Trek 320R Features
Installing the Trek 320R
1. Please install the driver first and then connect Trek 320R to
the USB port.
2. Installing the Trek 320R driver
a. Insert the Trek 320R Installation CD into the CD-ROM drive.
b. The Autorun screen will bring up the installation screen. Click on
"Driver" then simply follow the on-screen instructions.
c. Install "DirectX" from the CD.
Notice:
If the Autorun screen doesn't start, please follow these steps:
Click on "Start Menu".
Type D：\SETUP.EXE, then click "Enter" key.
(Assume your CD-ROM is in Drive D)
3. Insert the Trek 320R's USB cable to your desktop's or
laptop's USB port.
1
SnapShot Button
2
LED Indicator
3
Lens
4
Swivel Base
-1-
English
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Genius TREK 320R
Summary of Contents for Genius TREK 320R
- Page 1 LED Indicator Lens Swivel Base Installing the Trek 320R 1. Please install the driver first and then connect Trek 320R to the USB port. 2. Installing the Trek 320R driver a. Insert the Trek 320R Installation CD into the CD-ROM drive.
- Page 2 Genius Application (Windows Only) You can use our software to capture the real-time image, record or execute the simply security function. To run the software, please go to the task bar and follow “Start” Click “Program” Choose “Trek 320R” Click “Trek 320R”. Or you may execute the software by simply clicking the shortcut of “Trek...
- Page 3 English NOTE After installing the driver of Trek 320R, the system will automatically create a file (C:\WINDOWS\Album or C:\WINNT\Album) to save the images you take using the Genius Application. 1. Description for the major icon Preview mode Snapshot mode Video Clip Mode...
- Page 4 English Environment You may adjust the values for different lighting. The default value is Auto (Auto White Balance) Rotation: You can flip the image horizontally or vertically Extension: You can select different sizes of image resolution Frequency: Select the correct frequency according to the country where you are using the...
- Page 5 English Video Proc Amp: In this section, you can adjust different values for the image itself. -Press “Default” to return to the manufacturer’s settings.
- Page 6 English Camera Control: Select the values of “Exposure” according to the environment where you are using the web camera. Before adjusting the values, please unclick the “Auto”. -Press “Default” to return to the manufacturer’s settings.
- Page 7 English 2. Preview Mode You can use the function buttons on the control panel to zoom in/out and move upward/downward/left/right. Zoom in the image Zoom out the image Move the image upward Move the image downward Move the image to the left...
-
Page 8: Snapshot Mode
There are 2 categories of resolution: RGB24 and I420. You can select 5 different image resolutions for each of them. The file size of I420 will be smaller than RGB24. So, I420 may be the better choice for transmission. 3. SnapShot Mode... - Page 9 English Shoot continuously Resolution selection This section shows the resolution you selected in the “Preview Mode”. If you want to change the resolution, please click “ ”to go back to the “Preview Mode” to make the changes. 4. Video Clip Mode You can record real-time image in this section.
- Page 10 5. Security Monitoring System This function records any movements that appear in front of your monitor automatically. It can also record anytime until the HD is full. If there’s no movement, it will shut down automatically after four seconds otherwise it will be active when detecting new movement.
- Page 11 Start recording Stop recording Setup time of the security monitoring system Set up the degree of the variance for every second of recording image. When the differences are over the setup degree, the system will alert you.
- Page 12 ”to go back to the “Preview Mode” and make the changes. MSN Messenger, Yahoo Messenger, AOL MSN Messenger For live video function, you’ll need MSN Messenger version 6 or later. If you don’t have it, please refer to the website: http://www.msnmessenger-download.com to download.
- Page 13 Sign onto AOL Instant Messenger. Click on “Show Messenger Lists” and choose the friend you want to start a video chat with. Your friend will then receive an invitation message. When your friend confirms to talk, the video chat will start.
- Page 14 English a. Insert the Trek 320R Installation CD into the CD-ROM drive. b. The Autorun screen will bring up the installation screen. Click on “DDPlayCam” then simply follow the on-screen instructions. Once finished, DD ThemeParty and DD PrintCenter are ready to go.
- Page 15 View photo from captured pictures or animation. View Photo 3. Running DD PrintCenter a. Connect the web camera into the computer b. Please go to the task bar and follow “Start” Click “Program” Choose “DDPlayCam” Click “DD PrintCenter”. Or you may execute the software by simply clicking the shortcut of “DD...
- Page 16 DD PlayCam software and saved automatically in the DD PlayCam folder within My Pic tures. a. Step 1: Select Paper Size and Layout or Load Document DD PrintCenter provides you three standard paper sizes. They are A4, 4*6 and 3*5 inch styles.
- Page 17 Each layout template shows you the actual size of a single photo and the number of ph otos a single paper can print, such as 24 mm*18 mm. Select the layout by directly clicking the template, and then click the Next button.
- Page 18 DD PlayCam folder. Roll over any pictures you want to print and drag it directly into an empty position you would like to place it in the template. Or click an empty position first and the frame of the position is marked immediately, double click on the picture you want to print.
- Page 19 English c. Step 3: Add, Delete and Save -19-...
- Page 20 English If you want to print several copies from the same picture, you do not have to repeat the steps for dragging. You only need to select the target picture which you have already dragged into template and click the “+” button. The picture will duplicate at the next position automatically.
- Page 21 You can click the Preview button, then Print. However, please note that DD PrintCenter does not provide functions for controlling or adjusting any settings of your client printer device. We recommend you should check your printer settings and the paper you have loaded before printing. NOTE For further information about the DDPlayCam software, please go to the task bar and follow “Start”...
- Page 22 English “DDPlayCam” Click “DD ThemeParty Uninstallation”, then follow the on-screen instructions to remove the driver. -22-...
