Look 312P Features
Installing the Look 312P
1. Please install the driver first and then connect Look 312P to
the USB port.
2. Installing the Look 312P driver
Windows Environment
a. Insert the Look 312P Installation CD into the CD-ROM drive.
b. The Autorun screen will bring up the installation screen. Click on
"Driver" then simply follow the on-screen instructions.
c.
Install DirectX from the CD.
Notice:
If the Autorun screen doesn't start, please follow the steps:
Click on "Start Menu"
Type D：\SETUP.EXE , then click Enter key.
(Assume your CD-ROM is in Drive D)
Linux Environment
For Linux operating system, we only have 4 kernel versions:
2.4.22, 2.4.25, 2.4.26 and 2.6.9, in the CD.
a.
Insert the Look 312P Installation CD into the CD-ROM
drive.
Lens
1
Manual focus by adjusting the Lens
Pocket
2
You can put the cable in the pocket.
Bendable Body
3
You can adjust Look 312P in different
position.
-1-
English
Advertisement
Related Manuals for Genius LOOK 312P
Summary of Contents for Genius LOOK 312P
- Page 1 Bendable Body You can adjust Look 312P in different position. Installing the Look 312P 1. Please install the driver first and then connect Look 312P to the USB port. 2. Installing the Look 312P driver Windows Environment a. Insert the Look 312P Installation CD into the CD-ROM drive.
- Page 2 Genius Application (Windows Only) You can use our software to capture the real-time image, record or execute the simply security function. To run the software, please go to the task bar and follow “Start” Click “Program” Choose “Look 312P” Click “Look 312P”. Or you may execute the software by simply clicking the shortcut of “Look...
- Page 3 English NOTE After installing the driver of Look 312P, the system will automatically create a file (C:\WINDOWS\Album or C:\WINNT\Album)to save the images you take using the Genius Application. 1. Description for the major icon Preview mode Snapshot mode Video Clip Mode...
- Page 4 -Press “Restore” to return to the previous settings. -Press “Save” to save the values you set up. - You can flip the image horizontally or vertically by choosing “Mirror Flip” or “Vertical Flip”. - -If your web camera is located in backlight position, you may click “Backlight Comp”...
- Page 5 English 2. Preview Mode You can use the function buttons on the control panel to zoom in/out and move upward/downward/left/right. Zoom in the image Zoom out the image Move the image upward Move the image downward...
-
Page 6: Snapshot Mode
There are 2 categories of resolution: RGB24 and I420. You can select 5 different image resolutions for each of them. The file size of I420 will be smaller than RGB24. So, I420 may be the better choice for transmission. 3. SnapShot Mode... - Page 7 Send photo by e-mail Shoot continuously Resolution selection This section shows the resolution you selected in the “Preview Mode”. If you want to change the resolution, please click “ ”to go back to the “Preview Mode” to make the changes.
- Page 8 5. Security Monitoring System This function records any movements that appear in front of your monitor automatically. It can also record anytime until the HD is full. If there’s no movement, it will shut down automatically after four seconds or otherwise it...
- Page 9 Start recording Stop recording Setup time of the security monitoring system Set up the degree of the variance for every second of recording image. When the differences are over the setup degree, the system will alert you.
- Page 10 ”to go back to the “Preview Mode” and make the changes. MSN Messenger, Yahoo Messenger, AIM MSN Messenger a. For live video function, you’ll need MSN Messenger version 6 or later. If you don’t have it, please refer to the website: http://www.msnmessenger-download.com to download.
- Page 11 Sign onto AOL Instant Messenger. c. Click on “Show Messenger Lists” and choose the friend you want to start with video chat with. d. Your friend will then receive an invitation message. When your friend confirms to talk, the video chat will start.
- Page 12 Installing the DDPlayCam Software 1. Insert the Look 312P Installation CD into the CD-ROM drive. 2. The Autorun screen will bring up the installation screen. Click on “DDPlayCam” then simply follow the on-screen instructions. Once finished, DD ThemeParty and DD PrintCenter are ready to go.
- Page 13 Tool Tip Function Description Display DD PlayCam software version AboutDD PlayCam Capture (Enter) Take a snapshot in process Take 12 snapshots as a GIF animation Sequential Capture Open DD PrintCenter application DD PrintCenter Exit application Close Windows Call help documentation...
- Page 14 Please note that as an indivisible part of DD PlayCam software, this function allows you only t print photos generated by DD PlayCam software and saved automatically in the DD PlayCam folder within My Pictures.
- Page 15 Each layout template shows you the actual size of a single photo and the number of photos a single pape can print, such as 24 mm*18 mm. Select the layout by directly clicking the template, and then click the “Next”...
- Page 16 English b. Step 2: Choose and Load Photo -16-...
- Page 17 You can see an empty layout template and thumbnail pictures that you captured and saved in the DD PlayCam folder. Roll over any pictures you want to print and drag it directly into an empty position you would like to place it in the template. Or...
- Page 18 English If you want to print several copies from the same picture, you do not have to repeat the steps for dragging. You only need to select the target picture which you have already dragged into template and click the “+” button. The picture will duplicate at the next position automatically.
- Page 19 English button to open the PCF file for further editing. You can also use Sa as function to save a file as the format you indicated. d. Step 4: Preview and Print You can click the Preview button, then Print. However, please note that DD PrintCenter does not provide functions for controlling or adjusting any settings of your client printer device.
- Page 20 English To remove the driver installation: Please go to the taskbar and follow “Start” “Program” Choose “DDPlayCam” Click “DD ThemeParty Uninstallation”, then follow the on-screen instructions to remove the driver. -20-...
