Congratulations on your purchase of Precision Aerobatics
Be sure you have read and understood this entire manual before you assemble this model
Do not overlook the warnings and instructions enclosed herewith or those provided by other manufacturers, and the official
AMA (Academy of Model Aeronautics) Safety Code (see at the end of this manual). They were designed to assist you in
preventing damage or injury.
The instructions below are our suggestions only on how to assemble this model. There are other ways and methods to do
so.
Precision Aerobatics has no control over the final assembly, the materials and accessories you use when assembling this
kit or the manner in which the assembled model and the installed radio system and electronic parts, are used and
maintained. Thus, no liability is assumed or accepted for any damage resulting from the use of the assembled model
aircraft or from this instruction manual including but not limited to direct, indirect, incidental, special, and consequential
damages. In no event shall Precision Aerobatics' liability exceed the original purchase price of this kit.
BY THE ACT OF ASSEMBLING AND OPERATING THE ASSEMBLED MODEL YOU ASSUME
Radio controlled model aircraft that are not properly assembled, operated and maintained can cause serious damage to
body and property. If you are not an experienced pilot and airplane modeller you must use the help of an experienced pilot
or preferably an authorized flight instructor who will assist you with the assembly and flying of this model.
SAFETY NOTES:
1.
Before assembling and flying this model read carefully any instructions and warnings of other
manufacturers for all the products you installed or used on your model (especially radio equipment and
power source).
2.
Check thoroughly before every flight that the airplanes components are in good shape and function
correctly. If you find a fault do not fly the model until you have corrected it.
3.
Radio interference caused by unknown sources can occur at any time without notice. In such a case, your
model will be uncontrollable and completely unpredictable. Make sure to perform a range check before
every flight. lf you detect a control problem or interference during a flight, immediately land the model to
prevent a potential accident
4.
Youngsters should only be allowed to assemble and fly these models under the instruction and supervision
of an experienced adult.
5.
Do not operate this model in a confined area.
6.
Do not stand in line with, or in front of a spinning propeller and never touch it with any object.
Precision Aerobatics quality control team checks each plane before it leaves the factory to ensure that each kit is in fine
condition. We have no bearing on the condition of any component parts damaged by use, modification or assembly of this
model. Inspect the components of this kit now. If you find any parts damaged or missing, contact the hobby shop who
supplied this kit immediately. We do not accept the return or replacement of parts on which assembly work has already
begun. Precision Aerobatics reserves the right to change this warranty at anytime without notice.
NOTE:
Although we have done most of the work for you and not much assembling work left in completing the model and getting
it ready to fly we urge you to read the manual thoroughly.
We have spent weeks in preparing the manual making it as detailed as possible, and you will find in it many tips and
suggestions that will help you get the most out of your plane, in the safest way possible.
We hope you'll find the manual helpful and that you'll enjoy your new model.
111
Warning – This is not a toy!
Equipment Selection
AND ACCEPT FULL LIABILITY FOR YOUR ACTIONS.
Precision Aerobatics Team
Precision Aerobatics Team
1
www.PrecisionAerobatics.com
Copyrights ©2014 Precision Aerobatics. All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR52 and is the answer not in the manual?

Questions and answers

Joe Elder
May 1, 2025

How do I secure the wings on my xr52?

Summary of Contents for Precision Aerobatics XR52

  • Page 1 Do not stand in line with, or in front of a spinning propeller and never touch it with any object. Precision Aerobatics quality control team checks each plane before it leaves the factory to ensure that each kit is in fine condition.
  • Page 2: Equipment Selection

    Equipment selection At Precision Aerobatics we have gone to great lengths developing the XR-52 in order to provide you with an aircraft like no other. We have used many unique production techniques including our revolutionary PA FiberFusion® to create the lightest, strongest aircraft possible.
  • Page 3: Pre-Assembly

    Note: There are two identical sets of servo openings on each side of the fuselage. Choose the side per your preference. Elevator servo should be mounted on one side of the fuselage (upper opening) while the rudder www.PrecisionAerobatics.com Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 4: Aileron Servo Installation

    Tip: Carefully “tap” the screws in by making a full turn in and then backing out by ¼ turn and repeat until the screw sits fully in. Shown with a long lead for illustration Drill the mounting holes with care PA Lightweight servo extension Feed the extension lead through www.PrecisionAerobatics.com Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 5 Locate the plastic ball link and install it onto the CF servo arm with the ball on the bottom side of the servo arm. Install the aileron ball link in the servo arm inner mounting hole. The order of assembly is M2x8mm bolt/ball link/CF arm/nut. Apply permanent Loctite to secure the nut. www.PrecisionAerobatics.com Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 6: Tail Section

