- Page 1 Art.nr: 95346 TA. Service A/S · Centervej Syd 2 · DK-4733 Tappernøje Tlf +45 56 72 57 77 · Fax +45 56 72 57 76 · www.ta-service.dk Ver. 2.3 Eng 2015...
-
Page 2: Warnings
TA Indoor Wave is not intended for users with a weight exceeding 120 kg TA Indoor Wave should always be turned off when making entry and exit of the chair and when assisted by a helper, so that the chair does not accidentally run if the joystick is activated. -
Page 3: Preface
TA Services A/S hope you are satisfied with your new TA Indoor Wave. TA Indoor Wave is designed to facilitate your daily movement indoors and outdoors close to your home. It has been very important to design the chair as small and compact as possible, without reducing the chair's stability and handling. -
Page 4: Table Of Contents
Contents Warnings..............................2 Preface ............................... 3 ce decalration ............................. 3 Technical Data ............................5 4.1 Serial number ..........................6 Before driving: ............................7 Performance check ..........................8 Swing-away bracket .......................... 8 Getting in and out of the wheelchair ....................9 While driving: ............................ -
Page 5: Technical Data
4 TECHNICAL DATA Wheelchair Type: Class A: Wheelchairs mainly intended for indoor use and are not necessarily doing outdoor hurdles. Dimensions: Width excl. seat: 56 cm Length excl. footplate / foot supports: 69.5 cm Length incl. Standard footplate: 88.5 cm Diagonal excl. -
Page 6: Serial Number
It is possible to set how fast the chair's slowdown will be. If this change is wanted please contact TA Service A/S. Electromagnetic brake is activated when the chair is stationary and serves as a "parking"... -
Page 7: Before Driving
TA Indoor Wave is not intended for users with a weight exceeding 125 kg WARNING! TA Indoor Wave should be turned off when making entry and exit of the chair and when assisted by a helper, so that the chair does not accidentally run if the joystick is activated. -
Page 8: Performance Check
Joystick: With the control system switched off, check that the joystick is not bent or damaged and that it returns to the center when you push and release it. If there is a problem do not continue with the safety checks and contact TA Service or your service agent. Weekly Checks Parking brake: This test should be carried out on a level floor with at least one meter clear space around the wheelchair. -
Page 9: Getting In And Out Of The Wheelchair
5.3 Getting in and out of the wheelchair ! Before getting in and out of the wheelchair, make sure that the wheelchair is turned off. If the user can transfer itself, lower the tilt and the lift to the lowest position. For transferring from the front tilt the footplate up figure 1 Figure 1... -
Page 10: While Driving
6 WHILE DRIVING: TA Indoor Wave's driving characteristics including: braking, maximum speed and acceleration can be set to suit the individual needs. Setting the chair's driving characteristics is performed by TA Services A/S. 6.1 Speed and profiles TA Indoor Wave is switched on by a light pressure on the Power button. -
Page 11: Mechanical Disengaging The Brakes
This kind of slowdown should to the fullest extent be avoided on sloping surfaces and ramps. 6.5 Force of obstacles. TA Indoor Wave can climb obstacles, making it able to run over smaller doorsteps and the like. At very steep increases may be necessary inlet and a certain speed. -
Page 12: Driving On Slopes
When driving on slopes, seat should not be lifted to keep the chair's stability. 6.7 Surfaces TA Indoor wave is fitted with a pattern tread on the big drive wheel for best grip. If the tread is worn, it will affect the grip on the surface. -
Page 13: Controller/Adjustents
8 CONTROLLER/ADJUSTENTS 8.1 Controller 1 Power button 2 Horn 3 Light* 4 Hazard* 5 Display 6 Profile 7 Switching between driving and menu 8 Speed up button. 9 Speed down button. 10 Right indicator light* 11 Left indicator light * * - Accessories on some versions Display 1 - Battery indicator:... -
Page 14: Locking The Joystick
DANGER!!! Programming of the power chair must be performed by TA Service or repairer who is authorized by TA Service. Unauthorized programming can cause that the power chair will handle in a way that could cause danger to the user or the surroundings. -
Page 15: Setting Menu
(The display is more visible with a white background in bright sunlight) Auto = The chair can be programmed to display different backgrounds at different profiles. Contact TA Service for special adaptation. Distance - following submenu appears: (Figure 3) Total distance: total distance power module has been running Trip distance: Trip odometer - can be reset. -
Page 16: Setting The Power Functions
8.4 Setting the power functions The wheelchair may depending on model have the following power functions: Seat lift Seat tilt Back Right legsupport Figure 1 Left legsupport The functions are activated by pressing the "Mode" button on the control box, then there's a picture of power features (figure 1). -
Page 17: Alternative Controls/Functions
The system is set up to function as max speed. If profiles (fx 1 slow and 1 quick) are wanted instead, please contact TA Service for different programming. Adjusting speed (or choice of profile, depending on setting) Battery indicator Shows that the power chair is on, plus status of batteries. - Page 18 Red, yellow and green light (1-10 lights: This indicates all is well. Red and yellow light (1-7 lights): The control system is functioning correctly, but you should charge the battery as soon as possible. Red lights (1-3 lights constant or flashing): The power chair must be charged immediately not to destroy the batteries.
