Part of start up diagnostics.
88
At power up:
1.) Tongue motor cycles – finds
home.
2.) Bug wheel spins – calibrates
speed. Display will show
RPM calibration.
Tongue sensor not seen.
E11
Wheel Sensor not seen.
E12
Wheel Sensor always seen.
E13
Ticket tray empty.
Lo
or
Faulty low ticket switch.
Broken/loose wires.
.
ERROR CODES
Leave game for up to 10 minutes.
Error 88 will clear, though a new error may be displayed.
Part of start up diagnostics. Tongue motor will cycle in and
out—twice.
If sensor under assy. Does not see silver tape, the game will
show E11.
Refer to "How to Access Chameleon Motor & Sensor" section
for details on locating motor and sensor.
Refer to "How to Remove Chameleon Assy" section for details
on bench testing motor and silver tape placement.
Part of start up diagnostics. Only after tongue sensor is
tested, the bug wheel will start turning and sensor will "see"
reflective tape on wheel tabs.
Refer to "How to Remove Wheel" section for details on silver
tape placement.
Part of start up diagnostics. Only after tongue sensor is
tested, the bug wheel will start turning and sensor will "see"
reflective tape on wheel tabs.
Refer to "How to Remove Wheel" section for details on silver
tape placement.
Load tickets.
Make sure ticket stack rests on top of wire actuator of switch.
Replace switch. (AASW200)
Check cable connections from switch to main circuit board.
