- Page 1 User Manual (Original English Version) Sliding-Door Automation SDA-05 & SDA-05 PRO Metaflex. Meet reliability.
- Page 2 The contents of these operating instructions have been checked for compliance with the products descri- bed. However, deviations cannot be ruled out. Full compliance is not guaranteed. Reprinting of these instructions, even in part, is only permitted with the written consent of Metaflex Doors Europe.
-
Page 3: Table Of Contents
Battery pack SDA-05 ........ - Page 4 6.1.1 Connection to SDA-05 ........
-
Page 5: General
User Manual - Sliding-Door Automation General General 1 .1 Notes on the operating instructions These operating instructions enable you to use your device safely and efficiently. The manual is part of the scope of delivery and must be kept accessible to the operating personnel at all times. If resold, it must be handed over to the new owner. Due to technical development, the illustrations and descriptions used in these operating instructions may differ slightly from the delivered device. -
Page 6: Copyright Protection
This manual and all documents supplied with the device remain copyrighted by Metaflex Doors. Their use is recommended when using the device. Without the express permission of Metaflex Doors, these documents may not be duplicated or made accessible to third parties, in particular to competitor companies. 1 .4... -
Page 7: Security
Any other use or use that goes beyond this is deemed improper. The SDA-05 is not to be used as an escape door. If an explosive atmosphere (ATEX) is to be expected, the SDA-05 must not be used. -
Page 8: Mechanical Hazards
– Defective fuses may only be replaced by fuses of the same type. – To connect the SDA-05 to the mains power supply, always use the included cables. – The Mains connection cable may only be connected to a grounded outlet. -
Page 9: Responsibility Of The Operator
User Manual - Sliding-Door Automation Security 2 .5 Responsibility of the operator The operator is responsible for the: – Installation of protective devices that detect short circuits and power failure and disconnect all the electrical phases permanently, – Easily accessible storage of the operating instructions, –... -
Page 10: Behaviour In The Event Of Danger And Accidents
User Manual - Sliding-Door Automation Security 2 .8 Behaviour in the event of danger and accidents Shut down the system immediately in the event of danger or accidents. Consult a doctor immediately in the event of injury. 2 .9 Warning and information signs Depending on the system layout, the following notices and warning signs are present. Damaged or removed notices or warning signs are to be renewed immediately. -
Page 11: Layout And Function
The SDA-05 is an automation for sliding doors, both hermetic and non-hermetic. The automation consists of a controller, power supply and motor. There are two versions of the controller, namely the SDA-05 and SDA-05 PRO. The general layout is the same, but the SDA-05 PRO has more connection options and therefore more available functionalities. -
Page 12: Sda-05
8 Button to start the self-teaching function 9 Inputs and outputs 3 .2 LED-Indicators The SDA-05 is equipped with four status LED lights. These are positioned at the front of the controller (6) and have the following meaning: Red LED Green LED... -
Page 13: Function
Layout and function 3 .3 Function The SDA-05 ensures the automatic opening and closing of a sliding door system. All movements of the drive are electronically controlled. Many functions and parameters are programmed by default. Some parameters can be changed by the user. -
Page 14: Additional Properties For The Sda-05 Pro Version
– Safety Sensors: The door can be equipped with up to four sensors (with or without self-test) that can be individually set for opening or closing. – Sensitive Safety: The SDA-05 recognizes automatically a blockage of the door and reacts accordingly (see Chapter 5 Installation and commissioning). -
Page 15: Layout Of The Power Supply
3 .5 Layout of the power supply Fig. 3: Left side-view of the power supply 1 Power connection to the SDA-05 Fig. 4: Right side-view of the power supply 1 Mains connection (appliance plug, IEC C13), with replaceable fuse* 2 Main switch... - Page 16 User Manual - Sliding-Door Automation Layout and function Two power-supplies can be connected in cascade for heavy door-systems. Fig. 5: Two Power supply units in cascade (for particularly heavy doors) 1 PSxxxVA-C (Master power supply with main switch and cascade connection 2 Cascade cable 3 PSxxxVA-T (additional slave power supply with connection to the master power supply 4 LED indicators DC1 and DC2 (for all power supplies)
-
Page 17: Battery Pack Sda-05
2 Charger 3 Power cable Fig. 7: Connection view battery pack 1 Charger connector 2 Power connection to the SDA-05 3 Fuse* 4 Power button with LED indicator *Fuse type: 32 V ATO blade fuse 30 A Revision: 1/03/2024 REV 1.8... - Page 18 Layout and function Remarks: – The power button disconnects the SDA-05 but not the charger from the battery. – Only the original Metaflex charger is to be used! – Batteries must be replaced after 3 years at the latest or if the performance deteriorates.
