- Page 1 GET IT DONE ! 4"×6" BELT DISC SANDER Contact Us: email: service@bucktool.com https://www.bucktool.com IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety Guidelines and Operating Instructions before operating MANUAL this product.
- Page 2 BD4603 TABLE OF CONTENTS Specifications Specifications Safety guidelines Package contents Key parts diagram Operating instructions Troubleshooting Exploded view Parts list Warranty SPECIFICATIONS Motor 230~240V, 50Hz , 500W Speed (no load) 2980RPM Belt size 100x914 mm Belt speed 9.2 m/s Disc size...
- Page 3 BD4603 IMPORTANT! Safety is the single most important consideration in the operation of this equipment. The following instructions must be followed at all times. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury.
- Page 4 BD4603 2) Electrical safety a. The terminal plug of the tool must fit into the outlet. The plug may not be modified in any way. Do not use an adaptor plug together with grounded power tools. The original plugs and the appropriate outlets reduce the risk of an electrical shock.
- Page 5 BD4603 4) Use and treatment of the power tool a. Do not overtax the tool. Use the appropriate tool for the work that is to be done. With the correct power tool, you can work better and more safely. b. Do not use a power tool where the switch is defective. A power tool that cannot be turned on and off is dangerous and must be repaired.
- Page 6 BD4603 • Make sure the sanding belt is running correctly so that it cannot come off the drive pulleys. • Make sure the sanding belt is not twisted or loose. • Firmly hold the workpiece when sanding. • Always use the fence when using the sanding machine in horizontal position.
- Page 7 BD4603 Package contents No. Description Qty. Belt / disc sander (not shown) Miter gauge Work table 5 mm hex wrench Adapter Table lock knob washer...
- Page 8 BD4603 150mm diameter sanding disc Work table On/Off switch with Miter gauge Work table Worktable lock knob Mounting hole 100mm width / 914mm length Belt frame connection sanding belt Tracking knob Belt tension lever Belt sander support rod Dust exhaust port...
- Page 9 BD4603 INSTALLING WORKTABLE ON DISC The worktable can be used with both the sanding disc and the belt. It should be used to support workpieces in all sanding operations except inside curve applications. 1. Place the worktable (1) onto the disc 1/16 in.
- Page 10 BD4603 INSTALLING BELT BACKSTOP The belt backstop prevents the workpiece from being pulled or dragged beyond the sanding belt surface. It should always be used to help control the workpiece when using the sanding belt. 1. Remove the belt worktable.
- Page 11 BD4603 MOUNTING BELT / DISC SANDER TO WORKBENCH 1. Place the sander on a surface that is level but also provides enough room on all sides for the workpiece and for the operator (or bystanders) to not be standing in line with the wood while using the tool. Allow room for the belt to be positioned horizontally or vertically.
- Page 12 BD4603 TO PROPERLY TRACK THE SANDING BELT 1. Plug in the sander. 2. Turn power switch ON, then immediately OFF, noting whether the belt (1) tends to slide off its track, and to which side (front or back) of the sander.
- Page 13 BD4603 BELT HORIZONTAL SANDING When using the sanding belt in the horizontal position, to perform surface or edge sanding, the belt worktable (1) must always be used. Always hold the workpiece (2) firmly keeping your fingers away from the sanding belt (3).
- Page 14 BD4603 OPERATING DUST EXHAUST Sanding operations are inherently dusty. It is strongly recommended that users attach a shop vacuum when using this belt/disc sander. Use of a mask or respirator is still recommended even when a dust-collection system is in use.
- Page 15 BD4603 7. Replace and tighten the two screws (2, 3) and push the tension lever (4) in to apply belt tension. 8. Push the belt by hand and check if the sanding belt tends running to one side or the other of the two drums.
- Page 16 BD4603 WARNING! To avoid injury from an accidental start, turn the switch OFF and always remove the plug from the power source before making any adjustments. PROBLEM PROBLEM CAUSE SUGGESTED CORRECTIVE ACTION Motor will not 1. Defective or broken ON/OFF 1.
- Page 17 BD4603...
- Page 18 BD4603 ITEM DES. SPE. QTY. ITEM DES. SPE. QTY. Philips Screw+Flat M4×10 5×10 Washer Disc Dust Port Tension Handle Dust port pipe Pull Spring Disc Paper Philips Screw M5×25 Miter Gauge Bar Philips Screw M5×20 Work Table Fixed Inner Hex Screw M6×16...
- Page 19 BD4603 ITEM DES. SPE. QTY. ITEM DES. SPE. QTY. Philips Screw+Flat M5×185 Miter Gauge Pointer Washer Philips Screw+Spring Wire clip M5×8 Washer+Flat Washer Work Table Miter Philips Screw M5×10 Gauge Right End Cap Miter Gauge Knob Belt Frame Connect Wrench Inner Hex Screw M6×25...
- Page 20 GET IT DONE ! TWO-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : service@bucktool.com https://www.bucktoolfactorydirect.com https://www.bucktool.com...
