Introduction

DAP over CAN Physical Layer Converter enables debugging via the regular CAN pins of the ECU
connector without opening its housing. This connection is electrically robust due to the nature of
the CAN bus. The DXCPL Converter translates Infineon Aurix™ SPD (Single Pin DAP) encoded DAP
messages to the CAN bus physical layer. Hardware solution supports DXCPL on Infineon Aurix™
TC2xx and TC3xx devices.
For details about DXCPL operation, refer to
DAP over CAN Physical Layer Converter can be used with iC5700 BlueBox:
·
via DTM or
·
and iC7max via Infineon DAP/DAPE Active Probe
·
and iC7max via Infineon DAP/DAPE II Active Probe or
·
and iC7max via Infineon AGBT Active Probe
Schematic designer must assure the correct state of TRST signal on cold PORST.
Infineon Application Note
or
and a 10-pin 1.27 mm DAP Converter
AP32264.
