Summary of Contents for Progress Lighting Airpro P250073
- Page 1 ® P250073 93153464_A...
- Page 2 Limited Lifetime Warranty Date Purchased Progress Lighting fan motors are warranted to the original purchaser to be free of electrical and/or mechanical defects for so long as the original purchaser owns the fan. Pull chain switches, reverse switches, capacitors and...
-
Page 3: Table Of Contents
Safety Rules Unpacking Your Fan Installing Your Fan Wiring the Fan Preparing the Remote Control Operating Your Fan Care of Your Fan Troubleshooting Specifications Table of Contents... -
Page 4: Safety Rules
READ AND SAVE THESE INSTRUCTIONS To reduce the risk of electric shock, insure electricity has been To avoid personal injury or damage to the fan and other items, turned off at the circuit breaker or fuse box before beginning. be cautious when working around or cleaning the fan. All wiring must be in accordance with the National Electrical Do not use water or detergents when cleaning the fan or fan Code ANSI/NFPA 70-1999 and local electrical codes. -
Page 5: Unpacking Your Fan
Unpack your fan and check the contents. You should have the following items: 1. Mounting Bracket (inside canopy) 7. Upper housing a. Blade attachment hardware (16 screws) 2. 6” Ball/Downrod Assembly (hanger pin 8. Flywheel b. Flywheel attachment hardware and locking pin pre-attached) 9. -
Page 6: Installing Your Fan
Tools Required Figures 1, 2, and 3 are examples of different ways to mount the electrical box. Phillips screw driver or straight slotted screw driver, adjustable wrench, step ladder, and wire cutters. Figure 3 Mounting Options Note: You may need a longer downrod to maintain proper blade clearance when If there isn’t an existing electrical box, then installing on a steep, sloped ceiling. - Page 7 Attaching the Fan Blades 1. Attach the blades to the flywheel by Screws aligning the notches on the blades with alignment post on the flywheel and put the blade on to the flywheel. Secure with screws but do not tighten. (Figure 5) 2.
- Page 8 Attaching the Decorative Ring Screws 1. Attach the decorative ring through the bottom of the flywheel by aligning the Flywheel holes on the decorative ring with the holes on the tab and install the screws. Screws (Figure 7) 2. Put the fan motor assembly inside the flywheel, engage the fan motor assembly with tabs onto the flywheel by turning clockwise till the screw holes on the fan...
- Page 9 Hanging the Fan 5. Loosen, but do not remove, the set screws Turn Canopy to Remove on the collar on the top of the motor REMEMBER to turn off the power. Follow housing. the steps below to hang your fan properly. 6.
- Page 10 Installing Fan to the Electrical Box UL Listed Electrical WHEN USING THE STANDARD BALL/DOWNROD MOUNTING, THE TAB IN THE RING AT THE Ceiling BOTTOM OF THE MOUNTING BRACKET MUST Mounting REST IN THE GROOVE OF THE HANGER BALL. Bracket FAILURE TO PROPERLY SEAT THE TAB IN THE Washers GROOVE COULD CAUSE DAMAGE TO WIRING.
-
Page 11: Wiring The Fan
Installing the Wiring the Receiver to Receiver into the the Household Wiring SUPPLY CIRCUIT Mounting Bracket 1. Connect the green wire to the household ground wires using a wire connecting nut. 1. Position the house supply wires to one side 2. - Page 12 Finishing the Fan 1. Check that all blade screws are secure. Installation 2. Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling STANDARD CEILING MOUNTING above the tip of one of the blades. Measure 1.
-
Page 13: Preparing The Remote Control
Mounting the remote Preparing the Remote control holder Control NOTE: Screw wall anchors are included NOTE: The remote control has already for extra support. The included screws are been paired to the ceiling fan for your designed to screw easily into the wall. If you convenience. -
Page 14: Operating Your Fan
Remote Control Timer: Timer While the fan is on press 2h - turns on a 2 hour run timer. Comfort Comfort While the fan is on press 4h - turns on a 4 hour run timer. Breeze Breeze While the fan is on press 8h - turns on a 8 hour run timer. (speeds 1-3) (speeds 4-6) Comfort Breeze (speeds 1-3):... -
Page 15: Care Of Your Fan
Troubleshooting Care of Your Fan Here are some suggestions to help you Problem Solution maintain your fan. Check main and branch circuit fuses or breakers Fan will not start 1. Because of the fan’s natural movement, Check line wire connections to the fan and switch wire connections in some connections may become loose. -
Page 16: Specifications
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ©2017 Progress Lighting, Inc. 701 Millennium Blvd., Greenville, SC 29607 13.
