Operation
A – DAP connector
Pinout valid on the DAP connector side:
Signal
Signal Direction
Description
Reference
O
voltage
Ground
Ground
Not Connected
Ground
Signal Direction is described from the BlueBox perspective.
B – DB9 connector
Pinout valid on the DB9 connector side:
C – The LED indicator provides the status of the hardware as follows:
·
Green – Powered on
·
Red – Power supply issue (e.g., burnt fuse)
D – Power supply connection for the Converter. Use provided USB-C cable to power the converter
e.g. from a PC.
Signal
Pin
Vref
1
GND
3
GND
5
NC
7
GND
9
DAP connector pinout
Pin
1
2
3
4
5
6
7
8
9
DB9 connector pinout
Pin
Signal
2
TXD
4
NC
6
RXD
8
NC
10
NC
Signal
Not Connected
CAN_L
CAN GND
NC
SHIELD
NC
CAN_H
NC
NC
Signal Direction
Signal
Description
I
Transmitter
Not Connected
O
Receiver
Not Connected
Not Connected