-
Page 19: Electrical Connections
Fig. 8: Inputs and outputs (pro version) The input and output of the SDA-05 are all designed for 24 V DC. The opening inputs (0, 1, 8 and 9) are intended for the use of buttons. Lock, One way, unlock and stay open (6, 10, 15 and 16) are intended to be used with a switch. -
Page 20: Relays
3 .7 .2 Relays Fig. 9: Relays The SDA-05 PRO has three relays that can each switch 24 VDC or 250 VAC at 8 amp. They can be configured by software. The relays must be protected against capacitive and inductive loads. -
Page 21: Transport And Storage
4 .2 Transport The sliding door automation is delivered professionally packaged, and the weight of the SDA-05 is approx. 0.5 kg, the power supply is approx. 3kg and the battery pack is The S also b approx. 4 kg plus packaging. -
Page 22: Installation And Commissioning
The door controller is adjusted to the options and/or accessories agreed upon with the (end) user. The relevant options are laid down during the handover. You can add optional/accessories afterwards. Please contact Metaflex Doors or one of its dealers for this. Doors should always be delivered fully tested. -
Page 23: Configuration
Fig. 10: WLAN button Step 2: » After the WLAN is turned on, scan the service QR code (2) on the SDA-05 and press connect on your device. The connection between your device and the controller WLAN should be established automatically Fig. -
Page 24: Navigating Web-Interface
User Manual - Sliding-Door Automation Configuration 6 .1 .2 Navigating Web-Interface » » If you are connected to the WLAN of the SDA-05, go into your internet browser There is no internet and type the address „sda05.box“. Alternatively, the address “192.168.1.1” can be connection once used if „sda05.box“... -
Page 25: Changing Language Web-Interface
User Manual - Sliding-Door Automation Configuration 6 .1 .3 Changing language Web-interface The user has the option to choose one of four languages – English (default), – Nederlands (Dutch), – Deutsch (German) and – Français (French). This option is only available after logging in and is accessible on the top right of the home page. -
Page 26: Operation
User Manual - Sliding-Door Automation Configuration 6 .2 Operation Path: 6 .2 .1 Auto-Setup ► Doo ► Aut Fig. 14: “Auto-setup“ view Control buttons (1) If you The „Close“, „Part Open“ and „Full Open“ buttons are operating buttons for the door. softw When clicked, the door executes the corresponding command. The buttons only work to op close, after the door setup procedure has been executed. - Page 27 – Start door auto setup: If the „Start Door Auto Setup“ (or „LEARN“ button on the SDA-05 controller for 5 seconds) is pressed, the door starts a learning cycle without resetting previous settings. Only the end positions, the currents and the following error are verified here.
- Page 28 » Wait 3 seconds and start again. The door will now automatically starts the learning is bet 60 cm cycle. "Door homing" Reset Device and Homing - > SDA-05 perform a restart and then a reference run to find its end position. "Controller Type" This field displays the auto-detected type of controller. „Door Direction“...