-
Page 19: Adjustments
10 ADJUSTMENTS 10.1 Setting the armrests. Armrest cushion position relative to the back is adjusted by loosening the 2 screws under the horizontal tube with a 4 mm Allen key (A1), and the 2 screws in the c-profile with a 6 mm Allen key (A2) Armrest height is adjustable by loosening screws (B) on the armrest vertical tube with a 4mm Allen key. -
Page 20: Setting Up The Leg Rest
(E) behind the footplate with a 5 mm Allen key. 10.4 Mounting of hipbelt. It is possible to mount a hip belt on TA Indoor Wave. TA Service recommends that the hip belt is attached by the back bracket (A) or on the bracket of the seats... -
Page 21: Transportation By Car
(accessories), so it can be used as a seat in the car, bus or similar. The user can use the TA Indoor Wave during transport by car, bus or similar, if the TA Indoor Wave is equipped with TA 4-point car tiedown and/or Dahl Docking system. -
Page 22: Charging
12 CHARGING. TA Indoor Wave is equipped with a battery level indicator at the top of the control box - the long series of LEDs. As the chair is used the battery level falls and the LEDs turn off. See the following explanation:... -
Page 23: Disposal
V-O classified, ISO UL94 15 WARRANTY. There is 2 year warranty on TA Indoor Wave. Valid from date of purchase. Any warranty repairs will be performed free of charge with regard to working hours and spare parts. The warranty period on batteries and supplied by TA Service is 1 year from purchase date. -
Page 24: Troubleshooting - Controller With Display
17 TROUBLESHOOTING – CONTROLLER WITH DISPLAY Problem: Cause: Solution: The power chair cannot run 1. Charging connector is Remove the charging plug. connected to the control box. 2. Motor brake is disengaged. Connect the motor brakes. 3. Other cause. Contact authorized service center. The chair drives slowly. -
Page 25: Troubleshooting - Controller Without Display
17.1 Troubleshooting – controller without display If a system failure should occur, you can find the cause by counting the number of light diodes flashing – If light diodes lights constant – see chapter “CONTROLLER WITHOUT DISPLAY” Number of light diodes flashing: Cause: Solution: 1. -
Page 26: Service And Maintenance
A service manual is available for dealers and service agents – contact TA. Service for more information TA Service recommends that the wheelchair get service at a Dealer or at the factory of TA Service. ! Maintenance and service that are not listed under SERVICE AND MAINTENANCE and ADJUSTMET shall be done by the service agent, dealer or TA Service. -
Page 27: Fuse
18.4 Batteries: The batteries are maintenance-free. (no topping up) It is recommended that only the dealer or TA service replaces the batteries, they will also take care of the disposal. If the batteries run out of current the wheelchair can be pushed, see section: MECHANICAL DISENGAGING THE BRAKES. -
Page 28: Tyre Punctures
18.6 Tyre punctures: Start by lifting the wheelchairs wheel free from the ground, either by using a lift or by putting something stable between the bottom frame and the ground. Figure 1 ! Tilt or lift only the wheelchair when the user is not in the wheelchair Figure 1 Castors... - Page 29 Drive wheel Lift the wheelchair – see introduction and figure 1 Take the plastic cover off the nut with a screwdriver. Figure 5 Figure 5 Loosen the bolt in the center of the wheel with a 17 mm socket spanner and pull off the wheel from the shaft.
-
Page 30: Accessories And Spareparts
Figure 9 Figure 9 19 ACCESSORIES AND SPAREPARTS TA Service is constantly developing various accessories. For more information about accessories and spare parts contact the local dealer or TA Service.
