Slim 321C Features
Installing the Slim 321C
1. Please install the driver first and then connect Slim 321C to
the USB port.
2. Installing the Slim 321C driver
a. Insert the Slim 321C Installation CD into the CD-ROM drive.
b. The Autorun screen will bring up the installation screen. Click on
"Driver" then simply follow the on-screen instructions.
c. Install "DirectX" from the CD.
Notice:
If the Autorun screen doesn't start, please follow these steps:
Click on "Start Menu".
Type D：\SETUP.EXE, then click "Enter" key.
(Assume your CD-ROM is in Drive D)
Led indicator
1
When the Slim 321C is connected the LED
indicator will be turned on.
Lens
2
Adjust the focus by twisting the lens.
Adjustable base
3
The adjustable base allows you to place the
Slim 321C on different LCD monitor sizes.
-1-
English
Advertisement
Related Manuals for Genius SLIM 321C
Summary of Contents for Genius SLIM 321C
- Page 1 The adjustable base allows you to place the Slim 321C on different LCD monitor sizes. Installing the Slim 321C 1. Please install the driver first and then connect Slim 321C to the USB port. 2. Installing the Slim 321C driver a.
- Page 2 Genius Application (Windows Only) You can use our software to capture the real-time image, record or execute the simply security function. To run the software, please go to the task bar and follow “Start” Click “Program” Choose “Slim 321C” Click “Slim 321C”. Or you may execute the software by simply clicking the shortcut of “Slim...
- Page 3 English NOTE After installing the driver of Slim 321C, the system will automatically create a file (C:\WINDOWS\Album or C:\WINNT\Album) to save the images you take using the Genius Application. 1. Description for the major icon Preview mode Snapshot mode Video Clip Mode...
- Page 4 English Environment You may adjust the values for different lighting. The default value is Auto (Auto White Balance) Rotation: You can flip the image horizontally or vertically Extension: You can select different sizes of image resolution Frequency: Select the correct frequency according to the country where you are using the...
- Page 5 English Video Proc Amp: In this section, you can adjust different values for the image itself. -Press “Default” to return to the manufacturer’s settings.
- Page 6 English Camera Control: Select the values of “Exposure” according to the environment where you are using the web camera. Before adjusting the values, please unclick the “Auto”. -Press “Default” to return to the manufacturer’s settings.
-
Page 7: Preview Mode
English 2. Preview Mode You can use the function buttons on the control panel to zoom in/out and move upward/downward/left/right. Zoom in the image Zoom out the image Move the image upward Move the image downward Move the image to the left... - Page 8 There are 2 categories of resolution: RGB24 and I420. You can select 5 different image resolutions for each of them. The file size of I420 will be smaller than RGB24. So, I420 may be the better choice for transmission. 3. SnapShot Mo...
- Page 9 English Shoot continuously Resolution selection This section shows the resolution you selected in the “Preview Mode”. If you want to change the resolution, please click “ ”to go back to the “Preview Mode” to make the changes. 4. Video Clip Mode You can record real-time image in this section.
- Page 10 Press to return to the video recording mode This function has to be under the resolution of RGB24 320 x 240 or I420 320 x 240. Please make sure the resolution is correct before executing this function. Resolution selection This section shows the resolution you selected in the “Preview...
- Page 11 Start recording Stop recording Setup time of the security monitoring system Set up the degree of the variance for every second of recording image. W hen the differences are over the setup degree, the system will alert you. Set up the different alerting sound effects...
- Page 12 ”to go back to the “Preview Mode” and make the changes. MSN Messenger, Yahoo Messenger, AOL MSN Mess ger For live video function, you’ll need MSN Messenger version 6 or later. If you don have ’t it, please refer to t he website: http://www.msnmessenger-download.com...
- Page 13 Click on “Show Messenger Lists” and choose th e friend you want to start a video chat with. Your friend will then receive an invitation message. When your friend confirms to t alk, the video chat will start. NO E...
- Page 14 English a. Insert the Slim 321C Installation CD into the CD-ROM drive. b. The Autorun screen will bring up the installation screen. Click on “DDPlayCam” then simply follow the on-screen instructions. Once finished, DD ThemeParty and DD PrintCenter are ready to go.
- Page 15 View photo from captured pictures or animation. ew Photo . Running DD PrintCenter a. Connect the web camera into the computer b. Please go to the task bar and follow “Start” Click “Program” Choose “DDPlayCam” Click “DD PrintCenter”. Or you may execute the software by simply clicking the shortcut of “DD...
- Page 16 DD PlayCam software and saved automatically in the DD PlayCam folder within My Pictures. a. Step 1: Se lect Paper Size and Layout or Load Document PrintCenter provides you three standard paper sizes. They are A4, 4*6 and 3*5 inch styles. -16-...
- Page 17 Each layout template shows you the actual size of a single photo and the number of photos ingle paper can print, such as 24 mm*18 mm. Select the layout directly clicking the template, and then click the Next button.
- Page 18 DD PlayCam folder. Roll over any pictures you want to print and drag it directly into an empty position you would like to place it in the template. Or click an empty position first and the frame of the position is marked immediately, double click on the picture you want to print.
- Page 19 English c. Step 3: Add, Delete and Save -19-...
- Page 20 English If you want to print several copies from the same picture, you do not have to repeat the steps for dragging. You only need to select the target picture which you have already dragged into template and click the “+” button. The picture will duplicate at the next position automatically.
- Page 21 NOTE For further information about the DDPlayCam software, please go to the task bar and follow “Start” Click “Program” Choose “DDPlayCam” You can click “Click “DD ThemeParty Technical Support”; “DD ThemeParty User Guide”...
- Page 22 English “DDPl ayCam” Click “DD ThemeParty Uninstallation”, then follow the on-scr een instructions to remove the driver -22-...
