Congratulations on your purchase of Precision Aerobatics
Be sure you have read and understood this entire manual before you assemble this model
Do not overlook the warnings and instructions enclosed herewith or those provided by other manufacturers, and the official
AMA (Academy of Model Aeronautics) Safety Code (see at the end of this manual). They were designed to assist you in
preventing damage or injury.
The instructions below are our suggestions only on how to assemble this model. There are other ways and methods to do
so.
Precision Aerobatics has no control over the final assembly, the materials and accessories you use when assembling this
kit or the manner in which the assembled model and the installed radio system and electronic parts, are used and
maintained. Thus, no liability is assumed or accepted for any damage resulting from the use of the assembled model
aircraft or from this instruction manual including but not limited to direct, indirect, incidental, special, and consequential
damages. In no event shall Precision Aerobatics‟ liability exceed the original purchase price of this kit.
BY THE ACT OF ASSEMBLING AND OPERATING THE ASSEMBLED MODEL YOU ASSUME
Radio controlled model aircraft that are not properly assembled, operated and maintained can cause serious damage to
body and property. If you are not an experienced pilot and airplane modeller you must use the help of an experienced pilot
or preferably an authorized flight instructor who will assist you with the assembly and flying of this model.
SAFETY NOTES:
1.
Before assembling and flying this model read carefully any instructions and warnings of other
manufacturers for all the products you installed or used on your model (especially radio equipment and
power source).
2.
Check thoroughly before every flight that the airplanes components are in good shape and function
correctly. If you find a fault do not fly the model until you have corrected it.
3.
Radio interference caused by unknown sources can occur at any time without notice. In such a case, your
model will be uncontrollable and completely unpredictable. Make sure to perform a range check before
every flight. lf you detect a control problem or interference during a flight, immediately land the model to
prevent a potential accident
4.
Youngsters should only be allowed to assemble and fly these models under the instruction and supervision
of an experienced adult.
5.
Do not operate this model in a confined area.
6.
Do not stand in line with, or in front of a spinning propeller and never touch it with any object.
Precision Aerobatics quality control team checks each plane before it leaves the factory to ensure that each kit is in fine
condition. We have no bearing on the condition of any component parts damaged by use, modification or assembly of this
model. Inspect the components of this kit upon receipt. If you find any parts damaged or missing, contact the hobby shop
who supplied this kit immediately. All warranty claims to be submitted within 30 days of purchase and include the original
dated receipt. This warranty is extended to the original purchaser only. We do not accept the return or replacement of
parts on which assembly work has already begun. Precision Aerobatics reserves the right to change this warranty at
anytime without notice.
NOTE:
Although we have done most of the work for you and not much assembling work left in completing the model and getting
it ready to fly we urge you to read the manual thoroughly.
We have spent weeks in preparing the manual making it as detailed as possible, and you will find in it many tips and
suggestions that will help you get the most out of your plane, in the safest way possible.
We hope you‟ll find the manual helpful and that you‟ll enjoy your new model.
111
Warning – This is not a toy!
Equipment Selection
AND ACCEPT FULL LIABILITY FOR YOUR ACTIONS.
Precision Aerobatics Team
1
www.PrecisionAerobatics.com
Copyrights ©2015 Precision Aerobatics. All rights reserved