    “fogging” the covering. If fogging occurs, it can be easily removed by wiping off with a paper towel dipped in with acetone or nail polish remover. Note: Try to pull the elevator off the stabilizer to verify the integrity of the hinges gluing. www.PrecisionAerobatics.com Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 7 Being oversize, you need to lightly sand the balsa wedge (all around) until it fits flush with the fuselage. Do not attempt to force the wedge in as this could risk inducing a permanent twist www.PrecisionAerobatics.com Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 8 Then test fit the rudder into the fuselage all the way in, align the rudder counter balance with the fin leaving a small gap that allows the rudder to deflect freely, then place the fuselage on its side and fully www.PrecisionAerobatics.com Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 9 Run the servo leads along the bottom of the fuselage and use a cable tie to hold it in place on the fuselage floor as shown in the photo. If FM or PCM RX will be used the leads can be run over the CF braces. Elevator servo Rudder servo Tail extension leads www.PrecisionAerobatics.com Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 10 CF rudder control horn Rudder linkage geometry CF CNC machined rudder servo arm Ball link underneath the servo arm CF CNC machined elevator CF elevator control Elevator linkage geometry servo arm horn and clevis www.PrecisionAerobatics.com 101010 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 11 2. Verify with a ruler that the CF stringers do NOT protrude the rear of the motor box, otherwise the motor box will be mounted with an incorrect thrust angle which will impair the XR52 flight performance, therefore, if needed, sand/file the rear ends of the stringers flush with the motorbox ply.
  • Page 12 CF rods, especially the one at the front. Spot gluing will NOT work and will allow excessive flex of the front bulkhead which can cause the motorbox to fail under loads. www.PrecisionAerobatics.com 121212 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 13: Motor And Esc Installation

    Make sure your X mount bolts are at least 14mm long. Due to the thick Install laminated XR52 mounting plate, shorter bolts may strip the thread and air baffles cause the motor box to fail under the extreme thrust. We strongly advice to use temporary (blue color) Loctite on all mounting bolts.
  • Page 14 NOTE: Install the motor with the cables positioned downwards Zip ties X mount & bolts Apply Loctite to the retaining bolt Battery lead Solder an extension lead and insulate with shrinking tubes www.PrecisionAerobatics.com 141414 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 15 Apply a little bit of thin CA around the perimeter of the rims if required to keep them firmly in place. You may use a temporary Loctite on the outer nut to avoid it from fastening or loosening after time. Loctite if needed www.PrecisionAerobatics.com 151515 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 16: Wheel Pants

    A bit of trimming to the shape will result in a perfect no gap installation (see photo). Trim LG cuffs to a perfect fit LG cuffs – leave minimum gap M3x10mm Mounting bolts Mount the LG Apply covering www.PrecisionAerobatics.com 161616 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 17: Cowling Attachment

    Tip: It is easier to fit the cowl first with the hatch off as it allows you to push the upper cowl surface over the front bulkhead. Then fit the hatch under the cowl overlap, adjust and continue the procedure of final installation of the cowl. www.PrecisionAerobatics.com 171717 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 18: Wing Attachment

    If a gap is present simply follow the step above and sand down the wing tube to improve the fitting. www.PrecisionAerobatics.com 181818 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 19: Center Of Gravity (Cg)

    # AC-2210). CG of 107.5-108.5mm is more for sport/IMAC flying or in windy condition. NOTE - The XR-52 is an excellent high speed precision aerobatics and slow 3D performer; therefore, in order to achieve the best of both worlds we spent many hours testing the CG to find the “sweet spot” that offers a peak in overall performance.
  • Page 20: Applying The Decals

    Applying the Decals As a final touch decorate your XR-52 using the supplied PA stickers. Use the following photos as a guide. Apply white/grey sticker on the cowl to match the fuselage trim www.PrecisionAerobatics.com 202020 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 21 Following the steps in this sequence is a guaranteed method to success! Pin holes Sharpened paper clip Vortex Generator Slots www.PrecisionAerobatics.com 212121 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 22: Replacement Parts List

    3D flights with the correct linkage geometry to fit the XR-52. Incredibly light weight and accurately CNC machined in our facility. Snap installation - No glue required Hardware and instruction are included. www.PrecisionAerobatics.com 222222 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 23 Carry your batteries to the field in a padded enclosed bag that protects your lipos. Two lines of pockets allow up to 20 Lipos, or can be used for only 10 packs with and once discharged move the pack to the “Discharged” pockets www.PrecisionAerobatics.com 232323 Copyrights ©2014 Precision Aerobatics. All rights reserved...
  • Page 24 ® set up including Thrust ® motor and Quantum Pro ESC! A winning combination thoroughly tested with proven performance. Go to www.vimeo.com/channels/PrecisionAerobatics to watch hundreds of videos of Precision Aerobatics models using Thrust / Quantum setups. www.VoxProps.com www.Thrustmotors.com...
