmitter’s AUX 3.5mm port.
-
Page 9: Connecting Your Headphones
User Manual AUDIKAST PLUS Connecting Your Headphones Now that your Audikast Plus is all set up, you can connect your headphones to the transmitter. STEP 1 First, power everything on. STEP 2 For first time use, the Audikast Plus will enter PAIRING MODE automatically once turned on;... - Page 10 Bluetooth devices in its vicinity. If your TV prompts you to connect your Bluetooth headphones or the Audikast Plus, please “DENY” the request so that your device can properly pair with the transmitter. Avantree Audikast Plus Your permission is require d to connect your device to TV.
-
Page 11: Setting Up Your Tv
User Manual AUDIKAST PLUS Setting Up Your TV (FOR OPTICAL CONNECTIONS ONLY) If you connected to your TV via the optical OUT or “OPT OUT” port, you’ll need to configure your TV settings before you’ll receive audio. STEP 1 Using your TV’s remote control, press the SETTINGS button and navigate to the AUDIO tab within the settings menu. -
Page 12: Advanced Feature
Visit avantree.com/audikast/ video if you’d prefer to watch a video guide on this process. STEP 1 Pair your first pair of headphones to the Audikast Plus by following the steps in the “Connecting Your Headphones” section (Page 9). - Page 13 User Manual AUDIKAST PLUS STEP 2 Once your first device is successfully connected, put your Audikast Plus into PAIRING MODE once again by pressing & holding the button until the next to flashes red and blue alternately. STEP 3 Get your second pair of headphones into pairing mode.
-
Page 14: Reconnecting Your Headphones
NOTE: If you paired your headphones with a different Blue- tooth device, turn Bluetooth OFF on said device(s). Airpods in particular will always prioritize iPhones for automatic pairing, so you’ll need to turn your iPhone’s Bluetooth OFF when pairing your Airpods with the Audikast Plus. -
Page 15: Specifications
User Manual AUDIKAST PLUS Specifications Bluetooth version Bluetooth 5.3 Bluetooth profile A2DP, AVRCP aptX-adaptive, aptX Low Supported Codec Latency, aptX, SBC Supported Audio format in PCM / LPCM OPT mode Operating range Up to 100ft / 30M Product dimension 6.5cm*5.5cm*1.5cm Rated Input: DC5.0V/500Ma~2A... -
Page 16: Faq
TV is capable of this or not -- please refer to avantree.com/audikast/sound for more details. Why am I getting audio delay? Both the sender (i.e. the Audikast Plus) and the receiver (i.e. your Bluetooth headphones) must support either aptX Low Latency in order to eliminate audio latency. You can check your device’s specs to ensure it supports either of these... -
Page 17: Contact Us
User Manual AUDIKAST PLUS Contact Us Support Tickets avantree.com/submit-a-ticket Support Email support@avantree.com Support Numbers US +1 800 232 2078 9am-6pm PST Mon-Fri CA +1 800 232 2078 9am-6pm PST Mon-Fri UK +44 208 068 2023 9am-6pm GMT Mon-Sat DE +49 322 2109 7297 11am-9pm CET... - Page 18 Manufacturer: Avantronics Limited Luohu District, Shenzhen 518000 China + 86 755 8228 5022 support@avantree.com US Importer: Avantree Corporation San Jose, California 95119 USA +1 800 232 2078 support@avantree.com UK Importer: Avantree Limited Watford, WD180 0HQ UK +44 20 8068 2023 support@avantree.com Servicer in Europe: Gizmex GmbH,...
