TA Service TA IQ RWD Assembly And User's Manual

Docking anchoring set
Hide thumbs Also See for TA IQ RWD:

Advertisement

Table of Contents

Docking anchoring set
Model: TA IQ RWD
Assembly and
user manual
MEANING OF THE AP-
PLIED MARKERS
Safety instructions with a coloured back-
ground are mandatory and need to be
observed under any circumstance!
 This symbol indicates tips and recom-
mendations
[ ] Reference to a picture number
( ) Reference to a function element within
a picture.
INTRODUCTION
Read and observe this manual before
first operation. Children and adolescents
should read this document if necessary
together with their parents or a supervisor
or accompanying person before first use.
The user manual at hand should help you
get accustomed to the handling of your
product.
This product is a technical aid. It is subject to
explanations, requires regular care and can
cause danger when used improperly. The
correct handling must therefore be learned.
TA IQ FWD
TA IQ MWD
Users with visual impairments can find the
PDF-files together with further information
on our website:
< www.meyra.com >.
 Contact your specialist dealer when re-
quired.
Information about product safety and pos-
sible recalls of our products can be found in
the < Information center > on our website:
< www.meyra.com >.
The product meets the demands of ISO
7176-19.
LIST OF MODELS
This assembly and user manual is valid for
the following model options:
TA IQ RWD
TA IQ FWD
TA IQ MWD
en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TA IQ RWD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TA Service TA IQ RWD

Summary of Contents for TA Service TA IQ RWD

  • Page 1 Docking anchoring set Model: TA IQ RWD TA IQ FWD TA IQ MWD Assembly and user manual MEANING OF THE AP- Users with visual impairments can find the PDF-files together with further information PLIED MARKERS on our website: < www.meyra.com >. Safety instructions with a coloured back-...
  • Page 2 The Dahl Engineering docking anchoring set is solely to be used together with a Dahl Engineering anchoring unit mount- ed expertly into a motor vehicle < www. dahlengineering.dk >. The wheelchair adaption kits [3] for both of the Dahl Engineering anchoring units [1] + [2] are identical and can be used for both anchoring units.
  • Page 3 ASSEMBLY The following assembly is to be carried out by a professionally qualified person. Detailed information to the assembly tips of the Dahl Dockingstation inside the mo- tor vehicle can be obtained per e-mail at: < sales@dahlengineering.dk >. Safety instructions The electric wheelchair is to be switched off during assembly in order to prevent unintentional rolling movements.
  • Page 4 8. Loosen the 4 screws underneath the bottom of the electric wheelchair [4].  In order to ease a later assembly of the lifting piston, loosen the up- per screw first and saw of the head of the screw. Afterwards turn the screw back into the thread hole, so that about 10 mm of the screw is still visible above the thread hole (5).
  • Page 5 11. With a flat tool (for example an ruler) check, whether the screws are sticking out of the holes [1].  If the screws are sticking out of the holes, grind them flat (for example with an angle grinder) [2]. 12.

  • Page 6: Safety Instructions

    USER MANUAL For handicapped transport inside a motor vehicle observe the document <  Safety Safety instructions with Meyra-wheelchairs, also during trans- port in motor vehicles  > on our website The value noted on the label expresses < www.meyra.com >. the wheelchair’s ground clearance (minus 1-2 mm).
  • Page 7 Securing the wheelchair in the 4. Do not forget to buckle up for driving. docking station Release from docking station Do not move the vehicle: When the vehicle has been brought to – whilst the wheelchair is being maneu- a halt, remove the safety belt. vered into position in the docking 2.

  • Page 8: Emergency Release

    Manual release in case of electric failure A manual emergency release is located at the front edge of the docking station. Move wheelchair forward to remove the pressure on the lock pin and push the red release arm to one side and hold it there while the wheelchair moves away.
  • Page 9 Overview Dahl docking station MKII (1) Dahl docking station (2) Lock plate and spacer (3) Lock pin (4) Red LED (wheelchair NOT secured, can be removed from docking station) (5) Green LED (wheelchair IS secured) (6) Control panel 5.7 5.8 5.9 (7) Release button (8) Manual emergency release lever (9) Manual operating lever...
  • Page 10 Funktion of the docking station The Dahl VarioDock™ (1) is designed to re- tain manual and electric wheelchairs, as well as Dahl’s seat bases in the vehicle’s floor. A control module (6) controls and monitors Dahl VarioDock™’s features, distributes pow- er to the various components, as well as re- ceiving and sending signals to and from the control panel.

  • Page 11: Maintenance

    MAINTENANCE An incorrect or neglected cleaning and maintenance of the product results in a lim- itation of the product liability. Maintenance The following maintenance Instruction gives you a guide for carrying out the main- tenance work.  They do not give information about the actual extent of work required on the product.

  • Page 12: Technical Data

     Therefore observe chapter < Warranty / Guarantee > of the operating manual of your wheelchair. TA Service A/S Centervej Syd 2 4733 Tappernnøje DENMARK +45 56 72 57 77 This product is conform with the EC-direc- ta-service@ta-service.dk...
