2 Piping Diagrams
8-16HP
Figure 2-2.1: 8-16HP piping diagram
3
Legend
No.
1
2
3
4
5
6
7
8
9
8
XX
T4
4
2
12
1
13
Parts name
Compressor
Discharge temperature sensor
High pressure sensor
Oil separator
Heat exchanger
Electronic expansion valve (EXV)
Fan motor
Fan
Stop valve (liquid side)
7
EXVA
6
5 XX
° C
T3
° C
SV2
13
11
13
No. Parts name
10 Stop valve (gas side)
11 Accumulator
12 Low pressure switch
13 Solenoid valve
T3 Heat exchanger temperature sensor
T4 Outdoor ambient temperature sensor
SV2 Liquid injection valve
SV4 Oil return valve
SV7 Pressure valve
VC Pro VRF 50/60Hz
