SMART
TV
AAA
Replacement Remote for
2. Package Contents
SAMSUNG SERIES: TV/LCD/LED/HDTV
• Replacement Remote Control
• 2x AAA Batteries
• This operating instructions incl. Code List
3. Safety notes
• Do not use the Universal Remote Control in
Thank you for your decision for a Thomson product.
moist or wet environments and avoid spray-
Take your time and read the following instructions
water contact.
and information completely. Please keep these
• Do not expose the Universal Remote Control
instructions in a safe place for future reference.
to heat sources or direct sunlight.
This remote control can by default control 90%
• Do not drop the Universal Remote Control.
models of SAMSUNG brand, there´s no need to set
• Never open the Universal Remote Control. It
it up. lf the remote doesn't work, please choose
contains no user-serviceable parts.
one of the setup methods described in chapter 5.
• As with all electrical devices, keep the
Universal Remote Control away from
The keys
children.
1. Input signal source / Indicator LED
2. POWER TV ON / OFF
3. Switch to signal source PC
Warning
4. Switch to signal source TV
5. Switch to signal source HDMI
• When inserting batteries, note the
6. Numeric keys 0 – 9 to enter channel
correct polarity (+ and - markings) and
numbers
insert the batteries accordingly. Failure to
7. Previous channel
do so could result in the batteries leaking
8. Access to 2- or 3- digit channel numbers
or exploding.
9. TV Mute
• Do not short-circuit batteries.
10. Channel up/down
• Do not charge batteries.
11. Teletext ON / OFF / MIX
• Do not throw batteries in a fire.
12. Smart TV Menu
13. Change your TV's volume
• Keep batteries out of the reach of
14. Media Player
children.
15. Program Guide
• Do not allow children to change batteries
16. Program MENU
without supervision.
17. TOOLS MENU
• Remove the batteries from products
18. On-Screen Info
that are not being used for an extended
19. Use when watching TV to see what's on
period.
other channels or to highlight/Select
On-Screen options
4. Getting started – installing the Batteries
20. Return / Back key
21. Turn off the menu of the selected product.
22. Use to select a variety of on screen options
Note
23. Sound Mode
24. Picture Mode
• Use 2 AAA batteries
25. Multi Sound
• Remove the battery cover from bottom
26. Favorite Channel
of remote.
27. Picture Size
• Check the +/- polarity on the batteries
28. 3D Mode ON/OFF
and inside the compartment.
29. Suspends play and stops on an image
• Insert the batteries.
(DVD, BlueRay...)
• Slide the battery holder back into the
30. Fast Forward (DVD, BlueRay ... )
remote until the clips locate.
31. Goes backward (DVD, BlueRay ... )
32. Stop the disc (DVD, BlueRay ... )
PIP (Picture in Picture)
Note – Code Memory
33. Play a disc (DVD, BlueRay ... )
PIP Position
34. Record
This remote control saves the settings during
SWAP PIP
battery change.
1. Explanation of the Note and Warning
5. Setup
symbol
This remote control can by default control 90%
models of SAMSUNG brand, there´s no need to
Warning
set it up. lf it doesn't work, please choose one
of the following setup methods 5.1 or 5.2.
This symbol is used to indicate safety instructions
or to draw your attention to specific hazards
and risks.
Note
This symbol is used to indicate additional
information or important notes.
2
5.1 INPUT CODE
5.4 Compatible Remote Control Model
CODE List:
Due to too many Remote Control models, we
only Iist some of them below.
001, 002, 003, 004, 005, 006, 007, 008,
lf your remote control is similar to the drawing,
009, 010, 011, 012, 013, 014, 015, 016
the replacement remote can control your TV
(Page 38).
1.
Press and hold the key [MUTE] and
[POWER] until the LED will be lit,
6. Maintenance
then release keys.
• Do not mix new and used batteries for
powering the Universal Remote Control, as
old batteries tend to leak and may cause
power drain.
• Do not use corrosive or abrasive cleansers on
your Universal Remote Control.
2.
Enter the three codes from code Iist.
• Keep the Universal Remote Control dust free
When the code input is finished, the
by wiping it with a soft, dry cloth.
LED will turn off.
7. Troubleshooting
Q. My Universal Remote Control does not
work at all!
A. Check your TV. If the TV main switch is
turned off, your Remote cannot operate
your TV.
A. Check whether your batteries are inserted
3.
Please try to use the remote control.
properly and are in the correct +/- position.
lf it doesn't work well, please try other
A. If the batteries are low, replace the
codes: [002], [003], [004] ...
batteries.
Q. My TV responds only to some of the
commands.
Note
A. Try other codes until most keys work
properly.
lf the code is invalid, the LED flashes twice
and then lights up permanently. To exit the
8. Warranty Disclaimer
setup, please press [MUTE].
The manufacturer assumes no liability and
provides no warranty for damage resulting
5.2 FAST SEARCH
from improper installation/mounting, improper
1.
Press and hold the key [MUTE] and
use of the product or from failure to observe
[POWER] until the LED will be lit, then
the operating instructions and/or safety notes.
release keys.
9. Service and Support
Please contact Hama Product Consulting if you
have any questions about this product.
Hotline: +49 9091 502-115 (German/English)
2.
Press the key [ CH+]. Each time you
Further support information can be found here:
press, the remote will search once.
www.hama.com
When the code changes, you can test
if [POWER], [VOL+],[MENU],[0-9] keys
10. Recycling Information
work well. If ok ,please press [ MUTE] to
Note on environmental
save the code and exit.
protection:
After the implementation of the
3.
lf it doesn't work well, repeat the fast
European Directive 2012/19/EU and
search by pressing [ CH+].
2006/66/EU in the national legal
system, the following applies: Electric and
5.3 CODE INQUIRY
electronic devices as well as batteries must not
Use the following method to find out which
be disposed of with household waste.
code is currently set:
Consumers are obliged by law to return
electrical and electronic devices as well as
1.
Press and hold [MUTE], then press
batteries at the end of their service lives to the
[POWER] until the LED will be lit, then
public collecting points set up for this purpose
release keys.
or point of sale. Details to this are defined by
2.
Input [9].[9].[0] with number keys. The
the national law of the respective country. This
LED will flash twice and goes off.
symbol on the product, the instruction manual
or the package indicates that a product is
3.
Press the number key 1 for the 1st digit
subject to these regulations. By recycling,
of the code. The LED will start to flash.
reusing the materials or other forms of utilising
Count the LED flashes. The number of
old devices/Batteries, you are making an
flashes resemble the code's first digit.
important contribution to protecting our
Repeat this procedure for the 2nd and
environment.
3rd digit of the code:
2nd digit -> enter 2 -> count LED
flashes
3rd digit -> enter 3 -> count LED flashes
lf code number is [0] the LED will not
flash.
3
