Meross MSL610 - Smart Light Manual

Package Contents

  1. Power Adapter x 1
  2. User Manual x 1
  3. Lamp Pole x 2
  4. Lamp x 1
  5. Clamp x 1
  6. Fastener x 3
  7. Lamp Base x 1
  8. Remote Controller and Holder x 1

Lamp Size

Lamp Size

How to Install the Lamp

How to Install the Lamp

warning Note: Turn clockwise to tighten the light pole.

  1. Floor Lamp: Connect the two lamp poles with the lamp base and lamp head with provided fasteners.
  2. Table Lamp: Connect the lamp head and lamp base with provided fastener.
  3. Clamp Lamp: Connect the lamp head and clamp with provided fastener.

Installation Guide

  1. Download the Meross app.

www.apple.com

play.google.com

  1. Connect power cable and power the device up.
  2. Set up the device.
    1. Connect your smartphone or tablet to a 2.4 GHz Wi-Fi network.
    2. Make sure your smart device is covered by strong Wi-Fi signal.
    3. The smart device supports iOS 13/ iPadOS 13 and later. It is recommended that you upgrade your iOSor iPadOS to the latest version before pairing with the smart device.
    4. Launch the Meross app and log in to your account, or if you are a new user, tap Sign up to create a new account.
    5. Tap the "+" icon to select the type of smart device you want to add, then you can just follow the setup wizard to finish configuration.
    6. Relocation of the smart device does not require additional operations provided that it remains on the same network with strong Wi-Fi signal.
      Set up the device

warning Note:

  1. If this is not the first time you've added this smart device, you'll have to reset it before going any further.
  2. As long as you finish configuration, you'll be able to manage the device in Apple Home app.
  3. If the QR code does not work, please try to add the smart device in Apple Home app.
  4. Find more at https://www.meross.corn/support/

LED and Button Rules

LED and Button Rules

  1. Timer Indicator
    10 minutes auto off timer indicator.
    60 seconds auto off timer indicator.
  2. Power Indicator
    ON: Light is off, indicating the location of the power button in the dark.
    OFF: Light is on.
  3. Main Light
    Blinking 3 times: Configuration mode.
    Blinking smoothly from warm to white: Successfully connected.
  4. Power Button
    Short press to turn on/off the light.
    Hold for 5 seconds to reset the device.
  5. Color Button
    Adjust color temperature with 5 steps.
  6. Brightness Button
    Adjust brightness with 5 steps.
  7. Gooseneck
    Adjust the lamp head angle. Don't bend the gooseneck excessively to avoid damage.

Remote Controller

  1. (ON) Power ON/OFF
  2. (60S) 60 seconds auto off timer
  3. (10M) 10 minutes auto off timer
  4. (Bright+) Increase the brightness
  5. (Bright-) Decrease the brightness
  6. (Color+) Increase color temperature
  7. (Color-) Decrease color temperature
  8. () Night mode
  9. (20%) 20% brightness
  10. (50%) 50% brightness
  11. (100%) 100% brightness
  12. (Warm) 2700K warm color temperature
  13. (Cool) 6000K cold color temperature
  14. (Mix) 4500K mixed color temperature

How to Use

General Settings

Device name: Change device name.
User manual: Check user manual.
General Settings

Voice Control

Arnazon Alexa & Google Assistant:
Check how to pair Amazon alexa and Google assistant on Account->lntegration.
Voice Control

Amazon Alexa:
The example commands are as followings:
-"Alexa, set the smart floor lamp warmer."
-"Alexa, dim the smart floor lamp by 30%."

Google Assistant:
The example commands are as follows:
-"Hey Google, brighten the smart floor lamp."
-"Hey Google, set the smart desk floor to cool white."

HomeKit Siri:

warning Note: So far Homekit SDK doesn't support voice control for devices only with color temperature change. We'll pay close attention to HomeKit updates and upgrade Meross firmware when this function is available.

The example commands are as follows:
-"Hey Siri, turn on/off the smart floor lamp."

FAQ

At Meross, we strive to assure your satisfaction. Attached below is a non-exhaustive list of questions that users are mostly concerned about.

  1. How do I reset my Meross Smart Floor Lamp?
    Hold the power button for 5 seconds, it will reset and enter Wi-Fi configuration mode. Note that factory reset will erase all of your custom settings, and you'll have to set it up again.
  2. What if I can't control the smart device with the Meross app?
    You can troubleshoot the following:
    • Check if your home Wi-Fi is working properly.
    • Make sure that you have disabled access control in your router and that the smart device is not blocked by the router's firmware.
    • Factory reset your smart device and try to add it again.
  3. My Home app can't add the device by scanning the QR code.
    You can tap "Don't Have a Code or Can't Scan" and input the code manually.
  4. I can't pair my device with HomeKit anyhow.
    Please make sure your iOS is connecting to the 2.4GHz Of your home Wi-Fi and you are having iOS 13 or later. Restart your iOS will help due to some system cache issue.

Safety Information

  • Place on flat or secure surface.
  • ONLY use the supplied AC Power adapter.
  • Do not attempt to disassemble, repair, or modify the device.
  • Don't touch electrical parts with wet hands.

Email: support@meross.com
Website: www.meross.com
