Summary of Contents for Bucktool BD1801
- Page 1 GET IT DONE 1"×8" BELT DISC SANDER Contact Us: email: service@bucktool.com https://www.bucktool.com 909-255-1088 (8AM-5PM PST) IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety MANUAL Guidelines and Operating Instructions before operating this product.
-
Page 2: Table Of Contents
BD1801 TABLE OF CONTENTS Table of contents Safety guidelines Package contents Key parts diagram Assembly instructions Operating instructions Maintenance Troubleshooting Exploded view Parts list Warranty SPECIFICATIONS Motor 120VAC, 60Hz , 5.0A Speed (no load) 3580RPM Belt size 1" x 42"... -
Page 3: Safety Guidelines
BD1801 SAFETY GUIDELINES - DEFINITIONS • Always wear safety goggles or safety glasses with side shields. • Always wear respiratory and hearing protection. • To reduce the risk of injury, user and all bystanders must read and understand instruction manual before using this product. - Page 4 BD1801 POWER TOOL SAFETY 1. READ and become familiar with the entire Instruction Manual. LEARN the tool’s application, limitations and possible hazards. 2. KEEP GUARDS IN PLACE and in working order. 3. REMOVE ADJUSTING KEYS AND WRENCHES. Form the habit of checking to see that keys and adjusting wrenches are removed from the tool before turning ON.
- Page 5 BD1801 17. USE RECOMMENDED ACCESSORIES. Consult this Instruction Manual for recommended accessories. The use of improper accessories may cause risk of injury to yourself or others. 18. NEVER STAND ON THE TOOL. Serious injury could occur if the tool is tipped or if the cutting tool is unintentionally contacted.
- Page 6 BD1801 POWER TOOL SAFETY 1. USE sander on horizontal surfaces only. Operating the sander when mounted on non-horizontal surfaces might result in motor damage. 2. TO STOP it from tipping over or moving when in use, the sander must be securely fastened to a bench top or supporting surface.
- Page 7 BD1801 IMPORTANT INFORMATION-Electrical A separate electrical circuit should be used for your machines. This circuit should not be less than #12 wire and should be protected with a 20-A time-lag fuse. If an extension cord is used, use only 3-wire extension cords which have 3-pronged grounding type plugs and matching receptacle which will accept the machine’s plug.
- Page 8 BD1801 The plug must be plugged into a matching outlet that is properly installed and grounded in accordance with all local codes and ordinances. Do not modify the plug provided–if it will not fit the outlet, have the proper outlet installed by a qualified electrician.
-
Page 9: Package Contents
BD1801 Package contents No. Description Qty. Belt / disc sander (not shown) Disc worktable Disc table handle Flat washer D8 Belt table handle Belt worktable Miter gauge assy Belt tension handle Inner hex wrench Sanding disc cover Philips screw... -
Page 10: Key Parts Diagram
BD1801 No. Description 8 in. diameter sanding disc Miter gauge assy Disc worktable Base Disc table handle On / Off switch Belt table handle Belt worktable 1 in. width / 42 in. length sanding belt Belt tracking knob Belt tension handle... -
Page 11: Assembly Instructions
BD1801 WARNING! To avoid injury, always keep the plug disconnected from the power source and the switch turned OFF until the sander is completely assembled and adjusted properly. INSTALLING TENSION HANDLE Screw the tension handle (1) into the hole (2) of the hub and lock it. - Page 12 The sander has two dust ports. Slide the hose of your dust collector over the outlet, and secure with a hose clamp. Recommended (not included): BUCKTOOL Y-fitting 4" to 1-3/8"(O.D.) Reducer Search at AMAZON.COM or https://www.bucktool.com You can use it to attach two of your tools including your table saw, jointer, planer, bandsaw, disc sander, belt sander, drum sander, and more.
-
Page 13: Operating Instructions
BD1801 ON/OFF Switch (FIG. G) 1. Press the power switch side marked “ON” to turn the grinder on. 2. Press the power switch side marked “OFF” to turn the grinder off. 3. To lock the switch in the “OFF” position, grasp the end, of the switch key, and pull it out. - Page 14 BD1801 TO PROPERLY TRACK THE SANDING BELT 1. Plug in the sander. 2. Turn power switch ON, then immediately OFF, noting whether the belt (1) tends to down slide off its track, and to which side of the sander. 3. If the sanding belt does not slide to either side, it is tracking properly.
-
Page 15: Maintenance
BD1801 WARNING! For your safety, turn switch OFF and remove the power cord from the electrical outlet before adjusting or performing maintenance on your sander. To avoid electric shock or fire, all repairs to the electrical components should be done by a qualified service technician. Before each use check for damaged, missing, or worn parts;... - Page 16 BD1801 REPLACING SANDING BELT 1. Remove the belt cover (2) by loosen the inner hex nut (1). NOTE: No need remove the inner hex nut. 2. Release belt tension by pulling down on tension handle (2). Slide old belt off the drive and tracking wheels.
-
Page 17: Troubleshooting
BD1801 WARNING! To avoid injury from an accidental start, turn the switch OFF and always remove the plug from the power source before making any adjustments. Not connected to power source. Connect to power source. Determine reason for blown fuse/... -
Page 18: Exploded View
BD1801... -
Page 19: Parts List
BD1801 Item Description Item Description Belt tension handle Philips screw assy M4x7 Tension handle base Base Inner hex bolt M8x12 Switch plate Tension spring Switch Shaft circlip D16 Philips bolt assy M8x20 Driven eccentric shaft Rubber foot Knob Philips screw assy M5x16... -
Page 20: Warranty
GET IT DONE TWO-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : service@bucktool.com https://www.bucktool.com 909-255-1088 (8AM-5PM PST) https://www.bucktool.com...
