- Page 1 DAP OVER CAN HARDWARE USER MANUAL V1.6, May 2024 www.tasking.com...
- Page 2 Use included power cord and power supply The enclosed power supply has been approved for use by TASKING. Please contact TASKING if you need to consider an alternative power.
-
Page 3: Table Of Contents
Contents Introduction ......................4 Package content ....................5 Operation ......................6 winIDEA Configuration ................... 8 Accessories ...................... 9 User Notes ...................... 10 www.tasking.com... -
Page 4: Introduction
Infineon DAP/DAPE Active Probe · and iC7max via Infineon DAP/DAPE II Active Probe or · and iC7max via Infineon AGBT Active Probe and a 10-pin 1.27 mm DAP Converter Schematic designer must assure the correct state of TRST signal on cold PORST. www.tasking.com... -
Page 5: Package Content
Package content The DAP over CAN Physical Layer Converter is delivered with the following components: DAP over CAN USB-C cable Physical Layer Converter Ordering code: IEA-DXCPL www.tasking.com... -
Page 6: Operation
C – The LED indicator provides the status of the hardware as follows: · Green – Powered on · Red – Power supply issue (e.g., burnt fuse) D – Power supply connection for the Converter. Use provided USB-C cable to power the converter e.g. from a PC. www.tasking.com... - Page 7 CAN 120 Ohm terminating resistor is not implemented on the DAP over CAN Physical Layer Converter. TASKING provides cable solutions on request with build in terminating resistor, which can be easily switched on or off. www.tasking.com...
-
Page 8: Winidea Configuration
1. Open Hardware / CPU Options / SoC. 2. Select DXCPL from the Debug channel Mode drop-down. 3. Confirm and establish the debug connection. For detailed visual presentation of the hardware setup and configuration, refer to the Getting started Tutorial - use the link isystem.com/start. www.tasking.com... -
Page 9: Accessories
The functionality of the DAP over CAN Physical Layer Converter can be extended through the use of various accessories. Description Ordering Code 1m CAN cable DB9 plug IC57040-CAN-DB9 CAN cable pin wires IC57040-CAN-PIN CAN cable banana jacks IC57040-CAN-JACK CAN BUS T adapter IC57040-CAN-T More information about our products via sales@tasking.com. www.tasking.com... -
Page 10: User Notes
User Notes This page is intentionally left blank. www.tasking.com... - Page 11 This page is intentionally left blank. www.tasking.com...
- Page 12 Visit our website for: · Support - isystem.com/support · Tutorials - isystem.com/start · Knowledge Base - kb.isystem.com www.tasking.com www.tasking.com...