-
Page 29: Door-Setup
This setting is only temporary and can be used for testing. » Press the „Save to EEPROM“ (6) button to save your current settings This permanently stores the setting in the SDA-05. Notice! • Shutdown the controller and turn it back on, to check if everything is saved in EEPROM. -
Page 30: Special Pages Web Interface
User Manual - Sliding-Door Automation Configuration 6 .3 Special Pages Web Interface Path: 6 .3 .1 Home Info ► Firm ► Hom The web interface offers the option of displaying contact details on the start page see Figure 16. It is recommended to fill out the contact details of the service provider or in- house technician here. -
Page 31: Parameter
User Manual - Sliding-Door Automation Configuration » After you have made your adjustments, click on the „Save“ button (1). » If you click on „Logout“ (2), you will return to the start page and can check your entry. mware me Info Fig. -
Page 32: Door Setup
User Manual - Sliding-Door Automation Configuration 6 .4 .1 Door setup Fig. 20: Door setup view Mode Function Pull&Go If the door is opened manually and Pull&Go is active, the door will support opening. 0: OFF 1: The door is fully opened 2: The door is partially opened Notice: Pull &... -
Page 33: Behavior Of The Safety Features
User Manual - Sliding-Door Automation Configuration Mode Function Sensor override When this mode is active, the door moves in a safe low current setting without checking the safety sensors. 0: Normal – High-speed mode active 1: Low Current Mode Active Always Activation of locked mode 0: OFF 1: The door automatically enters “Locked”... - Page 34 User Manual - Sliding-Door Automation Configuration – When “One Way” , “Interlock” or “Lock” input is active, these will get overruled, and the door opens and closes automatically. – Pull and go is enabled and is set to partly open. Behaviour for Fire-/Smoke-Door Low Prio: –...
-
Page 35: Maintenance
► Damage to the insulation or individual components can be life-threatening Notice! Malfunctions due to wetness! ► Only clean the SDA-05 with a slightly damp cloth! 7 .2 Performing Maintenance Contact your service partner or Metaflex Doors for required maintenance work. -
Page 36: Troubleshooting
Homing“ under Door Setup -> Auto Setup. The SDA-05 restarts and the door moves to the closed position. The door then resumes normal operation. If the door is not ready for operation, check the web or PC interface to see whether the door is in an error state. -
Page 37: Overview Of Error Codes
Contact your service partner or Metaflex. -10008 FOC Runtime SDA-05 has a problem with the Repeat the door learning cycle. motor control Contact your service partner or Metaflex. -10009 Software error... - Page 38 Check if the door can easily be moved nical wear by hand Contact your service partner or Metaflex * If the batteries are empty temporarily disconnect the SDA-05 from battery pack to let batteries charge. Page 38 of 43 Revision: 1/03/2024 REV 1.8...
-
Page 39: Dismantling And Disposal
Safety instructions for dismantling DANGER! Danger to life from electric current! ► Never open the SDA-05! ► Do not touch any live parts. There is an immediate risk of death from electric shock. ► Pay attention to batteries that have energy stored, even when disconnected. -
Page 40: Specifications
User Manual - Sliding-Door Automation Specifications Specifications 10 .1 Technical data SDA-05 & SDA-05 PRO Technical data Unit Value Input power voltage Volt DC 24 to 48 Input electronic voltage Volt DC 24 to 30 Power consumption standby Watt Power consumption maximum... -
Page 41: Technical Specifications Battery Pack
Weight Battery type Maintenance-free Sealed Lead-acid Battery 12V 7.0 Ah (2x) Battery weight (single) 10 .4 Dimensions 10 .4 .1 Dimensions SDA-05 and SDA-05 PRO Fig. 22: Dimensions SDA-05 and SDA-05 PRO Revision: 1/03/2024 REV 1.8 Page 41 of 43... -
Page 42: Dimensions Powersupply Psxxxva-Xx
User Manual - Sliding-Door Automation Specifications 10 .4 .2 Dimensions Powersupply PSxxxVA-xx Fig. 23: Dimensions Powersupply PSxxxVA-xx 10 .4 .3 Dimensions Battery Pack SDA-05 Fig. 24: Dimensions Battery Pack SDA-05 Page 42 of 43 Revision: 1/03/2024 REV 1.8... -
Page 43: Appendix
User Manual - Sliding-Door Automation Appendix Appendix 11 .1 Appendix A Wiring diagram Revision: 1/03/2024 REV 1.8 Page 43 of 43...
