BD4603 4×6 BELT DISC SANDER " CONTACT US:BUCKTOOL@FOXMAIL.COM IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety MANUAL Guidelines and Operating Instructions before operating this product.
BD4603 TABLE OF CONTENTS Specifications Safety guidelines Package contents Key parts diagram Operating instructions Maintenance Troubleshooting Exploded view Parts list Warranty SPECIFICATIONS Motor 120VAC, 60Hz , 5.0A Speed (no load) 3450RPM Belt size 4" x 36" Belt speed 2161 FPM Disc size 6"...
BD4603 SAFETY GUIDELINES - DEFINITIONS • Always wear safety goggles or safety glasses with side shields. • Always wear respiratory and hearing protection. • To reduce the risk of injury, user and all bystanders must read and understand instruction manual before using this product.
Page 5
BD4603 POWER TOOL SAFETY 1. READ and become familiar with the entire Instruction Manual. LEARN the tool’s application, limitations and possible hazards. 2. KEEP GUARDS IN PLACE and in working order. 3. REMOVE ADJUSTING KEYS AND WRENCHES. Form the habit of checking to see that keys and adjusting wrenches are removed from the tool before turning ON.
Page 6
BD4603 17. USE RECOMMENDED ACCESSORIES. Consult this Instruction Manual for recommended accessories. The use of improper accessories may cause risk of injury to yourself or others. 18. NEVER STAND ON THE TOOL. Serious injury could occur if the tool is tipped or if the cutting tool is unintentionally contacted.
Page 7
BD4603 POWER TOOL SAFETY 1. USE sander on horizontal surfaces only. Operating the sander when mounted on non-horizontal surfaces might result in motor damage. 2. TO STOP it from tipping over or moving when in use, the sander must be securely fastened to a bench top or supporting surface.
Page 8
BD4603 IMPORTANT INFORMATION-Electrical A separate electrical circuit should be used for your machines. This circuit should not be less than #12 wire and should be protected with a 20-A time-lag fuse. If an extension cord is used, use only 3-wire extension cords which have 3-pronged grounding type plugs and matching receptacle which will accept the machine’s plug.
Page 9
BD4603 The plug must be plugged into a matching outlet that is properly installed and grounded in accordance with all local codes and ordinances. Do not modify the plug provided–if it will not fit the outlet, have the proper outlet installed by a qualified electrician.
BD4603 INSTALLING WORKTABLE ON DISC The worktable can be used with both the sanding disc and the belt. It should be used to support workpieces in all sanding operations except inside curve applications. 1. Place the worktable (1) onto the disc 1/16 in.
Page 13
BD4603 INSTALLING BELT BACKSTOP The belt backstop prevents the workpiece from being pulled or dragged beyond the sanding belt surface. It should always be used to help control the workpiece when using the sanding belt. 1. Loosen the inner hex screw (1) using the 5 mm hex key, and raise the belt bed (2) in the 90 degree vertical position.
Page 14
BD4603 MOUNTING BELT / DISC SANDER TO WORKBENCH 1. Place the sander on a surface that is level but also provides enough room on all sides for the workpiece and for the operator (or bystanders) to not be standing in line with the wood while using the tool. Allow room for the belt to be positioned horizontally or vertically.
Page 15
BD4603 TO PROPERLY TRACK THE SANDING BELT 1. Plug in the sander. 2. Turn power switch ON, then immediately OFF, noting whether the belt (1) tends to slide off its track, and to which side (front or back) of the sander.
Page 16
BD4603 BELT HORIZONTAL SANDING When using the sanding belt in the horizontal position, to perform surface or edge sanding, the belt worktable (1) must always be used. Always hold the workpiece (2) firmly keeping your fingers away from the sanding belt (3).
BD4603 OPERATING DUST EXHAUST Sanding operations are inherently dusty. It is strongly recommended that users attach a shop vacuum when using this belt/disc sander. Use of a mask or respirator is still recommended even when a dust-collection system is in use.
Page 18
BD4603 7. Replace and tighten the two screws (2, 3) and push the tension lever (4) in to apply belt tension. 8. Push the belt by hand and check if the sanding belt tends running to one side or the other of the two drums.
BD4603 WARNING! To avoid injury from an accidental start, turn the switch OFF and always remove the plug from the power source before making any adjustments. PROBLEM PROBLEM CAUSE SUGGESTED CORRECTIVE ACTION Motor will not 1. Defective or broken ON/OFF 1.
BD4603 p i l × Philips Screw+Flat washer+Spring Washer M4X8 p i l × p i l c t i c t i p i l p i l × p i l t i c Philips Screw+Flat washer+Spring Washer M4×10...
Page 22
BD4603 t i s × p i l × Hex Screw+Flat Washer+Spring washer M6×12 e l l t i c μ × × Philips Screw+Flat washer+Spring Washer M5×12 p i l × p i l ×...
Page 23
BD4603 Philips Screw+Flat washer+Spring Washer M4×8 i l e p i l × Philips Screw+Flat washer+Spring Washer M5×8 t i i d i l t i c μ t i c ×...
TUCKTOOL contact us:bucktool@foxmail.com ONE-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : bucktool@foxmail.com Skype : bucktool@foxmail.com Skype:bucktool@foxmail.com...
