Game Time; Diagnostics - BAYTEK GAMES CHAMELEON PARADIZE Service Manual

The following chart lists the symbol shown on the display when each individual input,
sensor or switch is activated in diagnostics mode.
If more than one input is activated, the symbols will alternate on the display.
Tongue Button (Player Button)
N18- RESTORE FACTORY SETTINGS
Press and hold the "SELECT" button until the display reads "dE".
All game settings will be restored to the factory default, which are
Depending on the postition of DIP 3, the defaults will be reset to the following:
MENU
N5
N10
N11
N12
N17- DIAGNOSTICS
Input/ Sensor/ Switch
Bug Score Sensor
Wheel Sensor
Tongue Sensor
Low Ticket Switch
(displays when OPEN)
Coin Switch
DBA
highlighted in this manual.
DESCRIPTION
TICKET PATTERNS

GAME TIME

TARGETS COUNTED PER GAME
WHEEL SPEED-UP
Display
DIP 3 ON
DEFAULT
Pattern 1
30 sec
0 (off )
0 (off )
16
1
2
3
b
L
C
d
DIP 3 OFF
DEFAULT
Pattern 11
0 (off )
30 Targets
2 (random)
