Trek 310 Features
NOTE
Please note that the red-infrared function will be triggered automatically
when the light is insufficient.
Due to the feature of the red-infrared light, the image will become black and
white when the environment is dark.
There are two sets of sticker, you can paste it anywhere you want on the Trek
310.
Installing the Trek 310
1. Please install the driver first and then connect Trek 310 to
the USB port.
2. Installing the Trek 310 driver
a. Insert the Trek 310 Installation CD into the CD-ROM drive.
b. The Autorun screen will bring up the installation screen. Click on
"Driver" then simply follow the on-screen instructions.
c. Install "DirectX" from the CD.
1
SnapShot Button
2
LED Indicator
3
Red-Infrared light
4
Microphone
5
Swivel and Clip Base
-1-
English
Advertisement
Related Manuals for Genius TREK 310
Summary of Contents for Genius TREK 310
- Page 1 Due to the feature of the red-infrared light, the image will become black and white when the environment is dark. There are two sets of sticker, you can paste it anywhere you want on the Trek 310. Installing the Trek 310 1.
- Page 2 Genius Application (Windows Only) You can use our software to capture the real-time image, record or execute the simply security function. To run the software, please go to the task bar and follow “Start” Click “Program” Choose “Trek 310” Click “Trek 310”. Or you...
- Page 3 “Trek 310”. NOTE After installing the driver of Trek 310, the system will automatically create a file (C:\WINDOWS\Album or C:\WINNT\Album) to save the images you take using the Genius Application.
- Page 4 2. For high quality image, please click the monitor type you are using with the web camera 3. You may adjust the values for different lighting. 4. Select the correct frequency according to the country where you are using the web camera.
- Page 5 English 2. Preview Mode You can use the function buttons on the control panel to zoom in/out and move upward/downward/left/right. Zoom in the image Zoom out the image Move the image upward Move the image downward Move the image to the left...
-
Page 6: Snapshot Mode
There are 2 categories of resolution: RGB24 and I420. You can select 5 different image resolutions for each of them. The file size of I420 will be smaller than RGB24. So, I420 may be the better choice for transmission. 3. SnapShot Mode... - Page 7 English Shoot continuously Resolution selection This section shows the resolution you selected in the “Preview Mode”. If you want to change the resolution, please click “ ”to go back to the “Preview Mode” to make the changes. 4. Video Clip Mode You can record real-time image in this section.
- Page 8 5. Security Monitoring System This function records any movements that appear in front of your monitor automatically. It can also record anytime until the HD is full. If there’s no movement, it will shut down automatically after four seconds otherwise it...
- Page 9 Start recording Stop recording Setup time of the security monitoring system Set up the degree of the variance for every second of recording image. When the differences are over the setup degree, the system will alert you.
- Page 10 ”to go back to the “Preview Mode” and make the changes. MSN Messenger, Yahoo Messenger, AOL MSN Messenger For live video function, you’ll need MSN Messenger version 6 or later. If you don’t have it, please refer to the website: http://www.msnmessenger-download.com to download.
- Page 11 Sign onto AOL Instant Messenger. Click on “Show Messenger Lists” and choose the friend you want to start a video chat with. Your friend will then receive an invitation message. When your friend confirms to talk, the video chat will start.
- Page 12 English a. Insert the Trek 310 Installation CD into the CD-ROM drive. b. The Autorun screen will bring up the installation screen. Click on “DDPlayCam” then simply follow the on-screen instructions. Once finished, DD ThemeParty and DD PrintCenter are ready to go.
- Page 13 View photo from captured pictures or animation. View Photo 3. Running DD PrintCenter a. Connect the web camera into the computer b. Please go to the task bar and follow “Start” Click “Program” Choose “DDPlayCam” Click “DD PrintCenter”. Or you may execute the software by simply clicking the shortcut of “DD...
- Page 14 DD PlayCam software and saved automatically in the DD PlayCam folder within My Pictures. a. Step 1: Select Paper Size and Layout or Load Document DD PrintCenter provides you three standard paper sizes. They are A4, 4*6 and 3*5 inch styles.
- Page 15 Each layout template shows you the actual size of a single photo and the number of photos a single paper can print, such as 24 mm*18 mm. Select the layout by directly clicking the template, and then click the Next button.
- Page 16 DD PlayCam folder. Roll over any pictures you want to print and drag it directly into an empty position you would like to place it in the template. Or click an empty position first and the frame of the position is marked immediately, double click on the picture you want to print.
- Page 17 English c. Step 3: Add, Delete and Save -17-...
- Page 18 English If you want to print several copies from the same picture, you do not have to repeat the steps for dragging. You only need to select the target picture which you have already dragged into template and click the “+” button. The picture will duplicate at the next position automatically.
- Page 19 You can click the Preview button, then Print. However, please note that DD PrintCenter does not provide functions for controlling or adjusting any settings of your client printer device. We recommend you should check your printer settings and the paper you have loaded before printing. NOTE For further information about the DDPlayCam software, please go to the task bar and follow “Start”...
- Page 20 English “DDPlayCam” Click “DD ThemeParty Uninstallation”, then follow the on-screen instructions to remove the driver. -20-...
