  • Page 1 Ceiling Fan Installation Manual P250119 93166477...
  • Page 2 Limited Lifetime Warranty Progress Lighting fan motors are warranted to the original purchaser to be free of electrical and/or mechanical defects for so Date Purchas ed long as the original purchaser owns the fan. Pull chain switches, reverse switches, capacitors and metal finishes are warranted to be free from defects in materials or workmanship for a period of 1 year from the date of purchase.
  • Page 3: Table Of Contents

    Safety Rules..................................... Unpacking Your Fan ..................................Installing Your Fan ..................................Installing the Decorative Cover ..............................Operating Your Transmitter ................................Care of Your Fan ................................... Troubleshooting .................................... Specifications ....................................Table of Contents...
  • Page 4 Do not use water or detergents when cleaning the fan or fan blades. A dry dust cloth or lightly water dampened cloth will be suitable for most cleaning.Do not use any chemical when cleaning the fan blades. WARNING TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE ARMS (ALSO REFERRED TO AS BRACKETS) DURING ASSEMBLY OR AFTER INSTALLATION.
  • Page 5: Unpacking Your Fan 2

    Unpack your fan and check the contents. You should have the following items: 1. Fan blades (2) 6. Decorative cover 8. Loose parts bag containing: 2. Ceiling bracket assembly 7. Transmitter a. Blade screws (7) 3. Motor assembly Receiver b. Blade bracket screws (5) CR2032 3V Battery 4.
  • Page 6: Installing Your Fan

    Figure 3 Figure 3 3. Installing Your Fan...
  • Page 7 Hanging the Fan REMEMBER to turn off the power. Follow the steps below to hang your fan properly: UL Listed Step 1. Check existing outlet box (not included) electrical to ensure it is securely fastened to at least two points in a structural ceiling member and can Ceiling support the full weight of the fan.Once verified, bracket...
  • Page 8 Making the Electrical Step 1. Motor to receiver electrical connections: Connect the grey wire from the fan to the grey wire Outlex box Connections from the receiver. Connect the red wire from the White Black fan to the red wire from the receiver. Connect the Ground wire Black(AC IN L) yellow wire from the fan to the yellow wire from...
  • Page 9 Finishing the Installation Step 1. Remove the one screw from the ceiling bracket, Ceiling bracket retain it for later and loosen the remaining two assembly Mounting screws(Figure8). screws Mounting screws Motor assembly Motor Ceiling assembly bracket assembly Figure 8 Step 2. Carefully secure the motor housing onto the Figure 9 Figure 10 mounting slots on ceiling bracket by twisting in a...
  • Page 10 Attaching the Fan Blades Step1. Assemble the blade to blade bracket as shown. Align the holes of the blade with blade Blade screw bracket and install three oval screw with washer. Repeat the step for second blade(Figure13). Step 2. Align and slide the blade bracket assembly in each other.
  • Page 11: Installing The Decorative Cover 8

    Blade Balancing Installing the Decorative cover WARNING TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE All blades are grouped by weight. The fan may Attach decorative cover and rotate clockwise until HOLDERS WHILE INSTALLING, BALANCING wobble even though the blades are weighed THE BLADES, OR CLEANING THE FAN.
  • Page 12: Operating Your Transmitter

    Restore power to ceiling fan and test for proper Installing the Remote Control operation. Holder and Battery 1. “ 0 , 1 , 2 , 3 , 4 , 5 , 6 ” buttons: Attach the remote control holder with the remote These seven buttons are used to set the fan speed as control holder mounting screw.
  • Page 14: Care Of Your Fan

    Figure 21 Figure 22 11. Care of Your Fan...
  • Page 15: Troubleshooting 12

    Problem Solution 1. Check circuit fuses or breakers. Fan will not start. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 1. Make sure all motor housing screws are snug. Fan sounds noisy.
  • Page 16: Specifications

    Volts Amps Watts Fan Size Speed N.W. G.W. C.F. 0.03 1.91 744.47 18.08 22.27 4.74' 33" 0.17 11.79 2668.40 High These are approximate measures. They do not include Amps and Wattage used by the light kit. 13. Specifications...
