TROUBLESHOOTING GUIDE
Symptom
An extra Dot on Display Board.
Part of a display is not showing
Display not functioning prop-
erly.
Light under Pushbutton does
not go on.
Light under button should be
flashing during game play,
and off all other times.
Light under Pushbutton stays
on.
Light under button should be
flashing during game play,
and off all other times.
Counters do not work.
Game counter clicks at start
of each game.
Ticket counter clicks as tick-
ets come out of game.
Probable Cause
The Dot means low
tickets.
Segment faulty.
Display not receiving
correct signals from
main board.
Faulty Main Board
Burnt out bulb.
Faulty Cable
Faulty Main Board.
Faulty Main Board.
The 2 wires crimped
together may be faulty
Faulty Cable.
Faulty Main Board.
27
Remedy
Refer to Lo (Low Tickets) in Error Code
Section.
Replace display board. (AABD4208)
Refer to Display & Speaker Wiring Diagram.
Communication problem with main board.
Check AACE1257 cable (J10) on main board.
Replace main board if possible to isolate the
problem to the main circuit board.
Replace (A5LA1100) It is a #1893 bulb.
Check cables from light to main board.
(AACE1251)
Replace main board. (A5NEWGEN1)
Replace main board. (A5NEWGEN1)
Also inspect bulb and wiring—a short on
bulb may damage main board.
(A5LA1100, AACE1251)
Inspect crimp to ensure good connection.
Check cables from counters to main board.
(AACO1000, AACE1251)
Replace main board. (A5NEWGEN1)
