Symbol for Separate Collection in European Countries
This symbol indicates that this product is to be
collected separately.
The following apply only to users in European
countries:
This product is designated for separate collection
at an appropriate collection point. Do not dispose
of as household waste.
For more information, contact the retailer or the local authorities in
charge of waste management.
Look 316 Features
SnapShot Button
1.
You can press the snapshot button to
take the images.
LED Indicator
2.
When the Look 316 connects to the PC
successfully, the LED will light up.
Lens
3.
Adjust the focus by twisting the lens.
Swivel and Clipping Base
The flexible base design allows the
4.
Look 316 to stand easily. The adjustable
clipping base can be up to 14 mm.
-1-
English
Advertisement
Related Manuals for Genius LOOK 316
Summary of Contents for Genius LOOK 316
- Page 1 This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste. For more information, contact the retailer or the local authorities in charge of waste management. Look 316 Features SnapShot Button You can press the snapshot button to take the images.
- Page 2 English Installing the Look 316 1. Please install the driver first and then connect Look 316 to the USB port. 2. Installing the Look 316 driver a. Insert the Look 316 Installation CD into the CD-ROM drive. b. The Autorun screen will bring up the installation screen. Click on “Driver”...
- Page 3 Genius Application (Windows Only) You can use our software to capture the real-time image, record or execute the simply security function. To run the software, please go to the task bar and follow “Start” Click “Program” Choose “Look 316” Click “Look 316”. Or you may execute the software by simply clicking the shortcut of “Look 316”.
- Page 4 English Security monitoring system Exit the Genius UI Camera Control NOTE In the “camera control section”, you can personalize your camera settings for different circumstances.
- Page 5 -Press “Restore” to return to the previous settings. -Press “Save” to save the values you set up. - You can flip the image horizontally or vertically by choosing “Mirror Flip” or “Vertical Flip”. - -If your web camera is located in backlight position, you may click “Backlight Comp”...
- Page 6 English 2. Preview Mode You can use the function buttons on the control panel to zoom in/out and move upward/downward/left/right. Zoom in the image Zoom out the image Move the image upward Move the image downward Move the image to the left...
-
Page 7: Snapshot Mode
There are 2 categories of resolution: RGB24 and I420. You can select 5 different image resolutions for each of them. The file size of I420 will be smaller than RGB24. So, I420 may be the better choice for transmission. 3. SnapShot Mode... - Page 8 English Resolution selection This section shows the resolution you selected in the “Preview Mode”. If you want to change the resolution, please click “ ”to go back to the “Preview Mode” to make the changes. 4. Video Clip Mode You can record real-time image in this section.
- Page 9 Press to return to the video recording mode This function has to be under the resolution of RGB24 320 x 240 or I420 320 x 240. Please make sure the resolution is correct before executing this function. Resolution selection This section shows the resolution you selected in the “Preview...
- Page 10 ”to go back to the “Preview Mode” and make the changes. MSN Messenger, Yahoo Messenger, AOL MSN Messenger a. For live video function, you’ll need MSN Messenger version 6 or later. If you don’t have it, please refer to the website: http://www.msnmessenger-download.com to download.
- Page 11 Sign onto AOL Instant Messenger. c. Click on “Show Messenger Lists” and choose the friend you want to start with video chat. d. Your friend will then receive an invitation message. When your friend confirms to talk, the video chat will start.
- Page 12 It allows you do a virtual role-play, interacting with a virtual environment, morphing yourself into real time. DDPlayCam includes two parts: DD ThemeParty and DD ThemeParty PrintCenter.
- Page 13 English camera resolution to 320*240 and also check for your position before the web camera. Please position your face around the center if possible. Please note that if your camera resolution is not in 320*240, the software will ask you to make the change. Please follow the on-screen instructions to change the resolution to 320*240.
- Page 14 DD PlayCam software, this function allows you only to print photos generated by DD PlayCam software and saved automatically in the DD PlayCam folder within My Pictures. a. Step 1: Select Paper Size and Layout or Load Document -14-...
- Page 15 Each layout template shows you the actual size of a single photo and the number of photos a single paper can print, such as 24 mm*18 mm. Select the layout by directly clicking the template, and then click the Next button.
- Page 16 DD PlayCam folder. Roll over any pictures you want to print and drag it directly into an empty position you would like to place it in the template. Or click an empty position first and the frame of the position is marked immediately, double click on the picture you want to print.
- Page 17 English c. Step 3: Add, Delete and Save -17-...
- Page 18 English If you want to print several copies from the same picture, you do not have to repeat the steps for dragging. You only need to select the target picture which you have already dragged into template and click the “+” button. The picture will duplicate at the next position automatically.
- Page 19 You can click the Preview button, then Print. However, please note that DD PrintCenter does not provide functions for controlling or adjusting any settings of your client printer device. We recommend you should check your printer settings and the paper you have loaded before printing. NOTE For further information about the DDPlayCam software, please go to the task bar and follow “Start”...
